Strona 1/32
1
Safety Instructions ........................ 2-5
Operating Instructions
Oven ............................................. 7-13
Surface Burners .............................. 6
Care and Cleaning
Broiler Compartment .................... 17
Broiler Pan and Grid ...................... 18
Burners .............................................. 15
Control Panel and Knobs ............... 6
Grates .............................................. 14
Lift-Up Cooktop .............................. 14
Lift-Off Oven Door .......................... 18
Oven Interior ................................... 19
Painted Surfaces ............................ 19
Removable Oven Bottom ............ 17
Shelves ............................................. 16
Thermostat Adjustment ................. 11
Installation Instructions ............ 20-28
LP ...................................................... 28
Troubleshooting Tips ...................... 29
Warranty ........................................... 31
Write the model and serial
numbers here:
You can find them on a label under
the cooktop. See the Lift-Up Cooktop
section in this manual for instructions
on how to lift the cooktop.
Owner's Manual and
Installation Instructions
RG200W
RG244W
Model #
Serial #
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
If the information in this manual is not followed exactly, a fire or explosion may result,
causing property damage, personal injury or death.
IMPORTANT SAFETY NOTICE
All ranges can tip. BURNS or other SERIOUS INJURIES can result. INSTALL and CHECK the anti-tip
bracket following the instructions supplied with the bracket. To reduce the risk of tipping the
range, the range must be secured by a properly installed anti-tip bracket See installation
instructions shipped with the bracket for complete details before attempting to install.
To check if the bracket is installed and engaged properly, look underneath the range to see
that the rear leveling leg is engaged in the bracket On some models, the storage drawer or
kick panel can be removed for easy inspection. If visual inspection is not possible, slide the
range forward, confirm the anti-tip bracket is securely attached to the floor or wall, and slide
the range back so the rear leveling leg is under the anti-tip bracket.
If the range is pulled from the wall for any reason, always repeat this procedure to verify the
range is properly secured by the anti-tip bracket.
Never completely remove the leveling legs or the range will not be secured to the anti-tip
device properly.
If you did not receive an anti-tip bracket with your purchase, call 1-800-932-4267 toll-free to
receive one at no cost.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
WARNING
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to
warn customers of potential exposure to such substances.
The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during the cleaning cycle.
Exposure can be minimized by venting with an open window or using a ventilation fan or hood.
WARNING
WARNING
SAVE THESE INSTRUCTIONS
3
Use this appliance for its intended purpose as described
in this owners manual.
Have your range installed and properly grounded by a
qualified installer in accordance with the provided
installation instructions. Any adjustment and service
should be performed only by qualified gas range
installers or service technicians. Do not attempt to repair
or replace any part of your range unless it is specifically
recommended in this manual.
Your range is shipped from the factory set for use with
natural gas. It can be converted for use with LP gas. If
required, these adjustments must be made by a
qualified technician in accordance with the installation
instructions and local codes. The agency performing this
work assumes responsibility for the conversion.
Have the installer show you the location of the range
gas shut-off valve and how to turn it off if necessary.
Plug your range into a 120-volt grounded outlet only. Do
not remove the round grounding prong from the plug. If
in doubt about the grounding of the home electrical
system, it is your responsibility and obligation to have an
ungrounded outlet replaced with a properly grounded,
three prong outlet in accordance with the National
Electrical Code. Do not use an extension cord with this
appliance.
Before performing any service, unplug the range or
disconnect the power supply at the household
distribution panel by removing the fuse or switching off
the circuit breaker.
Be sure all packing materials are removed from the
range before operating to prevent ignition of these
materials.
Avoid scratching or impacting glass doors, cooktops or
control panels. Doing so may lead to glass breakage. Do
not cook on a product with broken glass. Shock, fire or
cuts may occur.
GENERAL SAFETY INSTRUCTIONS
WARNING
WARNING
NEVER use this appliance as a space heater to
heat or warm the room. Doing so may result in
carbon monoxide poisoning and overheating of
the oven.
SAVE THESE INSTRUCTIONS
Do not leave children alone or unattended in an area
where an appliance is in use. They should never be
allowed to climb, sit or stand on any part of the
appliance.
Do not store items of interest to children above a range
or on the backguard of a range-children climbing on
the range to reach items could be seriously injured.
Do not allow anyone to climb, stand or hang on the
oven door, drawer or cooktop. They could damage the
range or tip it over causing severe injury or death.
Never block the vents (air openings) of the range. They
provide the air inlets and outlets that are necessary for
the range to operate properly with correct combustion.
Air openings are located at the rear of the cooktop, at
the top and bottom of the oven door, and at the
bottom of the range under the warming drawer, lower
oven drawer or kick panel.
Use only dry pot holders—moist or damp pot holders on
hot surfaces may result in burns from steam. Do not let
pot holders touch surface burners, burner grate, or oven
heating element Do not use a towel or other bulky cloth
in place of pot holders.
Be careful not to touch hot surfaces of the range.
Potentially hot surfaces include burners, grates, cooktop,
backguard, oven and door interior and crevices around
the oven door.
Do not heat unopened food containers. Pressure could
build up and the container could burst, causing an
injury.
To protect against foodborne illness, ensure that
temperatures of meat and poultry products meet or
exceed the USDA minimum recommended
temperatures for food safety. For more information see:
www.isitdoneyet.gov or call the USDA meat and poultry
hotline at 1-888-674-6854.
