Display Cabinet
Display Controller
Operating Instructions
Before operating the unit, please read this manual and the supplied Before Using This Unit document thoroughly and re-
tain it for future reference.
ZRD-CH12D/ZRD-CH15D/ZRD-BH12D/ZRD-BH15D
ZRD-C12A/ZRD-C15A/ZRD-B12A/ZRD-B15A
ZRCT-300
ZRK-CH12D/ZRK-CH15D/ZRK-BH12D/ZRK-BH15D
5-029-334-15 (1)
© 2021 Sony Corporation
2
Table of Contents
Please Read This First ..................................3
Manual Structure .....................................3
Condensation ..........................................3
Security ....................................................3
Burn-in .....................................................3
Defective pixels ...................................... 4
General Precautions ............................... 4
Precautions on viewing and displaying
3D images ............................................... 4
Precautions on the environment when
displaying 3D images ............................. 4
Precautions regarding the effect on
medical devices ...................................... 4
Precautions on visually induced motion
sickness (VIMS) and postural
instability .................................................5
Other precaution .....................................5
Overview ..................................................... 6
System Configuration Diagram .............. 6
Parts Identification .......................................7
Display Cabinet .......................................7
ZRCT-300 Display Controller .................. 9
Turning the Power On/Off ..........................11
Turning the Power On ............................11
Turning the Power Off ........................... 12
Selecting the Video Input .......................... 13
Changing the Display Starting Positions
of Pictures .............................................. 14
Configuring the Input Level and Signal
Format for HDMI Inputs ......................... 15
Displaying a Black Picture on the
Screen .................................................... 15
Adjusting the Picture Quality .....................16
Displaying 3D Video ................................... 19
Displaying the test pattern for each Display
Cabinet ...................................................... 20
Displaying the selected test pattern on
a Display Cabinet .................................. 21
Synchronizing with External Sync
Signals ........................................................22
Inputting External Sync Signals ............22
Enabling External Synchronization .......22
Synchronizing with the camera being
used for shooting ..................................22
Using Network Features .............................24
Displaying the Control Window of the
Display Controller with a Web
Browser ..................................................25
Setting the Control Protocol of the
Display Controller ..................................26
Troubleshooting .........................................27
Error Codes ................................................ 29
Display Cabinets ................................... 29
Display Controllers ................................30
Cleaning and Storage .................................31
Display Cabinets ....................................31
Display Controllers .................................31
Signal Formats ............................................31
2D Inputs ................................................31
3D Inputs ............................................... 32
Supported Signal Formats for a Single
Controller .............................................. 33
NOTICES AND LICENCES FOR SOFTWARE
USED IN THIS PRODUCT ............................. 35
Trademarks
• Products or system names appearing in this
document are trademarks or registered
trademarks of their respective owners.
Further, the ® or ™ symbols are not used in the
text.
• The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing Administrator, Inc. in the United
States and other countries.
• DisplayPort is a trademark or registered
trademark of Video Electronics Standards
Association in the United States and other
countries.
• Reproduction or duplication, in whole or
part, of the operation manual supplied with
the system without the authorization of the
right holder is prohibited under copyright
law.
• Note that the specifications of the system
are subject to change for improvement
without prior notice.
3
Please Read This First
For ZRK-CH12D/ZRK-CH15D/ZRK-BH12D/ZRK-
BH15D, ZRD-CH12D/ZRD-CH15D/ZRD-BH12D/
ZRD-BH15D and ZRCT-300 are included.
Manual Structure
This product includes the following manuals to
be used according to the situation.
Before Using This Unit (ZRD-CH12D/ZRD-
CH15D/ZRD-BH12D/ZRD-BH15D, ZRD-C12A/
ZRD-C15A/ZRD-B12A/ZRD-B15A, ZRCT-300)
This includes important safety precautions,
specifications, etc.
Before Using This Unit (ZRK-CH12D/ZRK-
CH15D/ZRK-BH12D/ZRK-BH15D)
This includes important safety precautions,
specifications, etc.
Installation Manual
This includes information on installation, initial
setup, equipment adjustment procedures, etc.
Refer to this manual when changing equipment
settings or performing readjustments after
installation as well.
Operating Instructions (this document)
This includes information on video input
selection, picture quality adjustment, parts
identification, etc. Refer to this manual when
performing general operations.
Service Manual
This is intended for use by service personnel and
includes information on diagnosing
malfunctions and instructions on repair.
Condensation
If the unit is suddenly taken from a cold to a
warm location, or if ambient temperature
suddenly rises, moisture may form on the outer
surface of the unit and/or inside of the unit. This
is known as condensation. If condensation
occurs, turn off the unit and wait until the
condensation clears before operating the unit.
Operating the unit while condensation is present
may damage the unit.
Security
• SONY WILL NOT BE LIABLE FOR DAMAGES OF
ANY KIND RESULTING FROM A FAILURE TO
IMPLEMENT PROPER SECURITY MEASURES ON
TRANSMISSION DEVICES, UNAVOIDABLE DATA
LEAKS RESULTING FROM TRANSMISSION
SPECIFICATIONS, OR SECURITY PROBLEMS OF
ANY KIND.
• Depending on the operating environment,
unauthorized third parties on the network may
be able to access the unit. When connecting
the unit to the network, be sure to confirm that
the network is protected securely.
• This unit is equipped with a maintenance
function performed via a network.
Maintenance may be performed with your
consent.
• From a safety standpoint, when using the unit
connected with the network, it is strongly
recommended to access the Control window
via a Web browser and change the access
limitation settings from the factory preset
values.
Also, it is recommended that you set a
password with a sufficiently long character
string that is hard to guess by others, and that
you store it safely.
• Do not browse any other website in the Web
browser while making settings or after making
settings. Since the login status remains in the
Web browser, close the Web browser when you
complete the settings to prevent unauthorized
third parties from using the unit or harmful
programs from running.
• When connecting this product to a network,
connect via a system that provides a protection
function, such as a router or firewall. If
connected without such protection, security
issues may occur.
Burn-in
Permanent burn-in may occur if a still image is
displayed for a prolonged period of time. Playing
a video with moving images may reduce the
severity of burn-in once it occurs, but it will not
remove the burn-in completely.
