04064ULSUMNAT (ENG) . .2016 07 11
BUILT-IN CERAMIC GAS COOKTOPS
Models GC2BGL
GC424BGL
Instruction Manual
Dear Customer,
Thank you for buying one of our ceramic gas cooktops. We are sure
that this modern, functional and practical appliance, made using the
finest quality materials, will fully satisfy your requirements.
This new appliance is very easy to use, but in order to obtain the best
results, we strongly recommend that you read this booklet carefully
before use. The manufacturer cannot be considered responsible for
any damages to people or things in the event of incorrect installation or
improper use of this appliance.
We reserve the right to make any changes to our products which we
consider to be necessary or useful, also in the interest of the user,
without affecting the essential characteristics in terms of functionality
and safety.
The staff of
Felix Storch, Inc.
Summit Appliance Division
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, New York 10474
www.summitappliance.com
1
TABLE OF CONTENTS
Important Safeguards ............................................................... 2 - 3
Location of Parts ............................................................................ 4
Installation ................................................................................. 5 - 8
Installing the Cooktop .............................................................. 5
Sealing the Cooktop ................................................................ 6
Room Ventilation ..................................................................... 6
Gas Connection ...................................................................... 7
Electrical Connection .......................................................... 7 - 8
Adjustments ................................................................................... 9
Conversions ................................................................................. 10
Using the Cooktop ................................................................ 11 - 12
Lighting the Burners .............................................................. 11
Proper Use of the Burners .............................................. 11 12-
Cleaning ................................................................................. 13 - 14
Servicing ....................................................................................... 15
Replacing Components
Limited Warranty .......................................................................... 16
2
IMPORTANT SAFEGUARDS
the installation of appliances designed for manufactured (mobile)
homes must conform with the Manufactured Home Construction and
Safety Standard, Title 24, CFR, Part 3280 (formerly the Federal Standard
for Mobile Home Construction and Safety, Title 24, HUD (Part 280)), or
when such standard is not applicable, the Standard for Manufactured
Home Installations, ANSI/NCSBCS 225.1, or with applicable local codes.
Leak testing of the appliance shall be conducted according to the
manufacturer’s instructions.
Assure that gas connection conforms with local codes and ordinances. In the
absence of local codes, installations must conform with American National
Standard, National Fuel Gas Code ANSI Z223/NFPA 54 or Canadian
CAN/CGA_B 149.1 or CAN/CGA-149.2.
The product must be electrically grounded in accordance with local codes or, in
the absence of local codes, with the National Electrical Code, NFPA 70 or the
Canadian Electric Code, CSA C22.1-02.
The appliance and its individual shutoff valve must be disconnected from the
gas supply piping system during any pressure testing of that system at test
pressure in excess of 1/2 psi (3.5 kPa). The maximum gas supply pressure is
4 inch WC (water column) for natural gas and 11 inch WC for LP. The gas
pressure regulator provided is regulated to 1 inch WC above the manufacturer's
specified manifold pressure.
Always disconnect the electrical supply before servicing the appliance.
WARNING If the information in this manual is :
not followed exactly, a fire or explosion could
result causing property damage, physical
injury or death.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
What to do if you smell gas:
Do not try to turn on any appliance.
Do not touch any electrical switch. Do not use
any phone in your building.
