Assembly Instructions:

SEDONA L400CART

L500CART

& L600CART

Lynx Freestanding Cart

Model L400CART, L500CART &L600CART

Lynx Grills, Inc., 6023 E. Bandini Blvd. Commerce, CA 90040 Ph

Document 33807 Rev C 02/08/13

Step 1.

Step 2.

Step 3.

Step 1.

Aer opening and idenfying the components, select the back

panel assembly and either the right or le side panel assembly.

Orient the parts as shown in the illustraon for . step 1

Note that these parts are upside down with the shelves at the

oor. Hook the right or le side to the back into the four keyways

located on the edge. When aached all four keyways should be

engaged and the back and side ush to the top.

Repeat this step for the opposite side panel.

Step 2.

With the cart oriented upside down, locate the 4 - #8 screws and

nuts and mount the electrical transformer to the access plate

shown in the illustraon for this step. It may be done at the end of

the assembly but is somewhat easier to access at this stage.

Step 3.

Refer to the gure for and insert the base assembly into the step 3

cavity at the back corners of the cabinet. Check that the tank hole

is posioned as shown and the magnet is located on the open side.

Splay the two sides out slightly and enclose them over the front of

the base. The sides and back have pockets that t over the casters

for clearance. Use 4 of the ¼-20 x ½ screw at each corner to lock

the assembly in place.

Access

Plate

magnet

tank

hole

Screw

4 places

Introducon:

Your Freestanding Cart comes with all of the components necessary

to assemble a cart for the SEDONA Series of Lynx Grills.

The SEDONA CART series is comprised of 8 sub assemblies:

1. Back Panel Assembly

2. Right Side Panel Assembly with Shelf

3. Le Side Panel Assembly with Shelf

4. Base Assembly with Wheels

5. Inner Shelf Assembly

6. Cross Brace Assembly

7. Right Door

8. Le Door

In addion there are 14 screws (1/4 -20 x ½) to assemble the

cart and grill and 4 screws with nuts (#8-32 x 3/8) to aach the

transformer assembly supplied with the Grill.

Step 4.

Step 5.

To begin turn the cabinet upright to secure the step 4

Inner Shelf Assembly. The and shelf will only L400 L500

assemble as shown at the right with the electrical hole to

the rear and the screws mounng at the back and le

side. The shelf is not only useful but necessary for the

proper stability of the cart. omit the inner shelf DO NOT

or any part in these instrucons.

The inner shelf is secured by 4 of the ¼-20 x ½ screws.

Two through the back and two through the le side.

The shelf as shown here assemble L600 will

the same as above.

Step 5 L400/L500 is the last assembly on the cart before

installing the Grill to the cart. The cross brace ts into

recesses located at the front edge of the cart above the

hinge brackets. Orient the brace with the center magnet

facing forward and posioned such that the magnet is

higher than center rather than lower. Install the brace from

the backside of the anges and align the nutcerts each at

end with the holes provided for the screws. The brace is

secured by 2 of the ¼-20 x ½ screws.

The door frame is aached along with the cross brace . L600

Support the cross brace from the backside of the front

anges. Align the nutcerts each end with the holes at

provided for the screws. Posion the door frame over the

nutcerts and cross brace , and secure them both with the ¼-

20 x ½ screws.

Step 4 .

L400

L500

Step 4 .

L600

Step 5.

L400

L500

Step 5.

L600

With assistance, remove all packing materials from the grill.

Also remove the grates and warming racks to lighten the

assembly. The grill will be placed onto the cart as

illustrated in this step. The back edge will engage rst and

the front will slide down into posion unl horizontal.

Using two people with gloves - grasp the front and side of –

the Grill at points A and B. Place the unit on the cart and

lower it slowly unl horizontal.

Do not grip grill by the

control knobs as damage

may occur

Step 6.

Four screws remain in the package for assembly.

To secure the grill to the cart locate 4 screws at the i

corners of the rebox. Remove and discard the 4 scr

these locaons. Replace them one at a me with the

screws from the kit.

The le and right hand doors now assemble to the c

shown.

Refer to the installaon manual provided with the gr

proper electrical and gas connecons.

Step 7.

Drop the door hinge

pins into the

corresponding door

hinge on the frame.

Step 6.

Step 5.

L600
