N
Operating Instructions - Hardware Guide
Personal Computer
VGN-Z Series
2
n N
Contents
Before Use.......................................................................... 4
Finding More about Your VAIO Computer .................... 5
Ergonomic Considerations ............................................ 7
Getting Started.................................................................... 9
Locating Controls and Ports........................................ 10
About the Indicator Lights ........................................... 16
Connecting a Power Source ....................................... 17
Using the Battery Pack................................................ 19
Shutting Down Your Computer Safely ........................ 25
Using the Power Saving Modes .................................. 26
Updating Your Computer ............................................ 28
Using Your VAIO Computer.............................................. 29
Using the Keyboard..................................................... 30
Using the Touch Pad................................................... 32
Using Special-function Buttons ................................... 33
Using the Built-in Camera ........................................... 34
Using the Optical Disc Drive ....................................... 35
Using "Memory Stick".................................................. 43
Using Other Modules / Memory Cards........................ 49
Using the Internet........................................................ 55
Using the Network (LAN) ............................................ 57
Using the Wireless LAN .............................................. 58
Using the Bluetooth Function ......................................65
Using Fingerprint Authentication .................................70
Using the TPM.............................................................77
Using Peripheral Devices..................................................84
Connecting a Docking Station .....................................85
Connecting External Speakers or Headphones ..........93
Connecting an External Display ..................................94
Selecting Display Modes ...........................................101
Using the Multiple Monitors Function ........................102
Connecting an External Microphone .........................104
Connecting a USB Device .........................................105
Connecting an i.LINK Device.....................................107
Customizing Your VAIO Computer..................................109
Selecting Performance Modes ..................................110
Setting the Password.................................................112
Using Intel® VT .........................................................124
Using the VAIO Control Center .................................125
Using the VAIO Power Management.........................127
Configuring Your Modem...........................................128
Protecting the Hard Disk............................................129
Upgrading Your VAIO Computer.....................................130
Adding and Removing Memory .................................131
3
n N
Precautions..................................................................... 137
Safety Information ..................................................... 138
Care and Maintenance Information........................... 141
Handling Your Computer........................................... 142
Handling the LCD Screen ......................................... 144
Using the Power Source ........................................... 145
Handling the Built-in Camera .................................... 146
Handling Discs .......................................................... 147
Using the Battery Pack.............................................. 148
Handling "Memory Stick"........................................... 149
Handling the Built-in Storage Device ........................ 150
Using Fingerprint Authentication ............................... 151
Using the TPM .......................................................... 152
Troubleshooting .............................................................. 153
Computer .................................................................. 155
System Security ........................................................ 164
Battery....................................................................... 165
Built-in Camera ......................................................... 167
Internet ...................................................................... 169
Networking ................................................................ 171
Bluetooth Technology ............................................... 176
Optical Discs ............................................................. 180
Display ...................................................................... 184
Printing ...................................................................... 188
Microphone................................................................189
Speakers ...................................................................190
Touch Pad .................................................................191
Keyboard ...................................................................192
Floppy Disks ..............................................................193
Audio/Video ...............................................................194
"Memory Stick" ..........................................................197
Peripherals ................................................................198
Docking Station .........................................................199
Trademarks .....................................................................200
Notice ..............................................................................202
4
n N
Before Use >
Before Use
Congratulations on your purchase of this Sony VAIO® computer, and welcome to the on-screen Hardware Guide. Sony has
combined leading-edge technology in audio, video, computing, and communications to provide a state-of-the-art personal
computing experience.
!
External views illustrated in this manual may look slightly different from those of your computer.
How to find specifications
Some features, options, and supplied items may not be available on your computer.
To find out about the configuration of your computer, see the Specifications (supplied with your computer).
5
n N
Before Use >
Finding More about Your VAIO Computer
Finding More about Your VAIO Computer
This section provides support information about your VAIO computer.
1. Printed Documentation
❑Quick Start Guide — An overview of components connection, set-up information, etc.
❑Specifications — The hardware configurations of your VAIO computer.
❑Recovery and Troubleshooting Guide
❑Safety Regulations
2. On-screen Documentation
❑VAIO Manual — General information and technical assistance for your VAIO computer.
To access VAIO Manual VAIO Manual, double-click on the desktop.
❑Windows Help and Support — A comprehensive resource for practical advice, tutorials, and demonstrations to help you
learn to use your computer.
To access Windows Help and Support, click Start and Help and Support, or press and hold the Microsoft Windows
key and press the F1 key.
6
n N
Before Use >
Finding More about Your VAIO Computer
3. Support Web Sites
If you have any problem with the computer, you can visit the following VAIO online web sites for troubleshooting:
❑http://www.sony-asia.com/support/vaio/ (English)
❑http://scs.sony.co.kr/ (Korean)
❑http://service.sony.com.tw/ (Traditional Chinese)
Before contacting VAIO Helpdesk by telephone, try to solve the problem by reading the supplied documentation and visiting
other Sony web sites.
❑For other Sony products, visit the web site at http://www.sony.net .
❑For available optional accessories, visit the following web sites:
❑http://vaio-online.sony.com/ (English)
❑http://vaio-online.sony.co.kr/ (Korean)
❑http://www.sonystyle.com.tw/vaio/ (Traditional Chinese)
7
n N
Before Use >
Ergonomic Considerations
Ergonomic Considerations
You will be using your computer as a portable device in a variety of environments. Whenever possible, you should attempt
to take account of the following ergonomic considerations for both stationary and portable environments:
❑Position of your computer – Place the computer directly in front of you. Keep your forearms horizontal, with your wrists
in a neutral, comfortable position while using the keyboard or the pointing device. Let your upper arms hang naturally at
your sides. Take frequent breaks while using your computer. Excessive use of the computer may strain eyes, muscles, or
tendons.
❑Furniture and posture – Sit in a chair with good back support. Adjust the level of the chair so your feet are flat on the
floor. A footrest may make you more comfortable. Sit in a relaxed, upright posture and avoid slouching forward or leaning
far backwards.
8
n N
Before Use >
Ergonomic Considerations
❑Viewing angle of the computer's display – Use the display's tilting feature to find the best position. You can reduce eye
strain and muscle fatigue by adjusting the tilt of the display to the proper position. Adjust the brightness level of the display
as well.
❑Lighting – Choose a location where windows and lights do not cause glare and reflection on the display. Use indirect
lighting to avoid bright spots on the display. Proper lighting adds to your comfort and work efficiency.
❑Positioning an external display – When using an external display, set the display at a comfortable viewing distance.
Make sure the display screen is at eye level or slightly lower when you are sitting in front of the monitor.
9
n N
Getting Started >
Getting Started
This section describes how to get started using your VAIO computer.
❑Locating Controls and Ports (page 10)
❑About the Indicator Lights (page 16)
❑Connecting a Power Source (page 17)
❑Using the Battery Pack (page 19)
❑Shutting Down Your Computer Safely (page 25)
❑Using the Power Saving Modes (page 26)
❑Updating Your Computer (page 28)
10
n N
Getting Started >
Locating Controls and Ports
Locating Controls and Ports
Take a moment to identify the controls and ports shown on the following pages.
!
The appearance of your computer may be different from those illustrated in this manual due to variations in specifications. It may also vary in some
countries or areas.
Front
ABuilt-in MOTION EYE camera (page 34)
BBuilt-in MOTION EYE camera indicator (page 16)
CNum lock indicator (page 16)
DCaps lock indicator (page 16)
EScroll lock indicator (page 16)
FLCD screen (page 144)
GBuilt-in speakers (stereo)
HKeyboard (page 30)
ITouch pad (page 32)
JLeft button (page 32)
KFingerprint sensor (page 70)
LRight button (page 32)
11
n N
Getting Started >
Locating Controls and Ports
ASTAMINA mode indicator (page 16)
BPerformance selector switch (page 110)
CSPEED mode indicator (page 16)
DS1/S2 buttons (page 33)
EDrive eject button (page 33)
FCharge indicator (page 16)
GDisc drive indicator (page 16)
HMedia Access indicator (page 16)
IWIRELESS indicator (page 16)
JSD memory card slot (page 51)
K"Memory Stick" slot* (page 43)
LWIRELESS switch (page 58), (page 65)
MBuilt-in microphone (monaural)
* Your computer supports both standard-size "Memory Stick" and Duo-size
"Memory Stick".
12
n N
Getting Started >
Locating Controls and Ports
Back
ABattery connector (page 19)
14
n N
Getting Started >
Locating Controls and Ports
Left
ADC IN port (page 17)
BNetwork (LAN) port (page 57)
CAir vent
DExpressCard/34 slot (page 49)
ESecurity slot
FModem port (page 55)
GHi-Speed USB (USB 2.0) port* (page 105)
Hi.LINK 4-pin (S400) port (page 107)
IMicrophone jack (page 104)
JHeadphones jack (page 93)
* Supports high-/full-/low- speeds.
15
n N
Getting Started >
Locating Controls and Ports
Bottom
ADocking station connector (page 87)
BAir vents
CMemory module compartment cover (page 131)
16
n N
Getting Started >
About the Indicator Lights
About the Indicator Lights
Your computer is equipped with the following indicator lights:
Indicator Functions
Power 1Illuminates in green while the computer is on, blinks slowly in orange while the computer is in Sleep mode, and
goes out when the computer is turned off or enters Hibernate mode.
Charge Illuminates while the battery pack is charging. See Charging the Battery Pack (page 22) for more information.
Media Access Illuminates while data access to a memory card, such as "Memory Stick" and an SD memory card, is in
progress. (Do not place the computer into Sleep mode or turn it off while this indicator light is lit.) When the
indicator light is unlit, the memory card is not in use.
Built-in MOTION EYE camera Illuminates while the built-in camera is in use.
STAMINA mode Illuminates while the computer is in STAMINA mode to conserve battery power.
SPEED mode Illuminates while the computer is in SPEED mode to provide faster performance.
Optical disc drive Illuminates while data access to the optical disc drive is in progress. When the indicator light is unlit, the optical
disc media is not in use.
Disc drive Illuminates while data access to the built-in storage device or the optical disc drive is in progress. Do not place
the computer into Sleep mode or turn it off while this indicator light is lit.
Num lock Press the Num Lk key to activate the numeric keypad. Press it a second time to deactivate the numeric keypad.
The numeric keypad is not active when the indicator light is unlit.
Caps lock Press the Caps Lock key to type letters in uppercase. Letters appear in lowercase if you press the Shift key
while the indicator light is lit. Press the key a second time to turn off the indicator light. Normal typing resumes
when the Caps lock indicator light is turned off.
Scroll lock Press the Fn+Scr Lk keys to change how you scroll the display. Normal scrolling resumes when the Scroll lock
indicator light is turned off. The Scr Lk key functions differently depending on the program you are using and
does not work with all programs.
WIRELESS Illuminates while one or more wireless options are enabled.
17
n N
Getting Started >
Connecting a Power Source
Connecting a Power Source
You can use either an AC adapter or a rechargeable battery pack for supplying power to your computer.
Using the AC Adapter
While your computer is directly connected to AC power and has a battery pack installed, it uses power from the AC outlet.
✍
Use only the supplied AC adapter for your computer.
To use the AC adapter
1Plug one end of the power cord (1) into the AC adapter (3).
2Plug the other end of the power cord into an AC outlet (2).
3Plug the cable from the AC adapter (3) into the DC IN port (4) on the computer or on the optional docking station.
!
The shape of the DC In plug varies depending on the AC adapter.
20
n N
Getting Started >
Using the Battery Pack
3Slide the battery pack diagonally into the battery compartment until the projection (2) on either side of the battery
compartment fits into the U-shaped cut (3) on either side of the battery pack.
4Push the battery pack down into the compartment until it clicks into place.
5Slide the battery LOCK switch outward to secure the battery pack on the computer.
21
n N
Getting Started >
Using the Battery Pack
To remove the battery pack
!
You may lose data if you remove the battery pack while your computer is on and not connected to the AC adapter or if you remove the battery pack
while the computer is in Sleep mode.
1Turn off the computer and close the LCD screen lid.
2Slide the battery LOCK switch (1) inward.
3Slide and hold the battery RELEASE latch (2) inward, put your fingertip underneath the tab (3) on the battery pack, and
lift the battery pack in the direction of the arrow, and then slide it away from the computer.
!
For your safety, it is highly recommended that you use genuine Sony rechargeable battery packs and AC adapters that meet the quality assurance
standards and supplied by Sony for your VAIO computer. Some VAIO computers may operate only with genuine Sony battery packs.
22
n N
Getting Started >
Using the Battery Pack
Charging the Battery Pack
The battery pack supplied with your computer is not fully charged at the time of delivery.
To charge the battery pack
1 Install the battery pack.
2 Connect the computer to a power source with the AC adapter.
The charge indicator light is on while the battery pack is charging. When the battery pack charges close to the maximum
charge level you selected with the battery charge functions, the charge indicator turns off.
!
Charge the battery pack as described in this manual from your first battery charge.
Charge indicator status Meaning
Lit in orange The battery pack is charging.
Blinks along with the green
power indicator
The battery pack is running out of power.
(Normal mode)
Blinks along with the orange
power indicator
The battery pack is running out of power.
(Sleep mode)
Blinks fast in orange A battery error has occurred due to a failed battery
pack or an unlocked battery pack.
23
n N
Getting Started >
Using the Battery Pack
✍
Keep the battery pack in your computer while it is directly connected to AC power. The battery pack continues to charge while you are using the
computer.
When the battery pack is running out of power and both the charge and power indicator lights blink, you should either connect the AC adapter to
recharge the battery pack or shut down your computer and install a fully charged battery pack.
Your computer is supplied with a lithium ion battery pack and can be recharged any time. Charging a partially discharged battery pack does not affect
the life of battery.
You can extend the life of your battery pack if you enable the battery care function of the Battery Charge Functions with the VAIO Control Center.
While some software applications or peripheral devices are in use, your computer may not enter Hibernate mode even when the remaining battery life
becomes short. To avoid loss of data while the computer is running on the battery, you should save your data frequently and manually activate a power
management mode, such as Sleep or Hibernate.
If the battery pack runs out of power while the computer is in Sleep mode, you will lose all unsaved data. Going back to the previous work state is
impossible. To avoid loss of data, you should save your data frequently.
24
n N
Getting Started >
Using the Battery Pack
Extending Your Battery Life
When your computer is running on battery power, you can extend your battery life using the following methods.
❑Decrease the LCD brightness of your computer screen.
❑Use the power saving mode. See Using the Power Saving Modes (page 26) for more information.
❑Change the power saving settings on the Power Options. See Using the VAIO Power Management (page 127) for more
information.
❑Set the wallpaper in Long Battery Life Wallpaper Setting as your desktop background with the VAIO Control Center.
25
n N
Getting Started >
Shutting Down Your Computer Safely
Shutting Down Your Computer Safely
To avoid losing unsaved data, be sure to shut down your computer properly, as described below.
To shut down your computer
1 Turn off any peripherals connected to the computer.
2 Click Start and the Shut down button.
3 Respond to any prompts warning you to save documents or to consider other users and wait for the computer to turn off
automatically.
The power indicator light turns off.
26
n N
Getting Started >
Using the Power Saving Modes
Using the Power Saving Modes
You can take advantage of the power management settings to conserve battery life. In addition to the normal operating mode,
your computer has two distinct power saving modes to suit your preference: Sleep and Hibernate.
!
If you do not intend to use your computer for an extended period of time while it is disconnected from AC power, place the computer into Hibernate
mode or turn it off.
If the battery pack runs out of power while your computer is in Sleep mode, you will lose all unsaved data. Going back to the previous work state is
impossible. To avoid loss of data, you should save your data frequently.
Mode Description
Normal mode This is the normal state of your computer while it is in use. The green power indicator light is lit while the
computer is in this mode.
Sleep mode Sleep mode turns off the LCD screen and places the built-in storage device(s) and the CPU into a low power
consumption mode. The orange power indicator light blinks slowly while your computer is in this mode. Your
computer comes out of Sleep mode quicker than out of Hibernate mode. However, Sleep mode uses more
power than Hibernate mode.
Hibernate mode While your computer is in Hibernate mode, the state of the system is saved on the built-in storage device(s) and
power is turned off. Even when the battery pack runs out of power, no data will be lost. The power indicator light
is unlit while your computer is in this mode.
27
n N
Getting Started >
Using the Power Saving Modes
Using Sleep Mode
To activate Sleep mode
Click Start, the arrow next to the Shut down button, and Sleep.
To return to Normal mode
❑Press any key.
❑Press the power button on your computer.
!
If you press and hold the power button for more than four seconds, your computer will turn off automatically. You will lose all unsaved data.
Using Hibernate Mode
To activate Hibernate mode
Press the Fn F12+ keys.
Alternatively, you can click Start, the arrow next to the Shut down button, and Hibernate.
!
Do not move your computer before its power indicator light turns off.
To return to Normal mode
Press the power button.
!
If you press and hold the power button for more than four seconds, your computer will turn off automatically.
28
n N
Getting Started >
Updating Your Computer
Updating Your Computer
Be sure to install the latest updates on your computer with the following software applications so that the computer can run
more efficiently.
❑Windows Update
Click Start, All Programs, and Windows Update and then follow the on-screen instructions.
❑VAIO Update 4
Click Start, All Programs, VAIO Update 4, and Go to VAIO Web Support and then follow the on-screen instructions.
!
Your computer must be connected to the Internet to download the updates.
29
n N
Using Your VAIO Computer >
Using Your VAIO Computer
This section describes how to get the most out of using your VAIO computer.
❑Using the Keyboard (page 30)
❑Using the Touch Pad (page 32)
❑Using Special-function Buttons (page 33)
❑Using the Built-in Camera (page 34)
❑Using the Optical Disc Drive (page 35)
❑Using "Memory Stick" (page 43)
❑Using Other Modules / Memory Cards (page 49)
❑Using the Internet (page 55)
❑Using the Network (LAN) (page 57)
❑Using the Wireless LAN (page 58)
❑Using the Bluetooth Function (page 65)
❑Using Fingerprint Authentication (page 70)
❑Using the TPM (page 77)
30
n N
Using Your VAIO Computer >
Using the Keyboard
Using the Keyboard
Your keyboard has additional keys that perform model-specific tasks.
Combinations and Functions with the Fn Key
✍
Some keyboard functions can be used only after the operating system is finished launching.
Combination/Feature Function
Fn + % (F2): muting Turns on and off the built-in speakers or the headphones.
Fn + 2 (F3/F4): volume control Changes the volume level.
To increase the volume, press the Fn+F4 keys and then the M or , key, or keep pressing the
Fn F4+ keys.
To decrease the volume, press the Fn+F3 keys and then the m or < key, or keep pressing the
Fn F3+ keys.
Fn + 8 (F5/F6): brightness control Changes the LCD brightness of your computer screen.
To increase lighting intensity, keep pressing the Fn F6+ keys or press the Fn+F6 keys and then
the M or , key.
To decrease lighting intensity, keep pressing the Fn+F5 keys or press the Fn+F5 keys and then
the m or < key.
Fn + /T (F7): display output Switches the display output between your computer screen, an external display, simultaneous
output to both, and multiple displays with both that function as a single desktop. Press the Enter
key to select the display output.
!
If you disconnect a display cable from your computer while an external display is selected as the display
output destination, the computer screen goes blank. In such a case, press the F7 key twice while holding
down the Fn key, and then press the Enter key to switch the display output to the computer screen.
Multiple displays may not be supported depending on the operating system on your computer.
31
n N
Using Your VAIO Computer >
Using the Keyboard
Fn + / (F9/F10): zooming Changes the size of an image or a document displayed on some software.
To make the view look smaller and further away (zoom out), press the Fn+F9 keys.
To make the view look bigger and closer (zoom in), press the Fn+F10 keys.
See the help file included with the VAIO Control Center for more information.
Fn + (F12): hibernation Provides the lowest level of power consumption. When you execute this command, the states
of the system and the connected peripheral devices are saved to the built-in storage device and
the system power is turned off. To return the system to its original state, use the power button
to turn on the power.
For details on power management, see Using the Power Saving Modes (page 26).
Combination/Feature Function
33
n N
Using Your VAIO Computer >
Using Special-function Buttons
Using Special-function Buttons
Your computer is equipped with special buttons to help you use specific functions of the computer.
Special-function button Functions
S1/S2 buttons Execute the task that is assigned to each button by default.
You can change the default assignment with the VAIO Control Center.
Drive eject button Ejects the optical disc drive tray.
If this button does not work, try the substitute drive eject button on the optical disc drive.
34
n N
Using Your VAIO Computer >
Using the Built-in Camera
Using the Built-in Camera
Your computer is equipped with a built-in MOTION EYE camera.
With the preinstalled image capture software, you can perform the following:
❑Capture still images and movies
❑Sense and capture object movements for monitoring purposes
❑Edit captured data
✍
Turning on the computer activates the built-in camera.
Video conferences are possible with the appropriate software.
!
Launching or exiting your instant messaging or video editing software does not activate or deactivate the built-in camera.
Do not place your computer into Sleep or Hibernate mode while you are using the built-in camera.
To use the preinstalled image capture software
1Click Start, All Programs, ArcSoft WebCam Companion 3, and WebCam Companion 3.
2Click your desired icon in the main window.
For detailed information on how to use the software, see the help file included with the software.
✍
When capturing an image or a movie in a dark place, click the Capture icon in the main window, and then click the WebCam Settings icon and select
the low light or low light compensation option in the properties window.
35
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
Using the Optical Disc Drive
Your computer is equipped with an optical disc drive.
Features and options in this section may not be available on your computer.
See the specifications to find out about the configuration of your computer.
To insert a disc
1Turn on the computer.
2Press the disc drive eject button (1) to open the drive.
The drive tray slides out.
!
If the power supply to the optical disc drive is disabled by the VAIO Power Management, it will take a while to eject the drive tray with the drive eject
button.
✍
If the drive eject button does not work, try the substitute drive eject button on the optical disc drive. The substitute drive eject button, however, is not
functional if the power supply to the optical disc drive is disabled by the VAIO Power Management.
36
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
3 Place a disc in the middle of the drive tray with the label side facing upward and gently push it down until the disc clicks
into place.
!
Do not exert pressure on the drive tray. Be sure to hold the bottom of the drive tray when placing/removing a disc onto/from the tray.
4 Close the drive tray by pushing it in gently.
!
Do not remove the optical disc while your computer is in a power saving mode (Sleep or Hibernate). Be sure to bring the computer back into Normal
mode before removing the disc.
37
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
Supported Disc Media
Your computer plays and records CDs, DVDs, and Blu-ray Disc ™ media, depending on the model you purchased.
See the reference chart below to find out which type of optical disc drive supports which types of media.
PR: playable and recordable
P: playable but not recordable
–: not playable or recordable
CD-
ROM
Video
CD
Music
CD
CD
Extra
CD-R/
RW
DVD-
ROM
DVD-
Video
DVD-R/
RW
DVD+R/
RW
DVD+R DL
(Double
Layer)
DVD-R DL
(Dual
Layer)
DVD-
RAM*1 *2
BD-
ROM
BD-R/RE *3
DVD±RW/
±R DL/RAM
P P P P PR *5 P P PR PR PR PR PR – –
Blu-ray Disc P P P P PR *5 P P PR PR P P PR P PR *4
Blu-ray Disc
Combo
P P P P PR *5 P P PR PR PR PR PR P P
*1 The DVD±RW/RAM disc drive on your computer does not support the DVD-RAM cartridge. Use non-cartridge discs or discs with a removable cartridge.
*2 Writing data to single-sided DVD-RAM discs (2.6 GB) compliant with DVD-RAM Version 1.0 is not supported.
DVD-RAM Version 2.2/12X-SPEED DVD-RAM Revision 5.0 disc is not supported.
*3 The Blu-ray Disc drive on your computer does not support BD-RE Disc media in Version 1.0 format and Blu-ray Disc media with a cartridge.
*4 Supports writing data to BD-R Part1 Version 1.1/1.2/1.3 discs (single-layer discs with the capacity of 25 GB, dual-layer discs with the capacity of 50 GB) and BD-
RE Part1 Version 2.1 discs (single-layer discs with the capacity of 25 GB, dual-layer discs with the capacity of 50 GB).
*5 Writing data to Ultra Speed CD-RW discs is not supported.
38
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
!
This unit is designed to playback discs that conform to the Compact Disc (CD) standard. DualDiscs and some music discs encoded with copyright
protection technologies do not conform to the Compact Disc (CD) standard. Therefore, these discs may not be compatible with this unit.
When you buy pre-recorded or blank discs for use with your VAIO computer, be sure to read the notices on the disc package carefully to check both
playback and recording compatibility with your computer's optical disc drives. Sony does NOT guarantee the compatibility of VAIO optical disc drives
with discs that are not compliant with the official "CD," "DVD," or "Blu-ray Disc" standard. USING NON-COMPLIANT DISCS CAN CAUSE FATAL DAMAGE
TO YOUR VAIO PC OR CREATE SOFTWARE CONFLICTS AND CAUSE SYSTEM HANGING.
For inquiries about disc formats, contact the individual publisher of the pre-recorded disc or the manufacturer of the recordable disc.
✍
8 cm disc writing is not supported.
!
To play copyright protected Blu-ray Disc media continually, update the AACS key. The AACS key update requires Internet access.
As with other optical media devices, circumstances may limit compatibility or prevent Blu-ray Disc media playback. VAIO computers may not support
movie playback on packaged media recorded in AVC or VC1 formats at high bit rates.
Region settings are required for some contents of DVD and BD-ROM Disc media. If the region setting on the optical disc drive does not match the
region coding on the disc, playback is not possible.
Unless your external display is compliant with the High-bandwidth Digital Content Protection (HDCP) standard, you cannot play or view the contents
of copyright protected Blu-ray Disc media.
Some content may restrict video output to standard definition or prohibit analog video output. When you output video signals through digital
connections, such as an HDMI connection or a DVI connection, it is strongly recommended that a digital HDCP compliant environment be implemented
for optimum compatibility and viewing quality.
Exit all memory-resident utility software before playing or writing a disc as it may cause the computer to malfunction.
39
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
Notes on Using the Optical Disc Drive
Notes on writing data to a disc
❑Only use circular discs. Do not use discs in any other shape (star, heart, card, etc.), as this may damage the optical disc
drive.
❑Do not strike or shake your computer while the optical disc drive is writing data to a disc.
❑Do not plug or unplug the power cord or the AC adapter while the optical disc drive is writing data to a disc.
❑Do not attach or disconnect your computer to or from the docking station (optional) while the optical disc drive is writing
data to a disc.
Notes on playing discs
To achieve optimum performance of disc playback, you should follow these recommendations:
❑Some CD players and computer optical disc drives may not be able to play audio CDs created with the CD-R or CD-RW
media.
❑Some DVD players and computer optical disc drives may not be able to play DVDs created with the DVD+R DL, DVD-R
DL, DVD+R, DVD+RW, DVD-R, DVD-RW, or DVD-RAM media.
❑You may not be able to play some Blu-ray Disc content on your computer, or the computer may become unstable during
Blu-ray Disc playback. To play content normally, download and install the latest updates for the WinDVD BD using the
VAIO Update.
For information on how to use the VAIO Update, see Updating Your Computer (page 28).
❑Depending on system environment, you may find sound interruptions and/or dropped frames during AVC HD playback.
❑Do not place your computer into either of the power saving modes while your computer is playing a disc.
40
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
Notes on region codes
Region code indicators are labeled on the discs or packages to indicate in which region and on what type of player you can
play the disc. If the region code indicates "all," you can play this disc in most regions of the world. If the region code for your
residence area is different from the label, you cannot play the disc on your computer.
To find out the region code for your residence area, see the following table.
If it is your first time to play a DVD video on your computer, follow these steps before inserting the disc:
1 Click Start and Computer.
2 Right-click the optical disc drive icon and select Properties.
3 Click the Hardware tab.
4 Select your optical disc drive from the All disk drives list and click Properties.
5 Click the DVD Region tab.
6 Select an appropriate region from the list and click OK.
Residence area Region code Residence area Region code Residence area Region code
Australia* 4 China 6 Hong Kong* 3
India* 5 Indonesia* 3 Japan* 2
Korea 3 Kuwait* 2 Malaysia* 3
New Zealand* 4 Philippines* 3 Saudi Arabia* 2
Singapore* 3 South Africa* 2 Taiwan 3
Thailand* 3 United Arab Emirates* 2 Vietnam 3
* A region code is not assigned to your computer's optical disc drive by default.
41
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
!
You can change the region code only a limited number of times. When you have exceeded this number, the drive's region code is permanently assigned
and you will not be able to change it again. Reconfiguring your computer does not reset this count.
If you change the region code while the WinDVD or WinDVD BD software is running, restart the software or eject the disc and re-insert it to make the
new setting effective.
42
n N
Using Your VAIO Computer >
Using the Optical Disc Drive
Playing Discs
To play a disc
1 Insert a disc into the optical disc drive.
!
Connect the AC adapter to the computer and close all running software applications before playing a disc.
2 If nothing appears on the desktop, click Start, All Programs, and your desired software to play the disc.
For instructions on how to use the software, see the help file included with the software.
Copying Files to Discs
To copy files to a disc
1 Insert a recordable disc into the optical disc drive.
!
Connect the AC adapter to the computer and close all running software applications before copying files to a disc.
2 If nothing appears on the desktop, click Start, All Programs, and your desired disc burning software to copy files to the
disc.
For instructions on how to use the software, see the help file included with the software.
43
n N
Using Your VAIO Computer >
Using "Memory Stick"
Using "Memory Stick"
"Memory Stick" is a compact, portable, and versatile IC recording media especially designed for exchanging and sharing
digital data with compatible products, such as digital cameras, mobile phones, and other devices. Because it is removable,
it can be used for external data storage.
Before You Use "Memory Stick"
The "Memory Stick" slot on your computer can accommodate the following sizes and types of media:
❑"Memory Stick"
❑"Memory Stick Duo"
❑"Memory Stick PRO"
❑"Memory Stick PRO Duo"
❑"Memory Stick PRO-HG Duo"
!
The "Memory Stick" slot on your computer does not support 8-bit parallel data transfer (high-speed data transfer).
For the latest information about "Memory Stick", visit [memorystick.com] at http://www.memorystick.com/en/.
44
n N
Using Your VAIO Computer >
Using "Memory Stick"
Inserting and Removing "Memory Stick"
To insert "Memory Stick"
1 Locate the "Memory Stick" slot.
2 Hold "Memory Stick" with the arrow facing upward and pointing toward the slot.
3 Carefully slide "Memory Stick" into the slot until it clicks into place.
✍
"Memory Stick" is automatically detected by your system and the contents of "Memory Stick" are displayed. If nothing appears on the desktop, click
Start, Computer, and double-click the "Memory Stick" icon.
The "Memory Stick" icon will appear in the Computer window after you insert "Memory Stick" into the slot.
45
n N
Using Your VAIO Computer >
Using "Memory Stick"
✍
You can insert Duo-size "Memory Stick" directly into the "Memory Stick" slot without using a "Memory Stick Duo" adaptor.
!
Be sure to hold "Memory Stick" with the arrow pointing in the correct direction as you insert it into the slot. To avoid damaging your computer or the
media, do not force "Memory Stick" into the slot if you cannot insert it smoothly.
Before using "Memory Stick Micro" ("M2"), be sure to insert it into an "M2" Standard-size adaptor or "M2" Duo adaptor. If you insert the media directly
into the "Memory Stick" slot without the adaptor, you may not be able to remove it from the slot.
"Memory Stick Micro" in an "M2" Duo adaptor may not operate properly if it is additionally inserted into a "Memory Stick Duo" adaptor.
To remove "Memory Stick"
!
Do not remove "Memory Stick" while the Media Access indicator light is lit. If you do, you may lose data. Large volumes of data may take time to load,
so make sure the indicator light is unlit before removing "Memory Stick".
1 Locate the "Memory Stick" slot.
2 Check that the Media Access indicator light is unlit.
3 Push in "Memory Stick" toward the computer and release.
"Memory Stick" ejects.
4 Pull "Memory Stick" out of the slot.
!
Be sure to remove "Memory Stick" gently, or it may pop out unexpectedly.
46
n N
Using Your VAIO Computer >
Using "Memory Stick"
Formatting "Memory Stick"
To format "Memory Stick"
"Memory Stick" has been formatted by default and is ready for use.
If you want to reformat the media with your computer, follow these steps.
!
Be sure to use the device that is designed to format the media and supports "Memory Stick" when formatting the media.
Formatting "Memory Stick" erases the entire data stored on the media. Before formatting the media, make sure that it does not contain your valuable
data.
Do not remove "Memory Stick" from the slot while formatting. This could cause a malfunction.
1 Locate the "Memory Stick" slot.
2 Carefully slide "Memory Stick" into the slot until it clicks into place.
3 Click Start and Computer to open the Computer window.
4 Right-click the "Memory Stick" icon and select Format.
5 Click Restore device defaults.
!
The size of the allocation unit and file system may change.
Do not select NTFS from the File system drop-down list as it may cause a malfunction.
✍
The formatting process will be completed more quickly if you select Quick Format in Format options.
47
n N
Using Your VAIO Computer >
Using "Memory Stick"
6 Click Start.
7 Follow the on-screen instructions.
!
It may take time to format "Memory Stick" depending on the media type.
49
n N
Using Your VAIO Computer >
Using Other Modules / Memory Cards
Using Other Modules / Memory Cards
Using the ExpressCard Module
Your computer is equipped with an ExpressCard/34 slot *
for transferring data among digital cameras, camcorders, music
players, and other audio/video devices. This slot can only accommodate an ExpressCard/34 (34 mm wide) module *.
* Referred to as the ExpressCard slot and the ExpressCard module in this manual.
To insert an ExpressCard module
1 Locate the ExpressCard slot.
2 Carefully slide the ExpressCard module into the slot until it clicks into place.
Do not force it into the slot.
✍
If the module does not go into the slot easily, remove it gently and verify you are inserting it in the proper direction.
Make sure you use the most recent driver software provided by the ExpressCard module manufacturer.
50
n N
Using Your VAIO Computer >
Using Other Modules / Memory Cards
To remove an ExpressCard module
✍
You can skip steps 1 to 4 when:
- your computer is off.
- the Safely Remove Hardware icon is not displayed on the taskbar.
- the hardware you want to unplug is not displayed in the Safely Remove Hardware window.
1 Locate the ExpressCard slot.
2 Double-click the Safely Remove Hardware icon on the taskbar.
3 Select the hardware you want to unplug and click Stop.
4 Follow the on-screen instructions for removing the ExpressCard module.
5 Push in the ExpressCard module toward the computer so that the module pops out.
6 Gently take hold of the ExpressCard module and pull it out of the slot.
51
n N
Using Your VAIO Computer >
Using Other Modules / Memory Cards
Using the SD Memory Card
Your computer is equipped with an SD memory card slot. You can use this slot to transfer data among digital cameras,
camcorders, music players, and other audio/video devices.
Before you use the SD memory card
The SD memory card slot on your computer supports the following memory cards:
❑SD memory card
❑SDHC memory card
For the latest information on compatible memory cards, see Finding More about Your VAIO Computer (page 5) to visit the
appropriate support web site.
52
n N
Using Your VAIO Computer >
Using Other Modules / Memory Cards
To insert an SD memory card
1 Locate the SD memory card slot.
2 Hold the SD memory card with the arrow facing upward and pointing toward the slot.
3 Carefully slide the SD memory card into the slot until it clicks into place.
Do not force the card into the slot.
✍
If the SD memory card does not go into the slot easily, remove it gently and verify you are inserting it in the proper direction.
The SD memory card icon will appear in the Computer window after you insert the card into the slot.
53
n N
Using Your VAIO Computer >
Using Other Modules / Memory Cards
To remove an SD memory card
1Locate the SD memory card slot.
2Check that the Media Access indicator light is unlit.
3Push in the SD memory card toward the computer and release.
The SD memory card ejects.
4Pull the SD memory card out of the slot.
54
n N
Using Your VAIO Computer >
Using Other Modules / Memory Cards
Notes on Using Memory Cards
General notes on using the memory card
❑Be sure to use memory cards that are compliant with the standards supported by your computer.
❑Be sure to hold the memory card with the arrow pointing in the correct direction as you insert it into the slot. To avoid
damaging your computer or the media, do not force the memory card into the slot if you cannot insert it smoothly.
❑Use care when inserting or removing the memory card from the slot. Do not force it in or out of the slot.
❑Do not remove the memory card while the media access indicator light is lit. If you do, you may lose data.
❑Do not attempt to insert a memory card or memory card adaptor of a different type into the memory card slot. An
incompatible memory card or memory card adaptor may cause difficulty in removing from the slot and can cause damage
to your computer.
Notes on using the SD memory card
❑Your computer has been tested and found compatible only with major memory cards available as of May 2009. However,
not all memory cards that meet the same specifications as the compatible media are guaranteed of compatibility.
❑SD memory cards with capacity of up to 2 GB and SDHC memory cards with capacity of up to 32 GB have been tested
and found compatible with your computer.
❑The SD memory card slot on your computer does not support the high-speed data transfer feature of the SD memory
card and the SDHC memory card.
55
n N
Using Your VAIO Computer >
Using the Internet
Using the Internet
Before using the Internet, you need to sign up with an Internet Service Provider (ISP) and set up devices required for
connecting your computer to the Internet.
The following types of Internet connection services may be available from your ISP:
❑Fiber to the Home (FTTH)
❑Digital Subscriber Line (DSL)
❑Cable modem
❑Satellite
❑Dial-up
For detailed information on devices required for Internet access and how to connect your computer to the Internet, ask your
ISP.
✍
To connect your computer to the Internet using the wireless LAN function, you need to set up the wireless LAN network. See Using the Wireless LAN
(page 58) for more information.
!
When you connect your computer to the Internet, be sure to take appropriate security measures to protect the computer against online threats.
If your computer is not equipped with a built-in modem, you may need to connect an external modem device, for example a USB telephone modem, a
DSL modem, or a cable modem, to your computer. For the detailed instructions on connection setups and modem configuration, see the manual that
came with your modem.
58
n N
Using Your VAIO Computer >
Using the Wireless LAN
Using the Wireless LAN
Using the Wireless LAN (WLAN), all your digital devices with the built-in WLAN function communicate freely with each other
through a network. A WLAN is a network in which a user can connect to a Local Area Network (LAN) through a wireless (radio)
connection.
The WLAN supports all normal LAN connectivity, but with the added benefits of mobility and roaming. You can still access
information, Internet/intranet and network resources, even in the middle of a meeting, or as you move from one place to
another.
You can communicate without an access point, which means that you can communicate with a limited number of computers
(ad-hoc). Or you can communicate through an access point, which allows you to create a full infrastructure network.
✍
In some countries, using WLAN products may be restricted by the local regulations (e.g. limited number of channels). Therefore, before activating the
WLAN function, read the Safety Regulations carefully.
WLAN uses the IEEE 802.11a
*/b/g standard or the IEEE 802.11n
* draft standard, which specifies the type of technology used. The standard includes
the encryption methods: Wired Equivalent Privacy (WEP), which is a security protocol, Wi-Fi Protected Access 2 (WPA2), and Wi-Fi Protected Access
(WPA). Proposed jointly by the IEEE and Wi-Fi Alliance, both WPA2 and WPA are specifications of standards based on interoperable security
enhancements that increase the level of data protection and access control for existing Wi-Fi networks. WPA is designed to be forward compatible with
the IEEE 802.11i specification. It utilizes the enhanced data encryption Temporal Key Integrity Protocol (TKIP) in addition to user authentication using
802.1X and Extensible Authentication Protocol (EAP). Data encryption protects the vulnerable wireless link between clients and access points. Besides
that, there are other typical LAN security mechanisms to ensure privacy, such as: password protection, end-to-end encryption, virtual private networks,
and authentication. WPA2, the second generation of WPA, provides stronger data protection and network access control and is also designed to secure
all versions of 802.11 devices, including 802.11b, 802.11a, 802.11g, and 802.11n draft standard, multi-band and multi-mode. In addition, based on
the ratified IEEE 802.11i standard, WPA2 provides government grade security by implementing the National Institute of Standards and Technology
(NIST) FIPS 140-2 compliant AES encryption algorithm and 802.1X-based authentication. WPA2 is backward compatible with WPA.
* See the specifications to find out about the configuration of your computer.
59
n N
Using Your VAIO Computer >
Using the Wireless LAN
The IEEE 802.11b/g standard is a wireless LAN standard, using the 2.4 GHz band. The IEEE 802.11g standard provides higher-speed communications
than the IEEE 802.11b standard.
The IEEE 802.11a standard is a wireless LAN standard, using the 5 GHz band.
The IEEE 802.11n draft standard is a wireless LAN standard, using the 2.4 GHz or 5 GHz band.
Wireless LAN devices using the 2.4 GHz band cannot communicate with devices using the 5 GHz band because the frequencies are different.
The 2.4 GHz band used by wireless LAN compatible devices is also used by other various devices. Although technologies to minimize interference from
other devices that use the same band are employed on wireless LAN compatible devices, such interference may cause lower communication speed,
narrower communication range, or broken wireless connections.
The communication speed varies depending on the distance between communication devices, existence of obstacles between such devices, the device
configuration, the radio conditions, and the software in use. In addition, communications may be cut off depending on the radio conditions.
The communication range varies depending on the actual distance between communication devices, existence of obstacles between such devices, the
radio conditions, the ambient environment that includes existence of walls and materials of such walls, and the software in use.
Actual communication speed may not be as fast as the one displayed on your computer.
Deploying IEEE 802.11b and IEEE 802.11g products on the same wireless network may reduce the communication speed due to radio interference.
Taking this into consideration, the IEEE 802.11g products are designed to reduce the communication speed to ensure communications with
IEEE 802.11b products. When the communication speed is not as fast as expected, changing the wireless channel on the access point may increase
the communication speed.
60
n N
Using Your VAIO Computer >
Using the Wireless LAN
Communicating without an Access Point (Ad-hoc)
An ad-hoc network is a network in which a LAN is created only by wireless devices themselves, with no other central controller
or access point. Each device communicates directly with other devices in the network. You can set up an ad-hoc network
easily at home.
62
n N
Using Your VAIO Computer >
Using the Wireless LAN
Communicating with an Access Point (Infrastructure)
An infrastructure network is a network that extends an existing wired local network to wireless devices by providing an access
point (not supplied). The access point bridges the wireless and wired LAN and acts as a central controller for the wireless
LAN network. The access point coordinates transmission and reception from multiple wireless devices within a specific range.
The access point will select which channel to use on an infrastructure network.
!
For details on how to select the channel that will be used by the access point, see the manual that came with your access point.
64
n N
Using Your VAIO Computer >
Using the Wireless LAN
Stopping Wireless LAN Communications
To stop wireless LAN communications
Click the button next to or above the WLAN icon in the VAIO Smart Network window.
!
Turning off the wireless LAN function while accessing remote documents, files, or resources may result in data loss.
66
n N
Using Your VAIO Computer >
Using the Bluetooth Function
Communicating with Another Bluetooth Device
You can connect your computer to a Bluetooth device such as another computer, a mobile phone, a PDA, a headset, a
mouse, or a digital camera without the use of any cables.
To communicate with another Bluetooth device
To communicate with another Bluetooth device, you first need to set up the Bluetooth function. For setting up and using the
Bluetooth function, search Windows Help and Support for Bluetooth information.
1Turn on the WIRELESS switch.
2Click the button next to or above the Bluetooth icon in the VAIO Smart Network window.
Make sure the WIRELESS indicator light turns on.
67
n N
Using Your VAIO Computer >
Using the Bluetooth Function
Stopping Bluetooth Communications
To stop Bluetooth communications
1Turn off the Bluetooth device that is communicating with your computer.
2Click the button next to or above the Bluetooth icon in the VAIO Smart Network window.
68
n N
Using Your VAIO Computer >
Using the Bluetooth Function
Notes on Using the Bluetooth Function
❑The data transfer rate varies, depending on the following conditions:
❑Obstacles, such as walls, located between devices
❑Distance between devices
❑Material used in walls
❑Proximity to microwaves and cordless telephones
❑Radio frequency interference and other environmental conditions
❑Device configuration
❑Type of software application
❑Type of operating system
❑Use of both wireless LAN and Bluetooth functions at the same time on your computer
❑Size of file being exchanged
❑Large files may occasionally be corrupted during continuous transfer due to limitations of the Bluetooth standard and
electromagnetic interference in the environment.
❑All Bluetooth devices must be certified to make sure that the applicable standard requirements are maintained. Even if
standards are met, individual device performance, specifications, and operation procedures can vary. Data exchange may
not be possible in all situations.
❑Video and audio may not be synchronized if you play videos on your computer with audio output from a connected
Bluetooth device. This is a frequent occurrence with Bluetooth technology and is not a malfunction.
❑The 2.4 GHz band, with which Bluetooth devices or wireless LAN devices work, is used by various devices. Bluetooth
devices use the technology to minimize the interference from other devices that use the same wave length. Simultaneous
use of the Bluetooth function and wireless communication devices, however, may cause radio interference and result in
reduced communication speeds and distances than the standard values.
69
n N
Using Your VAIO Computer >
Using the Bluetooth Function
❑The Bluetooth function may not work with other devices, depending on the manufacturer or the software version employed
by the manufacturer.
❑Connecting multiple Bluetooth devices to your computer may cause channel congestion, resulting in poor performance
of the devices. This is normal with Bluetooth technology and is not a malfunction.
70
n N
Using Your VAIO Computer >
Using Fingerprint Authentication
Using Fingerprint Authentication
Your computer is equipped with a fingerprint sensor to provide you with additional convenience.
Once you have registered your fingerprint(s), the fingerprint authentication function offers:
❑A substitute for password entry
❑Logging onto Windows (page 75)
If you have registered your fingerprints for your user account, you can substitute fingerprint authentication for
password entry when logging onto Windows.
❑Power-on Security feature (page 75)
If you have set the power-on password (page 113), you can substitute fingerprint authentication for password entry
when starting your computer.
❑Password Bank for quick web site access
Once you have registered your user information (user accounts, passwords, etc.) for web sites in the Password Bank,
you can substitute fingerprint authentication for entering information required to access the password-protected web sites.
For detailed information, see the help file included with the Protector Suite.
!
You may not be able to use the Password Bank feature depending on the web site you access.
❑Archive encryption
❑File Safe feature to encrypt/decrypt data
With the File Safe feature, you can create an encrypted archive to include a file and/or folder for protection against
unauthorized access. The encrypted archive can be decrypted or unlocked for included file/folder access by swiping
your finger across the fingerprint sensor or entering the backup password you specified for encryption.
❑Personal Safe feature
With the Personal Safe feature, you can encrypt contents of any protected folder on the desktop or the built-in storage
device. The encrypted folder will be hidden from other users sharing your computer.
71
n N
Using Your VAIO Computer >
Using Fingerprint Authentication
❑Application launcher function for quick application access
The application launcher feature is available on your computer for launching your preferred application (executable file)
that is assigned to one of your fingers with a registered fingerprint. Once you have assigned an application to your finger,
you can launch the assigned application simply by swiping the finger across the fingerprint sensor.
❑Strong Password Generator function
The Strong Password Generator function allows you to enhance computer security by generating a strong password
resistant to dictionary attacks. The generated password can be registered in the Password Bank.
73
n N
Using Your VAIO Computer >
Using Fingerprint Authentication
If you have failed to register a fingerprint, follow these steps to try again.
1Place the top joint of your finger on the fingerprint sensor (1).
74
n N
Using Your VAIO Computer >
Using Fingerprint Authentication
2Swipe your finger perpendicularly across the fingerprint sensor.
!
Place your fingertip flat in the center of the fingerprint sensor.
Scan your fingerprint from the top joint of the finger to the fingertip.
Keep your finger in contact with the fingerprint sensor while swiping.
Fingerprint registration may fail if you move your finger too quickly or too slowly. Let the fingerprint sensor take about one second to scan your
fingerprint.
You may not be able to register and/or have your fingerprint(s) recognized if your finger is too dry or wet, wrinkled, injured, dirty, etc.
Register more than one fingerprint in case that the fingerprint sensor fails to recognize the fingerprint.
Be sure to clean your fingertip(s) and the fingerprint sensor before swiping in order to keep good recognition performance.
You can register only the limited number of fingerprints for logging onto your system using the Power-on Security feature (page 75). The maximum
number of fingerprints you can register varies depending on the data amount of each fingerprint.
You can also select the fingerprint you want to use for the Power-on Security feature (page 75) later.
75
n N
Using Your VAIO Computer >
Using Fingerprint Authentication
Logging Onto Your System
To use the fingerprint authentication function in place of a password entry to log onto your system, you need to set the power-
on, hard disk, and Windows passwords and configure your computer for fingerprint authentication.
For setting the power-on, hard disk, and Windows passwords, see Setting the Password (page 112).
For detailed information, see the help file included with the Protector Suite.
Logging onto Windows
If you have registered your fingerprints for your user account, you can substitute fingerprint authentication for Windows
password entry. To log onto Windows, swipe the registered finger across the fingerprint sensor when the Windows log-on
screen appears.
Power-on Security feature
If you have set the power-on password (page 113) and/or the hard disk password (page 118), you can substitute fingerprint
authentication for password entry when starting your computer.
76
n N
Using Your VAIO Computer >
Using Fingerprint Authentication
Erasing the Registered Fingerprints
Before disposing of your computer or transferring it to a third person, it is strongly recommended you erase the fingerprint
data registered on the fingerprint sensor after erasing the data stored on your built-in storage device.
To erase the registered fingerprints
1Turn on the computer.
2Press the F2 key when the VAIO logo appears.
The BIOS setup screen appears. If the screen does not appear, restart the computer and press the F2 key several times
when the VAIO logo appears.
3Press the < or , key to select Security to display the tab.Security
4Press the m key to select Clear Fingerprint Data and press the Enter key.
5At the confirmation prompt, select Continue and press the Enter key.
The fingerprint data registered on the fingerprint sensor is erased automatically after your system restarts.
77
n N
Using Your VAIO Computer >
Using the TPM
Using the TPM
The embedded Trusted Platform Module (TPM) is embedded in your computer to provide basic security functions. In
combination with the TPM, you can encrypt and decrypt your data to strengthen computer security against inappropriate
access.
TPMs are defined by Trusted Computing Group (TCG) and also called security chips.
78
n N
Using Your VAIO Computer >
Using the TPM
Important Notice
Notes on encrypting the operating system or program files
Encrypting files used by your operating system or any software application, using the Encrypting File System (EFS) with the
TPM, will disable you to launch or operate such software.
To avoid such problems, observe the following before using the EFS:
❑Be sure to save data you want to encrypt to the following destinations:
❑The Encrypted Data folder created with the default settings in the user initialization process
❑A new encrypted folder created in the My Documents folder or the Documents folder on your account
❑The Personal Secure Drive
✍
The Personal Secure Drive is a virtual drive that is created by using the Personal Secure Drive feature and automatically encrypts data that is saved to it.
❑Do not change the following settings on the View tab in the Folder Options window displayed by clicking Folder and
search options from Organize in the menu of Windows Explorer.
❑Don't show hidden files, folders, or drives
❑Hide protected operating system files (Recommended)
❑Do not change the system attributes of the files, unless necessary.
❑Do not encrypt the Windows folder, the Program Files folder, and all files in each folder.
❑Do not encrypt the Users folder and all account folders in it.
79
n N
Using Your VAIO Computer >
Using the TPM
Notes on encrypting key files or files on the Personal Secure Drive
Encrypting files created in the following folders when your user account is initialized and the EFS is enabled will disable you
to launch your TPM software and decrypt the encrypted data.
With the default settings, the files in the folders below cannot be encrypted because they have system attributes.
Do not change the system attributes of the files in the folders below.
!
The following folders are hidden by default.
❑Folders containing key files
❑C:\ProgramData\Infineon
❑C:\Users\All Users\Infineon
(C:\Users\All Users is a shortcut to C:\ProgramData.)
❑ C:\Users\<account>\AppData\Roaming\Infineon
❑Files on the Personal Secure Drive
C:\Security Platform\Personal Secure Drive\System Data\xxx.FSF
80
n N
Using Your VAIO Computer >
Using the TPM
Notes on encrypting backup files or other files
Encrypting backup archive files or emergency recovery token files will disable you to recover your computer system for
emergency, and encrypting password reset token files or secret files will disable you to reset the password.
Do not encrypt the following files or folders:
✍
The default path for files below or displayed by clicking Browse is My Documents (or Documents)\Security Platform or Security Platform in removal
media.
❑Automatic backup archive file
Default file name: SPSystemBackup.xml or SPSystemBackup_<your computer name>.xml
❑Storage folder for automatic backup archive files
Folder name (Fixed):
❑SPSystemBackup (The folder is created as the subfolder for the SPSystemBackup.xml file.)
❑SPSystemBackup_<your computer name> (The folder is created as the subfolder for SPSystemBackup_<your
computer name>.xml file.)
❑Emergency recovery token file
Default file name: SPEmRecToken.xml
❑Password reset token file
Default file name: SPPwResetToken.xml
❑Token file for emergency recovery/password reset
Default file name: SPToken_<your computer name>.xml
❑Password reset secret file
Default file name: SPPwdResetSecret.xml or SPPwdResetSecret_<your computer name>_<user name>.<domain
name>.xml
81
n N
Using Your VAIO Computer >
Using the TPM
❑Key and certificate backup file
Default file name: SpBackupArchive.xml
❑PSD backup file
Default file name: <Drive name>-Personal Secure Drive.fsb
❑Owner password backup file
Default file name: SpOwner_<your computer name>.tpm
❑Protocol file
Default file name: SpProtocol_<your computer name>_<user name>.<domain name>.txt
82
n N
Using Your VAIO Computer >
Using the TPM
Configuring the TPM
To use the embedded TPM, you need to:
1 Enable the TPM in the BIOS setup screen.
2 Install the Infineon TPM Professional Package.
3 Initialize and configure the TPM.
To enable the TPM in the BIOS setup screen
1 Turn on your computer.
2 Press the F2 key when the VAIO logo appears.
The BIOS setup screen appears. If not, restart the computer and press the F2 key several times when the VAIO logo
appears.
3 Press the < , or key to select the Security tab, the M or m key to select Change TPM State, and then the Enter key.
4 Press the M or m key to select Enable and then the Enter key.
5 Press the < or , key to select Exit, select Exit Setup, and then press the Enter key.
6 After your system restarts, select Execute in the confirmation window and then press the Enter key.
✍
You can also disable the TPM and clear the TPM configuration in the BIOS setup screen.
!
Before enabling the TPM, be sure to set the power-on and hard disk passwords to protect against unauthorized modification of the TPM configuration.
If the TPM is enabled, it will take longer before the VAIO logo appears due to security checks at computer startup.
You will not be able to access any TPM-protected data if you clear the TPM ownership. Before clearing the TPM configuration, be sure to make backup
copies of the TPM-protected data.
83
n N
Using Your VAIO Computer >
Using the TPM
To install the Infineon TPM Professional Package
Read the Readme.txt in the C:\Infineon\Readme folder. Then, double-click setup.exe in the C:\Infineon folder to install the
package.
To install this package, you must have administrative rights on the computer.
!
You need to set a few passwords while installing the Infineon TPM Professional Package. Without these passwords, you will not be able to restore
any TPM-protected data or backup files. Be sure to write down the passwords and keep them safe and private from other people.
To initialize and configure the TPM
See the on-screen documentation for detailed information. To open the documentation, click Start, , All Programs Infineon
Security Platform Solution, and Help.
!
The maintenance and management of TPM-protected data must be carried out at your own risk. Sony assumes no liability for any defects arising out
of your data maintenance and management.
84
n N
Using Peripheral Devices >
Using Peripheral Devices
You can add functionality to your VAIO computer by using the various ports on the computer.
❑Connecting a Docking Station (page 85)
❑Connecting External Speakers or Headphones (page 93)
❑Connecting an External Display (page 94)
❑Selecting Display Modes (page 101)
❑Using the Multiple Monitors Function (page 102)
❑Connecting an External Microphone (page 104)
❑Connecting a USB Device (page 105)
❑Connecting an i.LINK Device (page 107)
85
n N
Using Peripheral Devices >
Connecting a Docking Station
Connecting a Docking Station
Attaching a docking station enables you to connect additional peripherals to your computer, such as a printer and an external
display.
A docking station is not supplied with your computer and is available as an optional accessory.
87
n N
Using Peripheral Devices >
Connecting a Docking Station
Attaching Your Computer to the Docking Station
!
Be sure to install the battery pack before attaching your computer to the docking station.
To attach your computer to the docking station
!
Use the AC adapter supplied with your computer.
Do not move your computer when it is attached to the docking station. This may detach the docking station and cause damage to both units.
1Disconnect all peripherals from the computer.
2Plug one end of the power cord (1) into the AC adapter (2) and the other end into an AC outlet.
3Plug the cable connected to the AC adapter (2) into the DC IN port (3) on the docking station (4).
4Unfold the docking station cover.
88
n N
Using Peripheral Devices >
Connecting a Docking Station
5Slide open the docking station connector cover on the bottom of the computer.
6Align the rear bottom corners of the computer with the guides on the docking station.
89
n N
Using Peripheral Devices >
Connecting a Docking Station
7Gently push down the computer until it clicks into place.
8Turn on the computer.
90
n N
Using Peripheral Devices >
Connecting a Docking Station
Disconnecting Your Computer from the Docking Station
!
Make sure that no devices connected to the docking station are in use before disconnecting your computer.
Do not disconnect your computer from the docking station while the IN USE indicator light is lit. Disconnecting the computer while the IN USE indicator
is lit may result in loss of unsaved data or a failure of the computer.
When the battery pack is running out of power, disconnecting your computer from the docking station may result in loss of unsaved data.
Do not disconnect your computer from the docking station during video playback. Be sure to close video playback software before disconnection.
Once you have completed the steps in To disconnect your computer from the docking station (page 91), be sure to take your computer off the docking
station. Use of the computer while on the docking station may cause unstable operations.
91
n N
Using Peripheral Devices >
Connecting a Docking Station
To disconnect your computer from the docking station
1Press the UNDOCK button (1) and wait until the IN USE indicator light (2) turns off.
✍
If the IN USE indicator is unlit, you do not have to press the UNDOCK button.
Pressing the UNDOCK button while your computer is in a power saving mode brings the computer to Normal mode first, and then initiates the
disconnection process.
!
Once you have placed your computer back in Normal mode, be sure to take your computer off the docking station. Use of the computer while on the
docking station may cause unstable operations.
93
n N
Using Peripheral Devices >
Connecting External Speakers or Headphones
Connecting External Speakers or Headphones
You can connect external sound output devices (not supplied), such as speakers or headphones, to your computer.
To connect external speakers
✍
Make sure your speakers are designed for computer use.
!
Turn down the volume of the speakers before you turn them on.
Connect external speakers (1) to the headphones jack (2) i with a speaker cable (3) (not supplied).
95
n N
Using Peripheral Devices >
Connecting an External Display
To connect a computer display or a projector
!
The monitor port on your computer is not accessible when the computer is attached to the docking station.
The HDMI output port on your computer and the DVI-D port on the docking station are functional only while your computer is in SPEED mode.
If you connect an HDMI cable to the HDMI output port on your computer or a display cable to the DVI-D port on the docking station while your computer
is in STAMINA mode, a confirmation window appears. Follow the on-screen instructions to change the performance mode to SPEED mode.
1 Plug the power cord (1) of your external display or the projector into the AC outlet.
2 Connect the external display or the projector to the monitor port (2) on the computer or the docking station with a display
cable (3).
✍
If necessary, connect the headphones jack on the projector and the headphones jack (4) i on the computer with a speaker cable (5).
96
n N
Using Peripheral Devices >
Connecting an External Display
!
Your computer is compliant with the HDCP standard and capable of encrypting the transmission channel of digital video signals for the purpose of
copyright protection, which enables you to play and view a wide variety of copyright protected and high-quality content. To view the copyright protected
content, connect an HDCP-compliant monitor to the HDMI output port on your computer or the DVI-D port on the docking station. If your computer
has a non-compliant monitor connected, you will not be able to play or view any copyright protected content.
✍
If the external computer display is equipped with an HDMI input port, plug one end of an HDMI cable into the HDMI output port on the computer and
the other end into the HDMI input port on the computer display.
If your computer is equipped with the HDMI output port, use an HDMI to DVI-D adapter to connect a TFT/DVI monitor.
DVI-D stands for Digital Visual Interface - Digital. It is a type of DVI port that supports only digital video signals (no analog video signals). It has 24 pins.
A DVI-I (Digital Visual Interface - Integrated) port supports digital video and analog video signals. It has 29 pins.
The HDMI cable carries both video and audio signals.
97
n N
Using Peripheral Devices >
Connecting an External Display
Using the VAIO Presentation Support
The VAIO Presentation Support allows you to use handy functions for the presentation, for example, displaying a document
for quick reference and the mirror image of the connected external display simultaneously on the computer screen.
To use the VAIO Presentation Support
1 Press the S1 or S2 button to launch the VAIO Presentation Support.
If the VAIO Presentation Support is not assigned to either of the buttons, change the button assignment with the VAIO
Control Center.
2 Select your desired display mode.
✍
Selecting any display mode other than Normal Display activates the Presentation mode. In Presentation mode, some functions of the computer, such
as a screen saver, the power saving modes, and system message generation, are disabled so as not to disturb a presentation.
98
n N
Using Peripheral Devices >
Connecting an External Display
Connecting a TV with an HDMI Input Port
You can connect a TV with an HDMI input port to your computer.
To connect a TV to your computer
!
To hear sound from the device connected to the output port, you need to change the device for sound output. For detailed instructions, see HDMI How
do I change the sound output device? (page 195).
The HDMI output port is functional only while your computer is in SPEED mode.
If you connect an HDMI cable to the HDMI output port while your computer is in STAMINA mode, a confirmation window appears. Follow the on-screen
instructions to change the performance mode to SPEED mode.
1 Plug the power cord of your TV (1) into an AC outlet.
2 Plug one end of an HDMI cable (2) to the HDMI output port (3) on the computer and the other end to the TV.
3 Switch the input channel of the TV to external input.
4 Set up the TV configuration system.
100
n N
Using Peripheral Devices >
Connecting an External Display
✍
You can adjust the screen resolution of the connected TV with your computer. See Why doesn't my screen display a video? (page 186) for more
information.
With the HDMI connection, the volume can be adjusted by the connected audio device only. Your computer has no control over the output volume of
any connected devices.
101
n N
Using Peripheral Devices >
Selecting Display Modes
Selecting Display Modes
When an external display is connected, you can select either your computer screen or the connected display to use as the
primary monitor.
!
The monitor port on your computer is not accessible when the computer is attached to the docking station.
The screen resolution of your external display may change when you switch between the performance modes.
✍
For selecting a video controller, see Selecting Performance Modes (page 110).
You may not be able to display the same content on your computer screen and the external display or projector at the same time, depending on the
type of your external display or projector.
Turn on the external display before turning on your computer.
To select a display mode with the Fn+F7 keys
You can select a display mode with the Fn+F7 keys. See Combinations and Functions with the Fn Key (page 30) for more
information.
To select a display mode from the display settings
1 Right-click on the desktop and select Screen resolution.
2 Click the drop-down list next to Multiple Displays, select your desired setting, and then click OK.
102
n N
Using Peripheral Devices >
Using the Multiple Monitors Function
Using the Multiple Monitors Function
The Multiple Monitors function allows you to distribute portions of your desktop across separate displays. For example, if you
have an external display connected to the monitor port, your computer screen and the external display can function as a
single desktop.
You can move the cursor from one display to the other. This allows you to drag objects, such as an open application window
or a toolbar, from one display to the other.
103
n N
Using Peripheral Devices >
Using the Multiple Monitors Function
To use the Multiple Monitors function
!
The monitor port on your computer is not accessible when the computer is attached to the docking station.
The screen resolution of your external display may change when you switch between the performance modes.
✍
For selecting a video controller, see Selecting Performance Modes (page 110).
Your external display may not support the Multiple Monitors function.
Certain software applications may not be compatible with Multiple Monitors settings.
Make sure that your computer does not enter Sleep or Hibernate mode while you are using the Multiple Monitors function, or the computer may not
return to Normal mode.
If you set different colors on each display, do not expand a single window across two displays, or your software may not work properly.
1 Right-click on the desktop and select Screen resolution.
2 Click the drop-down list next to Multiple Displays, select Extend these displays, and then click OK.
✍
You can set the display colors and resolution for each display and customize the Multiple Monitors function.
Set fewer colors or a lower resolution for each display.
104
n N
Using Peripheral Devices >
Connecting an External Microphone
Connecting an External Microphone
You can connect an external microphone (not supplied) to your computer.
To connect an external microphone
Plug the microphone cable (1) into the microphone jack (2) m.
✍
Make sure your microphone is designed for computer use.
105
n N
Using Peripheral Devices >
Connecting a USB Device
Connecting a USB Device
You can connect a Universal Serial Bus (USB) device to your computer, such as a mouse, floppy disk drive, speaker, and
printer.
To connect a USB device
1 Choose the USB port (1) you prefer to use.
2 Plug the USB device cable (2) into the USB port.
107
n N
Using Peripheral Devices >
Connecting an i.LINK Device
Connecting an i.LINK Device
Your computer is equipped with an i.LINK port which you can use to connect an i.LINK device, such as a digital video
camcorder.
✍
i.LINK is a trademark of Sony Corporation used only to designate that a product contains an IEEE 1394 connection. The procedure to establish an i.LINK
connection may vary, depending on a software application, an operating system, and a compatible i.LINK device. Not all products with an i.LINK
connection can communicate with each other. See the manual that came with your compatible i.LINK device for more information on operating
conditions and proper connection. Before connecting compatible i.LINK PC peripherals to your system, such as a CD-RW or hard disk drive, confirm
their operating system compatibility and required operating conditions.
Notes on connecting i.LINK devices
❑The i.LINK port on your computer does not supply power to an external device. If the external device requires external
power, be sure to connect it to a power source.
❑The i.LINK port supports transfer rates up to 400 Mbps. However, the actual transfer rate depends on the transfer rate of
the external device.
❑The optional i.LINK cables may not be available in some countries or regions.
❑An i.LINK connection with other compatible devices is not fully guaranteed.
❑The i.LINK connection may not be available depending on the software applications, operating system, and i.LINK-
compatible devices you use. See the manual that came with your software for more information.
❑Check the working conditions and operating system compatibility of i.LINK-compatible PC peripherals (for example, an
HDD or a CD-RW drive) before you connect them to your computer.
108
n N
Using Peripheral Devices >
Connecting an i.LINK Device
Connecting a Digital Video Camcorder
To connect a digital video camcorder
Plug one end of an i.LINK cable (1) (not supplied) into the i.LINK port (2) on the computer and the other end into the DV In/
Out port (3) on the digital video camcorder.
✍
The connection procedure varies depending on your compatible i.LINK device. See the manual that came with the device for more information.
You cannot access the contents of "Memory Stick" in the digital video camcorder via an i.LINK connection.
Switch the video format between NTSC and PAL with the software that you use.
Specyfikacje produktu
| Marka: | Sony |
| Kategoria: | laptop |
| Model: | Vaio VGN-Z56MG |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Sony Vaio VGN-Z56MG, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje laptop Sony
14 Października 2024
13 Października 2024
11 Października 2024
11 Października 2024
6 Października 2024
2 Października 2024
1 Października 2024
28 Września 2024
21 Września 2024
19 Września 2024
Instrukcje laptop
- laptop Samsung
- laptop Fellowes
- laptop LG
- laptop Xiaomi
- laptop Huawei
- laptop Lenovo
- laptop Gigabyte
- laptop Acer
- laptop Fujitsu
- laptop Panasonic
- laptop Viewsonic
- laptop Asus
- laptop Medion
- laptop MSI
- laptop Toshiba
- laptop Haier
- laptop HP
- laptop Prixton
- laptop Hyundai
- laptop Honor
- laptop Tripp Lite
- laptop Zebra
- laptop Dell
- laptop Schneider
- laptop Thomson
- laptop Pyle
- laptop Apple
- laptop Razer
- laptop ADATA
- laptop GoClever
- laptop SPC
- laptop NEC
- laptop Oregon Scientific
- laptop Jay-Tech
- laptop Microsoft
- laptop ECS
- laptop XPG
- laptop Denver
- laptop Lexibook
- laptop Micromax
- laptop Odys
- laptop TechBite
- laptop TrekStor
- laptop Alienware
- laptop Airis
- laptop Emachines
- laptop Hähnel
- laptop Sylvania
- laptop Coby
- laptop Evga
- laptop Naxa
- laptop Ricatech
- laptop Mpman
- laptop Vizio
- laptop Targa
- laptop Peaq
- laptop Ematic
- laptop Hannspree
- laptop Inovia
- laptop Ergotron
- laptop Ibm
- laptop Atdec
- laptop Packard Bell
- laptop Compaq
- laptop SIIG
- laptop Hercules
- laptop Kogan
- laptop Getac
- laptop Vulcan
- laptop System76
- laptop General Dynamics Itronix
- laptop CTL
- laptop Everex
- laptop Olidata
- laptop Dynabook
- laptop Hamilton Buhl
- laptop AORUS
- laptop Humanscale
- laptop Aplic
- laptop Schenker
Najnowsze instrukcje dla laptop
3 Kwietnia 2025
2 Kwietnia 2025
28 Marca 2025
28 Marca 2025
26 Marca 2025
13 Marca 2025
7 Marca 2025
4 Marca 2025
1 Marca 2025
26 Lutego 2025
