Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 02/22/2012
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 2xS-VideoExtenders(localandremoteends)
• 1x20cmS-Videocable
• 1xInstallation/MountingKit
• 1xUserManual
System Requirements
• AnS-VideovideoSource
• AnRCAcomponentaudiosource
• InputandOutputS-Videocables
• InputandOutputRCAcomponentaudiocables
• AdisplaywithanavailableS-Videoinput
SVIDUTPEXTA
S-Video Video Extender over Cat 5 with Audio
*actual product may vary from photos
Basic Setup
1. ConnecttheS-Videocabletotheoutputonthebackoftheaudio/videosource.
2. ConnecttheoppositeendoftheS-VideocableusedinStep1totheSVIDUTPEXTlocalunit(markedVIDEO).
3. ConnectanaudioRCAcomponentcabletotheoutputportslocatedontheaudio/videosource.
4. ConnecttheoppositeendofthecomponentaudiocabletotheaudioportsonthelocalSVIDUTPEXTunit(markedasL-Audio-R).
5. ConnecttheCat5cabletotheRJ45portonthelocalSVIDUTPEXTunit.
6. ConnecttheoppositeendoftheCat5cabletotheRJ45portontheremoteSVIDUTPEXTunit.
7. ConnectasecondS-VideocabletothedesignatedportontheremoteSVIDUTPEXTunit(markedVIDEO).
8. ConnecttheremainingendofthesecondS-Videocabletothemonitor/display.ForfurtherinstructionsonhowtolocatetheS-Video
port,pleaserefertothedocumentationthataccompaniedthedisplayatthetimeofpurchase.
9. ConnectanaudioRCAcomponentcabletotheaudioportslocatedontheremoteSVIDUTPEXTunit.
10.Connecttheoppositeendofthecomponentaudiocabletotheaudiooutputportslocatedontheaudiooutputdevice(i.e.Stereo
receiver,televisionetc.).
Cat5 Cable (up to 200m)
Video Source
Audio Connection
S-Video connection Display Unit
FCC Compliance Statement
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to
StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)
towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall
trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.
Technical Support
StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess
ourcomprehensiveselectionofonlinetools,documentation,anddownloads.
Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads
Warranty Information
Thisproductisbackedbyatwoyearwarranty.
Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned
forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom
misuse,abuse,alteration,ornormalwearandtear.
Limitation of Liability
InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSA LLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,
consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow
theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.
Pin Denition:
Pin Color Function
1W/O S-Video
2O S-Video
3W/G S-Video
4B AudioR
5W/B AudioR
6G S-Video
7W/BR AudioL
8BR AudioL
Specications
Local Unit
Connectors
1xS-Video(4pin;Mini-DIN)Female
1xStereoAudio(2xRCA)Female
1xRJ-45Female
Remote Unit
Connectors
1xS-Video(4pin;Mini-DIN)Female
1xStereoAudio(2xRCA)Female
1xRJ-45Female
Audio Support Yes
Dimensions (LxWxH) 110x77x24mm
Weight 460g
Maximum Resolution 480i/480p
Maximum Distance 660ft/200m
