Electric Air Pump Compressor / Air Inflator
SLPUMP20
for SUP Stand-Up Paddle-Boards
and Water Sport Pool Inatables
I. PRODUCT INTRODUCTION
SLPUMP20 is an intelligent DC electric pump with the preset pressure LCD
screen, which can be used for inatable tent, SUP, etc. Thanks to the intelligent
pressure system, for example, if a pressure value is preset, when the pressure
reaches the preset pressure value, the pump will automatically stop inating.
II. LIST OF ACCESSORIES
Please make sure that the following accessories are in the box before using it, if
any missing, please contact with the local supplier.
III. DETAILS OF ACCESSORIES
www.SereneLifeHome.com
1
READ THIS USER MANUAL CAREFULLY BEFORE USING THIS EQUIPMENT.
User Instructions must always be available to the user
and are not to be removed except by the user of this equipment.
CATALOGUE
I. Product Introduction
II. List of Accessories
III. Details of Accessories
IV. Safety Instructions
V. Ination Operation
VI. Precautions
VII. Fault Handling
VIII. Maintenance and Storage
IX. Features and Technical Specs
www.SereneLifeHome.com
2
Air pump Hose Instruction Book
2
3
4
5
6
1
10 11
7
8
9
16.00
Ination inlet
Pressure value LCD screen
Pressure unit toggle button
Pressurizing button
Decompressing button
On/o button
DC plug
Air tap
Hose
Flexible conduit adaptor
Air inlet
1
2
3
4
5
6
7
8
9
10
11
2
2
2
3
4
5
6
6
8
V. INFLATION OPERATION
• Connect the end with Flexible conduit adaptor of the hose with the air pump
ination inlet (1), and twist clockwise to tighten it, as Figure 1.
• Install the other end of the hose into the supporting air tap of the air bag
(step in Figure 2), and twist clockwise to tighten it, and then insert the ①
ination valve of the air bag and twist clockwise to x it (step in Figure 2).②
• Plug the DC plug into the 12V DC socket.
• Press the pressure unit toggle button to select the unit you need.
• Press the pressurizing button or decompressing button to set the
pressure value you need, with the range of the pressure value from 0 to 16PSI,
(1PSI=0.0689BAR)
• After nishing the above steps, press the power switch button to start to
inate.
• During the inating process, you can press the pressurizing button or
decompressing button to increase or reduce the pressure value, press the
pressure unit toggle button to switch the unit, and press the On/O button
to stop.
• When the pressure reaches the set value, the air pump will stop working
automatically.
• After completing the ination, pull out the DC plug from the 12V DC socket.
• After pulling out the DC plug, please take down the hose from the air pump and
air bag and store it.
www.SereneLifeHome.com
3
IV. SAFETY INSTRUCTIONS
• Warning: In order to reduce the risk of injury, please keep children away from it.
Always supervise children and incapacitated person contacting or using this air
pump.
• Warning: Children shall be kept far away from this product and wire.
• Warning: This product is not applicable for the person with declining physical
strength, sensory ability or mental capacity, the person lack of skill and the
mentally retarded person, unless they are under the protection of their
guardians, supervised and directed at the same time.
• Warning: Before moving, maintaining, repairing or adjusting this product,
please rst pull out the DC plug from the socket.
• Warning: Please do not bury the wire in the soil, and it shall be place in the safe
zone where it won't be damaged by mower or other equipment.
• Warning: If the power wire is damaged, the power wire must be changed by
the manufacturer or its service agent or the similar authorized personnel, in
case of any risk.
• Warning: If you are standing in a place with water or your hands are wet, please
don't plug or pull the DC plug.
• Warning: Before inating, please pay attention to check the maximum bearable
pressure of the inatable product, because the air bag may be damaged upon
exceeding the maximum bearable pressure.
• Warning: Before using, please check the cigarette lighter socket to make sure
that there is no rust or residue inside. The cigarette lighter socket with poor
electric conduction may cause overheating of the product or power source,
which will damage the product.
• Warning: The purpose of using this product is limited to the description in the
instruction book.
www.SereneLifeHome.com
4
Figure 1 Figure 2

Specyfikacje produktu

Marka: SereneLife
Kategoria: Niesklasyfikowane
Model: SLPUMP20
