Sauter GmbH

Ziegelei 1

D-72336 Balingen

e-mail: info@kern-sohn.com

Phone : +49-[0]7433- 9933-0

Fax: +49-[0]7433- - 9933 149

Internet: www.sauter.eu

Instruction Manual Multi-Mode

Ultrasonic Material Thickness Gauge

SAUTER - TN EE

Version 2.0

04/2020

TN_EE- -e-2020 BA

PROFESSIONAL MEASURING

TN_EE- -e-2020 2 BA

SAUTER TN- EE

V. 2.0 04/2020

Instruction Manual Multi-Mode Ultrasonic

Material Thickness Gauge

Congratulations on the purchase of a multi-mode material thickness gauge

from SAUTER. We hope you will enjoy your quality measuring instrument with its wide

range of functions. Please do not hesitate to contact us if you have any questions,

requests or suggestions.

Table of contents:

1. General information ....................................................................................... 3

1.1 Technical data ........................................................................................................................... 3

1.2 Main functions .......................................................................................................................... 3

1.3 Measuring principle .................................................................................................................. 4

1.4 Conguration ............................................................................................................................ 4

2. Control panel and display layout .................................................................. 5

2.1 Explanation of the key symbols .............................................................................................. 6

3. Preparation for commissioning .................................................................... 6

3.1 Selection of the sound generator ........................................................................................... 6

3.2 Conditions and preparations for surfaces ............................................................................. 8

4. Mode of operation .......................................................................................... 8

4.1 Switching on and o ................................................................................................................ 8

4.2 Selecting the measuring mode ............................................................................................... 9

4.3 Zero calibration ......................................................................................................................... 9

4.4 Calibration of the sound velocity .......................................................................................... 10

4.5 perform measurements .......................................................................................................... 12

4.6 Scan mode (ultrasound image mode) .................................................................................. 12

4.7 Change the resolution ............................................................................................................ 13

4.8 Changing the units ................................................................................................................. 13

4.9 Storage management ............................................................................................................. 13

4.10 EL Backlight ............................................................................................................................ 14

4.11 Battery information ................................................................................................................ 14

4.12 Automatic switch- off .............................................................................................................. 14

4.13 Establishing the basic setting of the system (reset) .......................................................... 14

4.14 Connection to the computer . ................................................................................................ 14

5. Maintenance ................................................................................................. 15

6. Transport and storage ................................................................................. 15

3 TN_EE- -e-2020 BA

1. General information

The Model TN-EE is a universal ultrasonic material thickness gauge. The device works

according to the same measuring principle as SONAR gauges and is used to measure

the thickness of various materials with a measuring accuracy of up to 0.1/0.01mm.

By simply switching from the operating mode 'pulse-echo' to 'echo-echo' (ignoring

resist lms or other lms) the ultrasonic measuring instrument TN 60-0.01EE can be

used universally.

1.1 Technical data

TN 30-0.01EE

TN 60-0.01EE

Dispaly

4.5 inch LCD display with backlight

Measuring range

(pulse-echo)

0.65~600mm (steel)

Measuring range

(Echo-Echo)

3~30mm

3~60mm

Sound velocity

1000~9999m/s

Resolution

0.1mm/0.01mm

Accuracy: ± 0,5 % thickness +0,01mm,

Memory

of up to 20 les (up to 99 measured values per le)

with stored measured values

Power supply

2x 1,5V AA batteries

Communication

USB 1.1

Ambient temperature

-20°C - 60°C

max. air humidity

≤ 90%

Dimensions

150x74x32mm

Weight

245g

1.2 Main functions

1. Universal application: Operation in 'pulse-echo' and 'echo-echo' mode

2. Possibility to measure the thickness of various materials, such as metal, plastic,

ceramics, composites, epoxy resins, glass and other materials with good ultrasonic

conductivity

3. Special applications possible with various transducers, including thickness

measurement of coarse-grained materials and at high temperature

4. Functions Sensor Zero, calibration of sound velocity

5. Function Two-point calibration

6. Single point mode and scan mode. The measurement results are requested seven

times per second in single point mode and sixteen times per second in scan mode.

7. The thickness gauge has a status display for coupling connection

8. Measuring unit: metric/inch.

9. Battery indicator to indicate the remaining battery life

10. Automatic standby and shutdown function to conserve battery power

11. Software for processing stored measurement data with the computer
