Strona 1/218

User Guide

Personal Computer

VPCZ12 Series

n N

Contents

Before Use.......................................................................... 4

Finding More about Your VAIO Computer .................... 5

Ergonomic Considerations ............................................ 8

Getting Started.................................................................. 10

Locating Controls and Ports........................................ 11

About the Indicator Lights ........................................... 17

Connecting a Power Source ....................................... 18

Using the Battery Pack................................................ 20

Shutting Down Your Computer Safely ........................ 27

Using the Power Saving Modes .................................. 28

Keeping Your Computer in Optimum Condition .......... 30

Using Your VAIO Computer.............................................. 32

Using the Keyboard..................................................... 33

Using the Touch Pad................................................... 36

Using Special-function Buttons ................................... 37

Using the Built-in Camera ........................................... 38

Using the Optical Disc Drive ....................................... 39

Using "Memory Stick".................................................. 47

Using Other Modules / Memory Cards........................ 54

Using the Internet........................................................ 62

Using the Network (LAN) ............................................ 63

Using the Wireless LAN ............................................. 64

Using the Wireless WAN .............................................69

Using the Bluetooth Function ......................................73

Using Fingerprint Authentication .................................79

Using the TPM.............................................................86

Using Peripheral Devices..................................................96

Using the Noise Canceling Headphones.....................97

Connecting a Port Replicator.....................................104

Connecting an Optical Disc Drive..............................112

Connecting External Speakers or Headphones ........114

Connecting an External Display ................................115

Selecting Display Modes ...........................................122

Using the Multiple Monitors Function ........................123

Connecting an External Microphone .........................125

Connecting a USB Device .........................................126

Customizing Your VAIO Computer..................................128

Selecting Performance Modes ..................................129

Setting the Password.................................................132

Using Intel(R) VT .......................................................139

Using the VAIO Control Center .................................140

Using the VAIO Power Management.........................141

Changing the Display Language ...............................142

n N

Upgrading Your VAIO Computer .................................... 143

Adding and Removing Memory................................. 144

Precautions..................................................................... 150

Safety Information ..................................................... 151

Care and Maintenance Information........................... 154

Handling Your Computer........................................... 155

Handling the LCD Screen ......................................... 157

Using the Power Source ........................................... 158

Handling the Built-in Camera .................................... 159

Handling Discs .......................................................... 160

Using the Battery Pack.............................................. 161

Handling "Memory Stick"........................................... 162

Handling the Built-in Storage Device ........................ 163

Using Fingerprint Authentication ............................... 164

Using the TPM .......................................................... 165

Troubleshooting .............................................................. 167

Computer Operations................................................ 169

System Update / Security.......................................... 175

Recovery ................................................................... 177

Battery Pack.............................................................. 180

Built-in Camera ......................................................... 183

Networking (LAN/Wireless LAN) ............................... 185

Wireless WAN ........................................................... 189

Bluetooth Technology ............................................... 190

Optical Discs..............................................................194

Display.......................................................................199

Printing ......................................................................203

Microphone................................................................204

Speakers ...................................................................205

Touch Pad .................................................................207

Keyboard ...................................................................208

Floppy Disks ..............................................................209

Audio/Video ...............................................................210

"Memory Stick" ..........................................................212

Peripherals ................................................................213

Port Replicator...........................................................214

Trademarks .....................................................................215

Notice ..............................................................................217

n N

Before Use >

Before Use

Congratulations on your purchase of this Sony VAIO® computer and welcome to the on-screen User Guide. Sony has

combined leading-edge technology in audio, video, computing, and communications to provide you with a state-of-the-art

computing experience.

External views illustrated in this manual may look slightly different from those of your computer.

How to find specifications

Some features, options, and supplied items may not be available on your computer.

To find out about the configuration of your computer, see the Specifications (supplied with your computer).

n N

Before Use >

Finding More about Your VAIO Computer

This section provides support information about your VAIO computer.

1. Printed Documentation

❑Quick Start Guide — An overview of components connection, set-up information, etc.

❑Specifications — The hardware configurations of your VAIO computer.

❑Recovery, Backup and Troubleshooting Guide

❑Safety Regulations

✍

Before activating the wireless functions such as the wireless LAN and Bluetooth technology, read the Safety Regulations carefully.

n N

Before Use >

Finding More about Your VAIO Computer

2. On-screen Documentation

❑VAIO Manual — General information and technical assistance for your VAIO computer.

To access VAIO Manual, double-click VAIO Manual on the desktop.

❑Windows Help and Support — A comprehensive resource for practical advice, tutorials, and demonstrations to help you

learn to use your computer.

To access Windows Help and Support, click Start and Help and Support, or press and hold the Microsoft Windows

key and press the F1 key.

n N

Before Use >

Finding More about Your VAIO Computer

3. Support Web Sites

❑Sony online support web site

The Sony online support web site provides instant access to information on commonly encountered problems:

http://www.sony-asia.com/support/vaio/onlinesupport

❑Online registration

You can register your computer online at the following URL:

http://www.sony-asia.com/support/vaio/registration

❑Contact information

You can contact us at the following URL:

http://www.sony-asia.com/support/vaio/contactus

❑For other Sony products, visit the web site at http://www.sony-asia.com/ .

n N

Before Use >

Ergonomic Considerations

You will be using your computer as a portable device in a variety of environments. Whenever possible, you should attempt

to take account of the following ergonomic considerations for both stationary and portable environments:

❑Position of your computer – Place the computer directly in front of you. Keep your forearms horizontal, with your wrists

in a neutral, comfortable position while using the keyboard or the pointing device. Let your upper arms hang naturally at

your sides. Take frequent breaks while using your computer. Excessive use of the computer may strain eyes, muscles, or

tendons.

❑Furniture and posture – Sit in a chair with good back support. Adjust the level of the chair so your feet are flat on the

floor. A footrest may make you more comfortable. Sit in a relaxed, upright posture and avoid slouching forward or leaning

far backwards.

n N

Getting Started >

Getting Started

This section describes how to get started with using your VAIO computer.

❑Locating Controls and Ports (page 11)

❑About the Indicator Lights (page 17)

❑Connecting a Power Source (page 18)

❑Using the Battery Pack (page 20)

❑Shutting Down Your Computer Safely (page 27)

❑Using the Power Saving Modes (page 28)

❑Keeping Your Computer in Optimum Condition (page 30)

n N

Getting Started >

Locating Controls and Ports

Take a moment to identify the controls and ports shown on the following pages.

The appearance of your computer may be different from those illustrated in this manual due to variations in specifications.

Front

ALCD screen (page 157)

BKeyboard (page 33)

CBuilt-in MOTION EYE camera (page 38)

DBuilt-in MOTION EYE camera indicator (page 17)

EBuilt-in speakers (stereo)

FAmbient light sensor (page 35), (page 201)

Measures ambient light intensity for automatically adjusting the

LCD brightness to an optimum level.

GNum lock indicator (page 17)

HCaps lock indicator (page 17)

IScroll lock indicator (page 17)

JWIRELESS indicator (page 17)

KCharge indicator (page 17)

LDisc drive indicator (page 17)

MTouch pad (page 36)

NLeft button (page 36)

OFingerprint sensor* (page 79)

PRight button (page 36)

* On selected models only.

n N

Getting Started >

Locating Controls and Ports

AASSIST button (page 37)

BWindow arrangement button (page 37)

CVAIO button (page 37)

DDrive eject button*1 (page 37), (page 39)

EPresentation button*2 (page 37)

FSPEED mode indicator (page 17), (page 129)

GPerformance selector switch (page 129)

HAUTO mode indicator (page 17), (page 129)

ISTAMINA mode indicator (page 17), (page 129)

J"Memory Stick Duo" slot*3 (page 47)

KMedia Access indicator (page 17)

LSD memory card slot (page 58)

MWIRELESS switch (page 64), (page 69), (page 73)

NBuilt-in microphone (monaural)

OHeadphones jack (page 114) (page 97),

PMicrophone jack (page 125)

*1 On models with the built-in optical disc drive.

*2 On models without the built-in optical disc drive.

*3 Your computer supports only Duo-size "Memory Stick".

n N

Getting Started >

Locating Controls and Ports

Back

ABattery connector (page 20)

BSIM card slot* (page 69)

* On selected models only.

n N

Getting Started >

Locating Controls and Ports

Right

AUSB port*1 (page 126)

BOptical disc drive*2 (page 39)

CManual eject hole*2 (page 194)

DMonitor port*3 (page 116)

EPower button/Power indicator (page 17)

*1 Compliant with the USB 2.0 standard and supports high-/full-/low- speeds.

*2 On selected models only.

*3 Not accessible when your computer is attached to the port replicator.

n N

Getting Started >

Locating Controls and Ports

Left

ADC IN port (page 18)

BAir vent

CSecurity slot

DNetwork (LAN) port*1 (page 63)

EHDMI output port*2 (page 119)

FUSB ports*3 (page 126)

GExpressCard/34 slot (page 54)

*1 Not accessible when your computer is attached to the port replicator.

*2 There may be no sound from an output device connected to the HDMI

output port for the first few seconds after playback starts. This does not

indicate a malfunction.

*3 Compliant with the USB 2.0 standard and support high-/full-/low- speeds.

n N

Getting Started >

Locating Controls and Ports

Bottom

AAir vents

BPort replicator connector cover (page 105)

CMemory module compartment cover (page 144)

n N

Getting Started >

About the Indicator Lights

Your computer is equipped with the following indicator lights:

Indicator Functions

Power 1Illuminates in green while the computer is in Normal mode, blinks slowly in orange while the computer is in Sleep

mode, and turns off when the computer is turned off or enters Hibernate mode.

Charge Illuminates while the battery pack is charging. See Charging the Battery Pack (page 24) for more information.

Built-in MOTION EYE camera Illuminates while the built-in camera is in use.

Media Access Illuminates while data access to a memory card, such as "Memory Stick" and an SD memory card, is in

progress. (Do not place the computer into Sleep mode or turn it off while this indicator light is lit.) When the

indicator light is unlit, the memory card is not in use.

AUTO AUTO mode Illuminates while the computer is in mode to provide optimum performance.

STAMINA mode Illuminates while the computer is in STAMINA mode to conserve battery power.

SPEED mode Illuminates while the computer is in SPEED mode to provide faster performance.

Disc drive Illuminates while data access to the built-in storage device or the optical disc drive

* is in progress. Do not place

the computer into Sleep mode or turn it off while this indicator light is lit.

Num lock Press the Num Lk key to activate the numeric keypad. Press it a second time to deactivate the numeric keypad.

The numeric keypad is not active when the indicator light is unlit.

Caps lock Press the Caps Lock key to type letters in uppercase. Letters appear in lowercase if you press the Shift key

while the indicator light is lit. Press the key a second time to turn off the indicator light. Normal typing resumes

when the Caps lock indicator light is turned off.

Scroll lock Press the Fn+Scr Lk keys to change how you scroll the display. Normal scrolling resumes when the Scroll lock

indicator light is turned off. The Scr Lk key functions differently depending on the program you are using and

does not work with all programs.

WIRELESS Illuminates while one or more wireless options are enabled.

* On selected models only.

n N

Getting Started >

Connecting a Power Source

You can use either an AC adapter or a rechargeable battery pack for supplying power to your computer. Before using the

computer for the first time, you need to connect an AC adapter to your computer.

Do not use your computer without installing the battery pack as it may cause the computer to malfunction.

Using the AC Adapter

While your computer is directly connected to an AC power source and has a battery pack installed, it uses power from the

AC outlet.

✍

Use only the supplied AC adapter for your computer.

To use the AC adapter

1Plug one end of the power cord (1) into the AC adapter (3).

2Plug the other end of the power cord into an AC outlet (2).

3Plug the cable from the AC adapter (3) into the DC IN port (4) on the computer.

The shape of the DC In plug varies depending on the AC adapter.

n N

Getting Started >

Connecting a Power Source

✍

To disconnect your computer completely from an AC power source, unplug the AC adapter from the AC outlet.

Make sure that an AC outlet is easily accessible.

If you do not intend to use your computer for an extended period of time, place the computer into Hibernate mode. See Using Hibernate Mode (page

29).

n N

Getting Started >

Using the Battery Pack

The battery pack is already installed on your computer at the time of delivery but is not fully charged.

Do not use your computer without installing the battery pack as it may cause the computer to malfunction.

Installing/Removing the Battery Pack

To install the battery pack

1Turn off the computer and close the LCD screen lid.

2Slide the battery LOCK switch (1) outward.

n N

Getting Started >

Using the Battery Pack

3Slide the battery pack diagonally into the battery compartment until the projection (2) on either side of the battery

compartment fits into the U-shaped cut (3) on either side of the battery pack.

n N

Getting Started >

Using the Battery Pack

4Push the battery pack down into the compartment until it clicks into place.

5Slide the battery LOCK switch inward to secure the battery pack on the computer.

n N

Getting Started >

Using the Battery Pack

Charging the Battery Pack

The battery pack supplied with your computer is not fully charged at the time of delivery.

To charge the battery pack

1Install the battery pack.

2Connect the computer to a power source with the AC adapter.

The charge indicator light is on while the battery pack is charging. When the battery pack charges close to the maximum

charge level you selected, the charge indicator turns off.

Charge the battery pack as described in this manual from your first battery charge.

Charge indicator status Meaning

Lit in orange The battery pack is charging.

Blinks along with the green

power indicator

The battery pack is running out of power.

(Normal mode)

Blinks along with the orange

power indicator

The battery pack is running out of power.

(Sleep mode)

Blinks fast in orange A battery error has occurred due to a failed battery

pack or an unlocked battery pack.

n N

Getting Started >

Using the Battery Pack

✍

Keep the battery pack in your computer while it is directly connected to an AC power source. The battery pack continues to charge while you are using

the computer.

When the battery pack is running out of power and both the charge and power indicator lights blink, you should either connect the AC adapter to

recharge the battery pack or shut down your computer and install a fully charged battery pack.

Your computer is supplied with a lithium ion battery pack and can be recharged any time. Charging a partially discharged battery pack does not affect

the life of battery.

While some software applications or peripheral devices are in use, your computer may not enter Hibernate mode even when the remaining battery life

becomes short. To avoid loss of data while the computer is running on the battery, you should save your data frequently and manually activate a power

management mode, such as Sleep or Hibernate.

If the battery pack runs out of power while the computer is in Sleep mode, you will lose all unsaved data. Going back to the previous work state is

impossible. To avoid loss of data, you should save your data frequently.

n N

Getting Started >

Using the Battery Pack

Checking the Battery Charge Capacity

The battery charge capacity gradually decreases as the number of battery charging increases or the duration of use of the

battery pack extends. To get the most out of the battery pack, check the battery charge capacity and change the battery

settings.

To check the battery charge capacity

1 Click Start, All Programs, and VAIO Control Center.

2 Click Power Management and Battery.

✍

Additionally, you can enable the battery care function to extend the life of the battery pack.

Extending the Battery Life

When your computer is running on battery power, you can extend the battery life using the following methods.

❑Decrease the LCD brightness of your computer screen.

❑Use the power saving mode. See Using the Power Saving Modes (page 28) for more information.

❑Change the power saving settings on the Power Options. See Using the VAIO Power Management (page 141) for more

information.

❑Set the wallpaper in Long Battery Life Wallpaper Setting as your desktop background with the VAIO Control Center.

n N

Getting Started >

Using the Power Saving Modes

Using Sleep Mode

To activate Sleep mode

Click Start, the arrow next to the Shut down button, and Sleep.

To return to Normal mode

❑Press any key.

❑Press the power button on your computer.

If you press and hold the power button for more than four seconds, your computer will turn off automatically. You will lose all unsaved data.

Using Hibernate Mode

To activate Hibernate mode

Press the Fn F12+ keys.

Alternatively, you can click Start, the arrow next to the Shut down button, and Hibernate.

Do not move your computer before its power indicator light turns off.

To return to Normal mode

Press the power button.

If you press and hold the power button for more than four seconds, your computer will turn off automatically.

n N

Getting Started >

Keeping Your Computer in Optimum Condition

Updating Your Computer

Be sure to update your VAIO computer with the following software applications for enhancing your computer's efficiency,

security, and functionality.

The VAIO Update automatically notifies you of new updates available on the Internet, and downloads and installs them on

the computer.

❑Windows Update

Click Start, All Programs, and Windows Update and then follow the on-screen instructions.

❑VAIO Update 5

Click Start, All Programs, and VAIO Update 5 and then follow the on-screen instructions.

Your computer must be connected to the Internet to download the updates.

n N

Getting Started >

Keeping Your Computer in Optimum Condition

Using the VAIO Care

With the VAIO Care, you can regularly conduct performance checks and tune-ups on your computer to keep it running at an

optimum level. Launch the VAIO Care whenever a problem is found on your computer. The VAIO Care will provide

appropriate measures to solve the problem.

To launch the VAIO Care

❑On models with the ASSIST button

Press the ASSIST button while your computer is on.

❑On models without the ASSIST button

Click Start, All Programs, VAIO Care, and VAIO Care.

Do not press the ASSIST button while the computer is in Hibernate mode.

✍

See the help file included with the VAIO Care for more information.

On models with the ASSIST button, pressing the ASSIST button while the computer is off launches the VAIO Care Rescue. The VAIO Care Rescue can

be used to recover your computer in case of emergency, for example, when the Windows does not start.

n N

Using Your VAIO Computer >

Using Your VAIO Computer

This section describes how to get the most out of using your VAIO computer.

❑Using the Keyboard (page 33)

❑Using the Touch Pad (page 36)

❑Using Special-function Buttons (page 37)

❑Using the Built-in Camera (page 38)

❑Using the Optical Disc Drive (page 39)

❑Using "Memory Stick" (page 47)

❑Using Other Modules / Memory Cards (page 54)

❑Using the Internet (page 62)

❑Using the Network (LAN) (page 63)

❑Using the Wireless LAN (page 64)

❑Using the Wireless WAN (page 69)

❑Using the Bluetooth Function (page 73)

❑Using Fingerprint Authentication (page 79)

❑Using the TPM (page 86)

n N

Using Your VAIO Computer >

Using the Keyboard

Fn + / (F9/F10): zooming Changes the size of an image or a document displayed on some software.

To make the view look smaller and further away (zoom out), press the Fn+F9 keys.

To make the view look bigger and closer (zoom in), press the Fn+F10 keys.

See the help file included with the VAIO Control Center for more information.

Fn + (F12): hibernation Provides the lowest level of power consumption. When you execute this command, the states

of the system and the connected peripheral devices are saved to the built-in storage device and

the system power is turned off. To return the system to its original state, use the power button

to turn on the power.

For details on power management, see Using the Power Saving Modes (page 28).

Combination/Feature Function

n N

Using Your VAIO Computer >

Using the Keyboard

Changing the Backlit Keyboard Settings

Some features and options may not be available on your computer.

If your computer is equipped with a backlit keyboard, you can set the keyboard light to automatically turn on and off according

to ambient light intensity.

Additionally, you can set a time period to turn off the keyboard backlight after inactivity of keyboard operations.

To change the backlit keyboard settings

1 Click Start, All Programs, and VAIO Control Center.

2 Click Keyboard and Mouse and Backlit KB.

✍

Ambient light intensity is measured by the ambient light sensor. Blocking the ambient light sensor may turn on the keyboard backlight.

n N

Using Your VAIO Computer >

Using Special-function Buttons

Your computer is equipped with special buttons to help you use specific functions of the computer.

Some features and options in this section may not be available on your computer.

See the specifications to find out about the configuration of your computer.

Special-function button Functions

ASSIST button

Launches the VAIO Care while the computer is on.

While the computer is off, the ASSIST button launches the VAIO Care Rescue.

Do not press the ASSIST button while the computer is in Hibernate mode.

Window arrangement button

By default, the window arrangement button shows all open windows by resizing the windows so that they all

fit on the desktop. To resume the previous window state, press this button once again.

You can change the default assignment with the VAIO Control Center.

VAIO button

Launches the Media Gallery or turns the volume on and off, depending on your model.

Drive eject button *1 Ejects the optical disc drive tray.

Presentation button *2

Executes the task that is assigned to the button by default.

You can change the default assignment with the VAIO Control Center.

*1 On models with a built-in optical disc drive.

*2 On models without a built-in optical disc drive.

n N

Using Your VAIO Computer >

Using the Built-in Camera

Your computer is equipped with a built-in MOTION EYE camera.

With the appropriate image capture software, you can perform the following operations:

❑Capture still images and movies

❑Sense and capture object movements for monitoring purposes

❑Edit captured data

✍

Turning on the computer activates the built-in camera.

Video calls are possible with the appropriate software.

Launching or exiting your instant messaging or video editing software does not activate or deactivate the built-in camera.

Do not place your computer into Sleep or Hibernate mode while you are using the built-in camera.

To use the image capture software

1 Click Start, All Programs, ArcSoft WebCam Companion 3, and WebCam Companion 3.

2 Click your desired icon in the main window.

For detailed information on how to use the software, see the help file included with the software.

✍

When capturing an image or a movie in a dark place, click the Capture icon in the main window, and then click the WebCam Settings icon and select

the low light or low light compensation option in the properties window.

n N

Using Your VAIO Computer >

Using the Optical Disc Drive

Your computer may be equipped with a built-in optical disc drive.

Some features and options in this section may not be available on your computer.

See the specifications to find out about the configuration of your computer.

To insert a disc

1 Turn on the computer.

2 Press the drive eject button (1) to open the drive.

The drive tray slides out.

3 Place a disc in the middle of the drive tray with the label side facing upward and gently push it down until the disc clicks

into place.

Do not exert pressure on the drive tray. Be sure to hold the bottom of the drive tray when placing/removing a disc onto/from the tray.

n N

Using Your VAIO Computer >

Using the Optical Disc Drive

4 Close the drive tray by pushing it in gently.

Do not remove the optical disc while your computer is in a power saving mode (Sleep or Hibernate). Be sure to bring the computer back into Normal

mode before removing the disc.

n N

Using Your VAIO Computer >

Using the Optical Disc Drive

This unit is designed to playback discs that conform to the Compact Disc (CD) standard. DualDiscs and some music discs encoded with copyright

protection technologies do not conform to the Compact Disc (CD) standard. Therefore, these discs may not be compatible with this unit.

When you buy pre-recorded or blank discs for use with your VAIO computer, be sure to read the notices on the disc package carefully to check both

playback and recording compatibility with your computer's optical disc drives. Sony does NOT guarantee the compatibility of VAIO optical disc drives

with discs that are not compliant with the official "CD," "DVD," or "Blu-ray Disc" standard. USING NON-COMPLIANT DISCS CAN CAUSE FATAL DA

TO YOUR VAIO COMPUTER OR CREATE SOFTWARE CONFLICTS AND CAUSE SYSTEM HANGING.

For inquiries about disc formats, contact the individual publisher of the pre-recorded disc or the manufacturer of the recordable disc.

✍

8 cm disc writing is not supported.

To play copyright protected Blu-ray Disc media continually, update the AACS key. The AACS key update requires Internet access.

As with other optical media devices, circumstances may limit compatibility or prevent Blu-ray Disc media playback. VAIO computers may not support

movie playback on packaged media recorded in AVC or VC1 formats at high bit rates.

Region settings are required for some contents of DVD and BD-ROM Disc media. If the region setting on the optical disc drive does not match the

region coding on the disc, playback is not possible.

Unless your external display is compliant with the High-bandwidth Digital Content Protection (HDCP) standard, you cannot play or view the contents

of copyright protected Blu-ray Disc media.

Some content may restrict video output to standard definition or prohibit analog video output. When you output video signals through digital

connections, such as an HDMI connection or a DVI connection, it is strongly recommended that a digital HDCP compliant environment be implemented

for optimum compatibility and viewing quality.

Exit all memory-resident utility software before playing or writing a disc as it may cause the computer to malfunction.

n N

Using Your VAIO Computer >

Using the Optical Disc Drive

Notes on Using the Optical Disc Drive

Notes on writing data to a disc

❑Only use circular discs. Do not use discs in any other shape (star, heart, card, etc.), as this may damage the optical disc

drive.

❑Do not strike or shake your computer while the optical disc drive is writing data to a disc.

❑Do not plug or unplug the power cord or the AC adapter while the optical disc drive is writing data to a disc.

❑Do not attach or disconnect your computer to or from the port replicator (optional) while the optical disc drive is writing

data to a disc.

Notes on playing discs

To achieve optimum performance of disc playback, you should follow these recommendations:

❑Some CD players and computer optical disc drives may not be able to play audio CDs created with the CD-R or CD-RW

media.

❑Some DVD players and computer optical disc drives may not be able to play DVDs created with the DVD+R DL, DVD-R

DL, DVD+R, DVD+RW, DVD-R, DVD-RW, or DVD-RAM media.

❑When your computer is equipped with a Blu-ray Disc drive, Blu-ray Disc playback is available on your computer. However,

the drive may not be able to play some Blu-ray Disc content, or the computer may become unstable during Blu-ray Disc

playback. To play content normally, download and install the latest updates for the WinDVD BD using the VAIO Update.

For information on how to use the VAIO Update, see Updating Your Computer (page 30).

❑Depending on system environment, you may find sound interruptions and/or dropped frames during AVC HD playback.

❑Do not place your computer into either of the power saving modes while your computer is playing a disc.

n N

Using Your VAIO Computer >

Using the Optical Disc Drive

Notes on region codes

Region code indicators are labeled on the discs or packages to indicate in which region and on what type of player you can

play the disc. If the region code indicates "all," you can play this disc in most regions of the world. If the region code for your

residence area is different from the label, you cannot play the disc on your computer.

To find out the region code for your residence area, see the following table.

Residence area Region code Residence area Region code Residence area Region code

Africa 5 Australia* 4 China 6

Europe 2 Hong Kong* 3 India* 5

Indonesia* 3 Japan* 2 Korea 3

Kuwait* 2 Malaysia* 3 New Zealand* 4

Philippines* 3 Russia 5 Saudi Arabia* 2

Singapore* 3 South Africa* 2 Taiwan 3

Thailand* 3 United Arab Emirates* 2 Vietnam 3

* A region code is not assigned to your computer's optical disc drive by default.

n N

Using Your VAIO Computer >

Using the Optical Disc Drive

If it is your first time to play a DVD video on your computer, follow these steps before inserting the disc:

1 Click Start and Computer.

2 Right-click the optical disc drive icon and select Properties.

3 Click the Hardware tab.

4 Select your optical disc drive from the All disk drives list and click Properties.

5 Click the DVD Region tab.

6 Select an appropriate region from the list and click OK.

You can change the region code only a limited number of times. When you have exceeded this number, the drive's region code is permanently assigned

and you will not be able to change it again. Reconfiguring your computer does not reset this count.

Any difficulties caused by changing the region code settings of the drive are not covered by the warranty.

If you change the region code while the WinDVD or the WinDVD BD is running, restart the software or eject the disc and re-insert it to make the new

setting effective.

n N

Using Your VAIO Computer >

Using the Optical Disc Drive

Playing Discs

To play a disc

1Insert a disc into the optical disc drive.

Connect the AC adapter to the computer and close all running software applications before playing a disc.

2If nothing appears on the desktop, click Start, All Programs, and your desired software to play the disc.

For instructions on how to use the software, see the help file included with the software.

Copying Files to Discs

To copy files to a disc

1Insert a recordable disc into the optical disc drive.

Connect the AC adapter to the computer and close all running software applications before copying files to a disc.

2If nothing appears on the desktop, click Start, All Programs, and your desired disc burning software to copy files to the

disc.

For instructions on how to use the software, see the help file included with the software.

n N

Using Your VAIO Computer >

Using "Memory Stick"

"Memory Stick" is a compact, portable, and versatile IC recording media especially designed for exchanging and sharing

digital data with compatible products, such as digital cameras, mobile phones, and other devices. Because it is removable,

it can be used for external data storage.

Before You Use "Memory Stick"

The "Memory Stick Duo" slot on your computer can accommodate the following sizes and types of media:

❑"Memory Stick Duo"

❑"Memory Stick PRO Duo"

❑"Memory Stick PRO-HG Duo"

Your computer supports only Duo-size "Memory stick", and does not support standard-size "Memory Stick".

For the latest information about "Memory Stick", visit [memorystick.com] at http://www.memorystick.com/en/.

n N

Using Your VAIO Computer >

Using "Memory Stick"

Before using "Memory Stick Micro" ("M2"), be sure to insert it into an "M2" Duo adaptor. If you insert the media directly into the "Memory Stick Duo"

slot without the adaptor, you may not be able to remove it from the slot.

n N

Using Your VAIO Computer >

Using "Memory Stick"

To remove "Memory Stick"

Do not remove "Memory Stick" while the Media Access indicator light is lit. If you do, you may lose data. Large volumes of data may take time to load,

so make sure the indicator light is unlit before removing "Memory Stick".

1Locate the "Memory Stick Duo" slot.

2Check that the Media Access indicator light is unlit.

3Push in "Memory Stick" toward the computer and release.

"Memory Stick" ejects.

4Pull "Memory Stick" out of the slot.

Be sure to remove "Memory Stick" gently, or it may pop out unexpectedly.

n N

Using Your VAIO Computer >

Using "Memory Stick"

Formatting "Memory Stick"

To format "Memory Stick"

"Memory Stick" is formatted by default and is ready for use.

If you want to reformat the media with your computer, follow these steps.

Be sure to use the device that is designed to format the media and supports "Memory Stick" when formatting the media.

Formatting "Memory Stick" erases the entire data stored on the media. Before formatting the media, make sure that it does not contain your valuable

data.

Do not remove "Memory Stick" from the slot while formatting. This could cause a malfunction.

1Locate the "Memory Stick Duo" slot.

2Carefully slide "Memory Stick" into the slot until it clicks into place.

3Click Start and Computer.

4Right-click the "Memory Stick" icon and select Format.

5Click Restore device defaults.

The size of the allocation unit and file system may change.

Do not select NTFS from the File system drop-down list as it may cause a malfunction.

✍

The formatting process will be completed more quickly if you select Quick Format in Format options.

n N

Using Your VAIO Computer >

Using "Memory Stick"

6Click Start.

7Follow the on-screen instructions.

It may take time to format "Memory Stick" depending on the media type.

n N

Using Your VAIO Computer >

Using "Memory Stick"

Notes on Using "Memory Stick"

❑Your computer has been tested and found compatible with Sony branded "Memory Stick" with capacity of up to 32 GB

that are available as of January 2010. However, not all "Memory Stick" are guaranteed of compatibility.

❑Be sure to hold "Memory Stick" with the arrow pointing in the correct direction as you insert it into the slot. To avoid

damaging your computer or the media, do not force "Memory Stick" into the slot if you cannot insert it smoothly.

❑Use care when inserting or removing "Memory Stick" from the slot. Do not force it in or out of the slot.

❑Inserting "Memory Stick" with multiple conversion adaptors is not guaranteed of compatibility.

❑"MagicGate" is the general name of the copyright protection technology developed by Sony. Use "Memory Stick" with the

"MagicGate" logo to take advantage of this technology.

❑Except for your personal use, it is against the copyright law to use any audio and/or image data you recorded without prior

consent from the respective copyright holders. Accordingly, "Memory Stick" with such copyrighted data can be used only

within the law.

❑Do not insert more than one "Memory Stick" into the slot. Improper insertion of the media may damage both your

computer and the media.

n N

Using Your VAIO Computer >

Using Other Modules / Memory Cards

Using the ExpressCard Module

Your computer is equipped with an ExpressCard/34 slot* for transferring data among digital cameras, camcorders, music

players, and other audio/video devices. This slot can only accommodate an ExpressCard/34 (34 mm wide) module*.

* Referred to as the ExpressCard slot and the ExpressCard module in this manual.

n N

Using Your VAIO Computer >

Using Other Modules / Memory Cards

✍

If the module does not go into the slot easily, remove it gently and verify you are inserting it in the proper direction.

Make sure you use the most recent driver software provided by the ExpressCard module manufacturer.

n N

Using Your VAIO Computer >

Using Other Modules / Memory Cards

Using the SD Memory Card

Your computer is equipped with an SD memory card slot. You can use this slot to transfer data among digital cameras,

camcorders, music players, and other audio/video devices.

Before you use the SD memory card

The SD memory card slot on your computer can accommodate the following memory cards:

❑SD memory card

❑SDHC memory card

For the latest information on compatible memory cards, see Finding More about Your VAIO Computer (page 5) to visit the

appropriate support web site.

n N

Using Your VAIO Computer >

Using Other Modules / Memory Cards

Notes on Using Memory Cards

General notes on using the memory card

❑Be sure to use memory cards that are compliant with the standards supported by your computer.

❑Be sure to hold the memory card with the arrow pointing in the correct direction as you insert it into the slot. To avoid

damaging your computer or the media, do not force the memory card into the slot if you cannot insert it smoothly.

❑Use care when inserting or removing the memory card from the slot. Do not force it in or out of the slot.

❑Do not remove the memory card while the media access indicator light is lit. If you do, you may lose data.

❑Do not attempt to insert a memory card or memory card adaptor of a different type into the memory card slot. An

incompatible memory card or memory card adaptor may cause difficulty in removing from the slot and can cause damage

to your computer.

Notes on using the SD memory card

❑Your computer has been tested and found compatible only with major memory cards available as of January 2010.

However, not all memory cards are guaranteed of compatibility.

❑SD memory cards with capacity of up to 2 GB and SDHC memory cards with capacity of up to 32 GB have been tested

and found compatible with your computer.

n N

Using Your VAIO Computer >

Using the Network (LAN)

You can connect your computer to 1000BASE-T/100BASE-TX/10BASE-T type networks with a LAN cable. Connect one end

of a LAN cable (not supplied) to the network (LAN) port on the computer or the optional port replicator and the other end to

your network. For detailed settings and devices required for LAN access, ask your network administrator.

The network (LAN) port on your computer is not accessible when the computer is attached to the optional port replicator.

✍

You can connect your computer to any network without changing the default settings.

Do not plug a telephone cable into the network (LAN) port on your computer.

If the network (LAN) port is connected to one of the telephone lines mentioned below, high electric current to the port may cause damage, overheating,

or fire.

- Home (intercom speakerphone) or business-use telephone lines (multi-line business telephone)

- Public telephone subscriber line

- Private branch exchange (PBX)

n N

Using Your VAIO Computer >

Using the Wireless LAN

The Wireless LAN (WLAN) allows your computer to connect to a network through a wireless connection.

The WLAN uses the following IEEE 802.11a/b/g/n standard, which specifies the type of technology used.

See the specifications to find out about the configuration of your computer.

WLAN standard Frequency band Remarks

IEEE 802.11a 5 GHz -

IEEE 802.11b/g 2.4 GHz The IEEE 802.11g standard provides higher-speed communications than the IEEE 802.11b

standard.

IEEE 802.11n 5 GHz/2.4 GHz On models compliant with the IEEE 802.11b/g/n standard, only the 2.4 GHz band can be used.

n N

Using Your VAIO Computer >

Using the Wireless LAN

Note on the data encryption

The WLAN standard includes the encryption methods: Wired Equivalent Privacy (WEP), which is a security protocol, Wi-Fi

Protected Access 2 (WPA2), and Wi-Fi Protected Access (WPA). Proposed jointly by the IEEE and Wi-Fi Alliance, both WPA2

and WPA are specifications of standards based on interoperable security enhancements that increase the level of data

protection and access control for existing Wi-Fi networks. WPA is designed to be forward compatible with the IEEE 802.11i

specification. It utilizes the enhanced data encryption Temporal Key Integrity Protocol (TKIP) in addition to user authentication

using 802.1X and Extensible Authentication Protocol (EAP). Data encryption protects the vulnerable wireless link between

clients and access points. Besides that, there are other typical LAN security mechanisms to ensure privacy, such as:

password protection, end-to-end encryption, virtual private networks, and authentication. WPA2, the second generation of

WPA, provides stronger data protection and network access control and is also designed to secure all versions of 802.11

devices, including 802.11b, 802.11a, 802.11g, and 802.11n standards, multi-band and multi-mode. In addition, based on the

ratified IEEE 802.11i standard, WPA2 provides government grade security by implementing the National Institute of

Standards and Technology (NIST) FIPS 140-2 compliant AES encryption algorithm and 802.1X-based authentication. WPA2

is backward compatible with WPA.

n N

Using Your VAIO Computer >

Using the Wireless LAN

Starting Wireless LAN Communications

You first need to establish wireless LAN communications between your computer and an access point (not supplied). See

Windows Help and Support for more information.

For details on how to select the channel that will be used by the access point, see the manual that came with your access point.

To start wireless LAN communications

1 Make sure an access point is set up.

See the manual that came with your access point for more information.

2 Turn on the WIRELESS switch.

3 Click the VAIO Smart Network icon on the taskbar.

4 Click the switch next to your desired wireless option(s) to toggle it to On in the VAIO Smart Network window.

Make sure the WIRELESS indicator light turns on.

5 GHz band wireless LAN communications, available on selected models only, are disabled by default. To enable 5 GHz band communication, you need

to select the option to use the 5 GHz band or both the 2.4 GHz and 5 GHz bands from the drop-down list for Wireless LAN Settings in the VAIO Smart

Network settings window.

5 Click or on the taskbar.

6 Select the desired access point and click Connect.

✍

For WPA-PSK or WPA2-PSK authentication, you must enter a passphrase. The passphrase is case sensitive and must be a text string between 8 and

63 characters in length or a hexadecimal string of 64 characters.

n N

Using Your VAIO Computer >

Using the Wireless LAN

Stopping Wireless LAN Communications

To stop wireless LAN communications

Click the switch next to Wireless LAN to toggle it to Off in the VAIO Smart Network window.

Turning off the wireless LAN function while accessing remote documents, files, or resources may result in data loss.

n N

Using Your VAIO Computer >

Using the Wireless WAN

Using the wireless WAN (WWAN) allows your computer to connect to the Internet through the wireless network wherever

there is the mobile phone coverage.

The WWAN may not be available in some countries or regions.

Some features and options in this section may not be available on your computer.

See the specifications to find out about the configuration of your computer.

n N

Using Your VAIO Computer >

Using the Wireless WAN

4 Insert the SIM card into the SIM card slot with its printed circuit side down.

Do not touch the printed circuit on the SIM card. Be sure to hold your computer firmly before inserting or removing the card.

Do not damage the SIM card in any way, either by bending or exerting pressure on the card.

5 Reinstall the battery pack.

Make sure the battery pack is installed properly.

n N

Using Your VAIO Computer >

Using the Bluetooth Function

Stopping Bluetooth Communications

To stop Bluetooth communications

1Turn off the Bluetooth device that is communicating with your computer.

2Click the switch next to Bluetooth to toggle it to Off in the VAIO Smart Network window.

n N

Using Your VAIO Computer >

Using Fingerprint Authentication

Your computer may be equipped with a fingerprint sensor to provide you with additional convenience.

Some features and options in this section may not be available on your computer.

See the specifications to find out about the configuration of your computer.

Once you have registered your fingerprint(s), the fingerprint authentication function offers:

❑A substitute for password entry

❑Logging onto Windows (page 84)

If you have registered your fingerprints for your user account, you can substitute fingerprint authentication for

password entry when logging onto Windows.

❑Power-on Security feature (page 84)

If you have set the power-on password (page 133), you can substitute fingerprint authentication for password entry

when starting your computer.

❑Password Bank for quick web site access

Once you have registered your user information (user accounts, passwords, etc.) for web sites in the Password Bank,

you can substitute fingerprint authentication for entering information required to access the password-protected web sites.

For detailed information, see the help file included with the Protector Suite.

You may not be able to use the Password Bank feature depending on the web site you access.

n N

Using Your VAIO Computer >

Using Fingerprint Authentication

❑Archive encryption

❑File Safe feature to encrypt/decrypt data

With the File Safe feature, you can create an encrypted archive to include a file and/or folder for protection against

unauthorized access. The encrypted archive can be decrypted or unlocked for included file/folder access by swiping

your finger across the fingerprint sensor or entering the backup password you specified for encryption.

❑Personal Safe feature

With the Personal Safe feature, you can encrypt contents of any protected folder on the desktop or the built-in storage

device. The encrypted folder will be hidden from other users sharing your computer.

❑Application launcher function for quick application access

The application launcher feature is available on your computer for launching your preferred application (executable file)

that is assigned to one of your fingers with a registered fingerprint. Once you have assigned an application to your finger,

you can launch the assigned application simply by swiping the finger across the fingerprint sensor.

❑Strong Password Generator function

The Strong Password Generator function allows you to enhance computer security by generating a strong password

resistant to dictionary attacks. The generated password can be registered in the Password Bank.

n N

Using Your VAIO Computer >

Using Fingerprint Authentication

Logging Onto Your System

To use the fingerprint authentication function in place of a password entry to log onto your system, you need to set the power-

on and Windows passwords and configure your computer for fingerprint authentication.

For setting the power-on and Windows passwords, see Setting the Password (page 132).

For detailed information, see the help file included with the Protector Suite.

Logging onto Windows

If you have registered your fingerprints for your user account, you can substitute fingerprint authentication for Windows

password entry. To log onto Windows, swipe the registered finger across the fingerprint sensor when the Windows log-on

screen appears.

Power-on Security feature

If you have set the power-on password (page 133), you can substitute fingerprint authentication for password entry when

starting your computer.

Specyfikacje produktu

Marka:	Sony
Kategoria:	laptop
Model:	Vaio VPCZ126GF

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Sony Vaio VPCZ126GF, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje laptop Sony

Sony Vaio VGN-FS215E Instrukcja

14 Października 2024

Sony Vaio VPCF120FD Instrukcja

13 Października 2024

Sony Vaio VGN-C270CE Instrukcja

11 Października 2024

Sony Vaio VGN-SR56GG Instrukcja

11 Października 2024

Sony Vaio SVE14A15FBP Instrukcja

6 Października 2024

Sony Vaio VGN-Z890S3 Instrukcja

2 Października 2024

Sony Vaio SVE14123CBW Instrukcja

1 Października 2024

Sony Vaio VGN-N250QE Instrukcja

28 Września 2024

Sony Vaio VPCW121 Instrukcja

21 Września 2024

Sony PCG-GRX15U24P Instrukcja

19 Września 2024

Instrukcje laptop

Najnowsze instrukcje dla laptop

Dell Latitude E7240 Instrukcja

3 Kwietnia 2025

Ergotron StyleView Instrukcja

2 Kwietnia 2025

Acer Chromebook Plus 515 Instrukcja

28 Marca 2025

Lenovo IdeaPad 3 17ALC6 Instrukcja

28 Marca 2025

Lenovo IdeaPad 1 15ALC7 Instrukcja

26 Marca 2025

Dell Inspiron 1501 Instrukcja

13 Marca 2025

ECS H42IA1 Instrukcja

7 Marca 2025

HP EliteBook X Flip G1i Instrukcja

4 Marca 2025

Everex StepNote NM3900W Instrukcja

1 Marca 2025

Dell Latitude 7320 Detachable Instrukcja

26 Lutego 2025
