Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: April 26, 2023 12:13 PM

Product Diagram (Side A)

(Side B)

Product ID

167B-USBC-MULTIPORT

USB-A & USB-C Hybrid Multiport Adapter - Dual HDMI - 3x USB-A

Component Function

1Built-in USB-C Host Cable • Connect to a USB-C Port on a Host Computer

• USB 3.2 Gen 1 (5Gbps)

2Tethered USB-C to USB-A

Adapter

• Connect to the Built-in USB-C Host Cable and to a

USB-A Port on a Host Computer

• USB 3.2 Gen 1 (5Gbps)

3USB-A Data Ports

• Connect USB Peripheral Devices

• USB 3.2 Gen 1 (5Gbps)

• Supports up to 5 V/0.9 A (4.5 W) of Power

4HDMI Video Port #1

• Connect an HDMI Display

• HDMI 1.4

• Up to 4K (4096x2160) 30Hz

5HDMI Video Port #2

• Connect an HDMI Display

• HDMI 1.2

• Up to 1080p (1920x1200/1080) 60Hz

Package Contents

• Multiport Adapter

• Quick-Start Guide

Requirements

• Host Computer

• With available USB-C or USB-A Port

For the latest drivers, manuals, product information, technical specications, and

declarations of conformance, please visit:

www.StarTech.com/167B-USBC-MULTIPORT

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other countries.

Warranty Information

This product is backed by a 3-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com

Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands

Regulatory Compliance

FCC - Part 15

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

Driver Installation

Installation is automatic for Windows 10 & up, and Chrome OS, in most situations.

If the drivers do not auto-install, contact your IT administrator or department to

allow the driver installation. If you are using macOS or another supported operating

system, the latest drivers are available at:

www.StarTech.com/167B-USBC-MULTIPORT

Installation

1. (Optional) Connect the to the Tethered USB-C to USB-A Adapter Built-In USB-C

Host Cable.

2. Connect the to an available on Built-In USB Host Cable USB-A or USB-C Port

the .Host Computer

3. Connect the HDMI displays, to the located on the HDMI Output Ports Multiport

Adapter, using HDMI cables (sold separately).

4. Connect the USB peripherals to the , located on the Multiport USB-A Data Ports

Adapter.

Operation

Change Display Settings in macOS

Intel Based Mac Devices

To change the Screen Rotation or other Settings, use the operating system’s

Display Settings.

M1/M2 Based Mac Devices

To Mirror/Extend the connected displays, use the . The InstantView App

InstantView App InstantView App is accessible by Single Clicking the Icon in the

Menu Bar.

To change the Screen Rotation or other Settings, use the by RightInstantView App

Clicking/Double Clicking the Icon in the , which will InstantView App Menu Bar

bring up a variety of available settings.
