Strona 1/4

Connections

yFor better picture and audio quality, connect to a digital device using an HDMI cable.

yThe picture may not display normally (if at all) or the audio may not work if an external

device that uses an older version of HDMI mode is connected to the TV. If such a problem

occurs, ask the manufacturer of the external device about the HDMI version and, if out of

date, request an upgrade.

yBe sure to purchase a certiﬁed HDMI cable. Otherwise, the picture may not display or a

connection error may occur.

yPC(D-Sub) and PC/DVI AUDIO IN input are not supported.

yFor HDMI/DVI cable connection, you must use the port. HDMI IN 1(DVI)

yConnecting through the HDMI cable may not be supported depending on the PC.

yIf an HDMI to DVI cable is connected to the port, the audio does not work.HDMI IN 1(DVI)

yService: Connector for service only.

Remote Control

✎This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired persons.

Figures and illustrations in this User Manual are provided for reference

only and may differ from actual product appearance. Product design and

speciﬁcations may be changed without notice.

Still image warning

Avoid displaying still images (like jpeg picture ﬁles) or still image element (like TV

programme logo, panorama or 4:3 image format, stock or news bar at screen bottom

etc.) on the screen. Constant displaying of still picture can cause ghosting of LED

screen, which will affect image quality. To reduce risk of this effect, please follow below

recommendations:

• Avoid displaying the same TV channel for long periods.

• Always try do display any image on full screen, use TV set picture format menu for

best possible match.

• Reduce brightness and contrast values to minimum required to achieve desired

picture quality, exceeded values may speed up the burnout process.

• Frequently use all TV features designed to reduce image retention and screen

burnout, refer to proper user manual section for details.

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to

ensure proper ventilation.

Failing to do so may result in ﬁre or a problem with the product due to an increase in

the internal temperature of the product.

✎When using a stand or wall-mount, use parts provided by Samsung

Electronics only.

xIf you use parts provided by another manufacturer, it may result in a problem

with the product or an injury due to the product falling.

✎The appearance may differ depending on the product.

✎Be careful when you contact the TV because some parts can be somewhat

hot.

Installation with a stand. Installation with a wall-mount.

10 cm

10 cm10 cm

10 cm

Channel Mode

Channels will be switched within the favourite or memorised channel

list.

■

Added Channels: Shows all added channels.

■

Favourite Ch.: Shows all favourite channels.

Fine Tune

If the reception is clear, you do not have to ﬁne tune the channel, as

this is done automatically during the search and store operation. If the

signal is weak or distorted, ﬁne tune the channel manually.

✎Fine tuned channels that have been saved are marked with an

asterisk “*” on the right-hand side of the channel number in the

channel banner.

✎To reset the fine-tuning, select .Reset

Picture Menu

Mode

Select your preferred picture type.

■

Dynamic: Suitable for a bright room.

■

Standard: Suitable for a normal environment.

■

Movie: Suitable for watching movies in a dark room.

Backlight / Contrast / Brightness / Sharpness /

Colour / Tint (G/R)

Your television has several setting options for picture quality control.

Advanced Settings

(available in mode)Standard / Movie

Compared to previous models, new Samsung TVs have a more

precise picture.

■

Colour Space (Auto / Native): Adjusts the range of colours

available to create the image.

■

White Balance: Adjust the colour temperature for a more natural

picture.

R-Offset / G-Offset / B-Offset: Adjust each colour’s (red, green,

blue) darkness.

R-Gain / G-Gain / B-Gain: Adjust each colour’s (red, green, blue)

brightness.

Reset White Balance: Resets the to its default settings.

■

Gamma: Adjusts the primary colour intensity.

■

Dynamic Contrast (Off / Low / Medium / High): Adjusts the

screen contrast.

■

Black Tone (Off / Dark / Darker / Darkest): Select the black level

to adjust the screen depth.

■

Flesh Tone: Emphasize pink “Flesh Tone”.

■

Motion Lighting (Off / On): Reduce power consumption by

brightness control adapted motion.

✎Only available in mode.Standard

Picture Options

■

Colour Tone (Cool / Standard / Warm1 / Warm2)

✎Warm1 Warm2 or will be deactivated when the picture mode

is .Dynamic

■

Size: Your cable box/satellite receiver may have its own set of

screen sizes as well. However, we highly recommend you use 16:9

mode most of the time.

16:9: Sets the picture to 16:9 wide mode.

Wide Zoom: Magniﬁes the picture size more than 4:3.

✎Adjusts the by using Position ▲, buttons.▼

Zoom: Magniﬁes the 16:9 wide pictures vertically to ﬁt the screen

size.

4:3: Sets the picture to basic (4:3) mode.

✎Do not watch in 4:3 format for a long time. Traces of borders

displayed on the left, right and centre of the screen may

cause image retention (screen burn) which are not covered

by the warranty.

Screen Fit: Displays the full image without any cut-off when HDMI

(720p / 1080i / 1080p) or Component (1080i / 1080p) signals are

inputted.

✎NOTE

xAfter selecting Screen Fit in HDMI (1080i / 1080p) or

Component (1080i / 1080p) mode: Adjusts the Position or

Size by using ▲, ▼, ◄ , button.►

xDepending on the input source, the picture size options may

vary.

xThe available items may differ depending on the selected

mode.

xSettings can be adjusted and stored for each external device

connected to an input on the TV.

xIf you use the function with HDMI 720p input, Screen Fit

1 line will be cut at the top, bottom, left and right as in the

overscan function.

■

Digital Noise Filter (Off / Low / Medium / High / Auto): If the

broadcast signal received by your TV is weak, you can activate the

Digital Noise Filter feature to reduce any static and ghosting that

may appear on the screen.

✎When the signal is weak, try other options until the best

picture is displayed.

■

HDMI Black Level (Normal / Low): Selects the black level on the

screen to adjust the screen depth.

✎Available only in mode (RGB signals).HDMI

■

Film Mode (Off / Auto): Sets the TV to automatically sense and

process ﬁlm signals from all sources and adjust the picture for

optimum quality.

✎Available in TV mode, AV, COMPONENT (480i / 1080i) and

HDMI (480i / 1080i).

■

LED Motion Plus (Off / On): Removes drag from fast scenes with

a lot of movement to provide a clear picture.

Picture Reset

Resets your current picture mode to its default settings.

■

Reset Picture Mode: Returns all picture values in the currently

selected mode to the default settings.

Sound Menu

Mode

■

Standard: Selects the normal sound mode.

■

Music: Emphasizes music over voices.

■

Movie: Provides the best sound for movies.

■

Clear Voice: Emphasizes voices over other sounds.

■

Amplify: Increase the intensity of high-frequency sound to allow a

better listening experience for the hearing impaired.

Equalizer

(standard sound mode only)

■

Balance: Adjusts the balance between the right and left speaker.

■

100Hz / 300Hz / 1KHz / 3KHz / 10KHz (Bandwidth Adjustment):

Adjusts the level of speciﬁc bandwidth frequencies.

■

Reset: Resets the equalizer to its default settings.

SRS TruSurround HD

(standard sound mode only)

This function provides a virtual 5.1 channel surround sound

experience through a pair of speakers using HRTF (Head Related

Transfer Function) technology.

Auto Volume

Because each broadcasting station has its own signal conditions,

the volume may ﬂuctuate each time channel is changed. This feature

lets you automatically adjust the volume of the desired channel by

lowering the sound output when the modulation signal is high or by

raising the sound output when the modulation signal is low.

Selecting the Sound Mode

When you set to , the current sound mode is displayed on Dual l-ll

the screen.

Audio Type Dual I-II Default

A2 Stereo

Mono Mono Automatic

change

Stereo Stereo ↔ Mono

Dual Dual I ↔ Dual II Dual I

NICAM

Stereo

Mono Mono Automatic

change

Stereo Mono ↔ Stereo

Dual Mono ↔ Dual I

 Dual II Dual I

✎If the stereo signal is weak and an automatic switching, occurs,

then switch to the mono.

✎Only activated in stereo sound signal.

✎This function is available for all input sources.

Sound Reset

■

Reset All: Reset all sound settings to the factory defaults.

Setup Menu

Setting the Time

Time

✎The current time will appear every time you press the INFO

button.

■

Clock Set Day Month Year Hour Minute: Set the , , , , .

■

Sleep Timer

Automatically shuts off the TV after a preset period of time. (30,

60, 90, 120, 150 and 180 minutes).

✎To cancel Sleep Timer, select .Off

Timer 1 / Timer 2 / Timer 3

Three different on / off timer settings can be made. You must set the

clock ﬁrst.

■

On Time / Off Time: Set the hour, minute and Activate / Inactivate.

(To activate the timer with the setting you have chosen, set to

Activate.)

■

Volume: Set the desired volume level.

■

Contents On Time: When the is activated, you can turn on a

speciﬁc channel or play back contents such as photo or audio ﬁles.

- TV/USB TV USB: Select or . (Make sure that an USB device is

connected to your TV.)

- : Displays the current antenna source.Antenna

- : Select the desired channel.Channel

- Music/Photo: Select the folder containing MP3/JPEG ﬁles on the

USB device.

✎The maximum displayed number of files, including sub

folders, in one folder of USB storage device is 2000.

✎The media may not be playing smoothly when using the

device lower than USB 2.0.

■

Repeat Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun: Select or

Manual Manual to set at your convenience. If you select , you can

set up the day you want to activate the timer.

Security

✎The PIN input screen appears before the setup screen.

✎Enter your 4-digit PIN, the default of which is “0-0-0-0”. Change

the PIN using the option.Change PIN

xChild Lock (Off / On) Channel List: Lock channels in , to prevent

unauthorized users, such as children, from watching unsuitable

programme.

✎Only available when the Input source is set to TV.

xChange PIN: Change your password required to set up the TV.

✎If you forget the PIN code, press the remote control buttons

in the following sequence in Standby mode, which resets the

PIN to “0-0-0-0”: (on).MUTE →8→2→4→POWER

Language

Set the menu language.

✎Select Language and press the ENTER

button.

Eco Solution

■

Energy Saving

(Off / Low / Medium / High / Picture

Off) : This adjusts the brightness of the TV in order to reduce

power consumption. If you select Picture Off, the screen is

turned off, but the sound remains on. Press any button except

volume button to turn on the screen.

■

No Signal Power Off (Off / 15 min / 30 min / 60 min): To avoid

unnecessary energy consumption, set how long you want the TV

to remain on if it’s not receiving a signal.

✎Disabled when the PC is in power saving mode.

■

Auto Power Off (Off / On): The TV will be automatically turned

off when no user operation is received for 4 hours.

Auto Protection Time

■

Auto Protection Time (Off / 2 hours / 4 hours / 8 hours / 10

hours): If the screen remains idle with a still image for a certain

period of time deﬁned by the user, the screen saver is activated

to prevent the formation of ghost images on the screen.

General

■

Game Mode (Off/On) : When connecting to a game console

such as PlayStation™ or Xbox™, you can enjoy a more realistic

gaming experience by selecting the game mode.

xPrecautions and limitations for game mode

- To disconnect the game console and connect another

external device, set to in the setup Game Mode Off

menu.

- If you display the TV menu in , the screen Game Mode

shakes slightly.

xGame Mode TV is not available in mode.

xAfter connecting the game console, set to Game Mode

On to prevent poor picture quality. Unfortunately, you may

notice reduced picture quality

■

Melody off: Set so that a melody plays when the TV is turned ,

Low Medium High, and .

✎The does not play.Melody

- When no sound is output from the TV because the MUTE

button has been pressed.

- When no sound is output from the TV because the volume

has been reduced to minimum with the button.VOL –

- When the TV is turned off by function.Sleep Timer

Support Menu

Self Diagnosis

■

Picture Test: Use to check for picture problems. If the problem

continues to occur, check the colour pattern.

■

Sound Test: Use the built-in melody sound to check for sound

problems.

■

Reset: Reset all settings to the factory defaults.

✎The PIN input screen appears before the setup screen.

✎Enter your 4-digit PIN. Change the PIN using the Change

PIN option.

Software Upgrade

Software Upgrade can be performed by downloading the latest

ﬁrmware from “www.samsung.com” to a USB memory device.

HD Connection Guide

Refer to this information when connecting external devices to the

TV.

Contact Samsung

View this information when your TV does not work properly or

when you want to upgrade the software. You can ﬁnd information

regarding our call centres, and how to download products and

software.

LED TV

user manual

Getting Started

Accessories

• Remote Control & Batteries (AAA x 2)

• Owner’s Instructions

• Warranty Card / Safety Guide (Not available

in some locations)

• Holder-Wire stand

• Power Cord

Input Cables (Sold Separately)

HDMI HDMI-DVI Component

Composite (AV) Coaxial (RF)

TV Controller (Panel Key)

Function menu

MEDIA.P

m R

Return

TV Controller Remote control sensor

Down (Front)

Up (Rear)

RightLeft

Power on Turns the TV on by pressing the controller in

standby mode.

Adjusting the volume Adjusts the volume by moving the controller from

side to side when the power is on.

Selecting a channel Selects a channel by moving the controller up and

down when the power is on.

Using the function menu

Press the controller when the power is on, then the

function menu screen appears. If you press it again,

the function menu screen disappears.

Using the Menu ( )m

Selects the ( ) by moving the controller in Menu m

the function menu screen. The OSD(On Screen

Display) of your TV’s feature appears.

Selecting the Source ( )

Selects the Source( ) by moving the controller in

the function menu screen. The Source List screen

appears.

Selecting the Media Play

Selects the MEDIA.P by moving the controller in

the function menu screen. The Media Play main

screen appears.

Power Off (

)Selects the Power Off (

) to turn the TV off by

moving the controller in the function menu screen.

✎Exits the menu when pressing the controller more than 1 second.

✎When selecting the function by moving the controller to the up/down/left/

right directions, be sure not to press the controller. If you press it first, you

cannot operate it to move the up/down/left/right directions.

Plug & Play

When you turn the TV on for the ﬁrst time, a sequence of on-screen

prompts will assist in conﬁguring basic settings. Press the POWER

button. is available only when the Input source is set to Plug & Play

TV.

✎Connecting the power cord and antenna. (refer to

‘Connections’)

Selecting a language

Select the OSD Language.

Language

Move

Enter

Plug & Play







English

Indonesia

Select the desired OSD (On Screen

Display) language.



Selecting a Home Use mode

Select 'Home Use' when installing this TV in your home.

Move

Enter

Plug & Play

Home UseStore Demo









• Select the Home Use mode.

Store Demo mode is for retail

environments.

• When pressing TV controller, the

function menu screen appears.

Select the ( ) and press Menu m

it more than 5 seconds using the

controller. The Store Demo mode

is set. Cancel the Store Demo by

selecting Source( ) and pressing

it more than 5 seconds.



Selecting an Area

Select Area.

Area : Asia/Europe

Plug & Play

Enter





Press the / ►ENTER

button. Press

the or ▲ ▼ button, then press the

ENTER

button to select the

appropriate area.



Auto Store

The channel search will start automatically.



Setting the Clock Set

Set current date and time

Day Month Year

01 01 2012

Hour Minute

23 00

Move

Adjust

Enter

Skip

Clock Set

Press the or ◄ ► button to select Day,

Month, Year, Hour Minute and .

Set these by pressing the / / ▲▼◄

/ button, and press the ►ENTERE

button to go next step.



Viewing the HD Connection Guide

The connection method for the best HD screen quality is displayed.



Enjoy your TV.

Press the ENTER

button.

Channel Menu

Seeing Channels

Channel List

Select a channel in the , All Channels, Added Channels

Favourites Programmed or screen by pressing the / ▲ ▼

buttons, and pressing the ENTER

button. Then you can watch

the selected channel.

Added Channels

a 5 Air

a 6 ♥ TV #6

a 7 ♥ TV #7

a 8 Air

a 9 Air

a 9 ♥ TV #9

a 10 Air

a 11 ♥ TV #11

a 12 ♥ TV #12

Zoom Select T Tools

■

All Channels: Shows all currently available channels.

■

: Shows all added channels.Added Channels

■*

Favourites: Shows all favourite channels.

■

: Shows all currently reserved Programmes.Programmed

✎Using the remote control buttons with the Channel List

xGreen : Enlarges or shrinks a channel number.(Zoom)

xYellow : Selects multiple channel lists. Select desired (Select)

channels and press the Yellow button to set all the selected

channels at the same time. The

mark appears to the left of

the selected channels.

(Tools Channel List): Displays the option menu. (The

Options menus may differ depending on the situation.)

Channel Status Display icons

Icons Operations

A channel selected.

A channel set as a favourites.

A locked channel.

)

A reserved programme.

Retuning Channels

Area

You can change the desired area.

Auto Store

(depending on the country)

Scans for a channel automatically and stores in the TV.

✎Automatically allocated programme numbers may not

correspond to actual or desired programme numbers. If a

channel is locked, the PIN input window appears.

Manual Store

Scans for a channel manually and stores in the TV.

✎If a channel is locked, the PIN input window appears.

✎According to channel source, may be Manual Store

supported.

✎Programme Colour System Sound System Channel, , , ,

Search Store, : If there is abnormal sound or no sound,

reselect the sound standard required.

✎Channel mode

xP (Programme): When tuning is complete, the broadcasting

stations in your area have been assigned to position

numbers from P0 to P99. You can select a channel by

entering the position number in this mode.

xC S (aerial channel mode) / (cable channel mode): These

two modes allow you to select a channel by entering the

assigned number for each aerial broadcasting station or

cable channel.

Channel List Option Menu

Set each channel using the menu options (Channel List Add/

Delete Add to Favourite/Delete from Favourite Timer Viewing, , ,

Lock/Unlock Edit Channel Name Sort Select All/Deselect , , ,

All Auto Store, ). Option menu items may differ depending on the

channel status.

Set each channel using the menu options. Option Channel List

menu items may differ depending on the channel status.

■

Add / Delete: Delete or add a channel to display the channels

you want.

✎All deleted channels will be shown on the All Channels

menu.

✎A gray-Coloured channel indicates the channel has been

deleted.

✎The menu only appears for deleted channels.Add

✎Delete a channel from the or Added Channels Favourites

menu in the same manner.

■

Add to Favourite / Delete from Favourite

: Set

channels you watch frequently as favourites

■

Timer Viewing: You can set a desired channel to be displayed

automatically at the set time; even when you are watching

another channel. Set the current time ﬁrst to use this function.

■

Edit Channel Name: Assign your own channel name.

■

Sort: This operation allows you to change the programme

numbers of the stored channels. This operation may be

necessary after using the auto store.

■

Lock / Unlock: Lock a channel so that the channel cannot be

selected and viewed.

✎This function is available only when the is Channel Lock

set to .On

✎The PIN input screen appears. Enter your 4-digit PIN, the

default of which is “0-0-0-0”. Change the PIN using the

Change PIN option.

■

Select All / Deselect All: You can select or deselect all channels

in the channel list.

■

Auto Store: Scans for a channel automatically and stores in the

TV.

Display Modes (HDMI/DVI Input)

Optimal resolution is 1366 X 768 @ 60 Hz.

Mode Resolution

Horizontal

Frequency

(KHz)

Vertical

Frequency

(Hz)

Pixel Clock

Frequency

(MHz)

Sync Polarity

(H / V)

IBM 640 x 350 31.469 70.086 25.175 +/-

720 x 400 31.469 70.087 28.322 -/+

MAC 640 x 480 35.000 66.667 30.240 -/-

832 x 624 49.726 74.551 57.284 -/-

VESA DMT

640 x 480 31.469 59.940 25.175 -/-

640 x 480 37.861 72.809 31.500 -/-

640 x 480 37.500 75.000 31.500 -/-

800 x 600 37.879 60.317 40.000 +/+

800 x 600 48.077 72.188 50.000 +/+

800 x 600 46.875 75.000 49.500 +/+

1024 x 768 48.363 60.004 65.000 -/-

1024 x 768 56.476 70.069 75.000 -/-

1024 x 768 60.023 75.029 78.750 +/+

1280 x 720 45.000 60.000 74.250 +/+

1366 x 768 47.712 59.790 85.500 +/+

Installing batteries (Battery size: AAA)

✎NOTE

xUse the remote control within 23 feet from TV.

xBright light may affect the performance of the remote control.

Avoid using nearby special fluorescent light or neon signs.

xThe Colour and shape may vary depending on the model.

Alternately select Teletext ON, Double, Mix or OFF. Returns to the previous channel.

Press to directly access to channels.

Turns the TV on and off. Displays and selects the available video

sources.

Use these buttons in a speciﬁc feature.

P.MODE: Selects the picture mode.

P.SIZE: Selects the picture size.

SRS: Turns the SRS TruSurround on and off.

Cuts off the sound temporarily.

Selects the HDMI mode directly.

Displays the main on-screen menu.

Displays information on the TV screen.

Quickly select frequently used functions.

Selects the on-screen menu items and changes the

values seen on the menu.

Exits the menu.

Returns to the previous menu.

Use these buttons according to the

direction on screen.

Changes channels.

Views the Media Play.

Adjusts the volume.

A B C D

P.MODE P.SIZE

SRS

MEDIA.P

HDMI

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products,

please contact the SAMSUNG customer care Centre.

Country Customer Care Centre Web Site

AUSTRALIA 1300 362 603 www.samsung.com

NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com

CHINA 400-810-5858 www.samsung.com

HONG KONG (852) 3698-4698

www.samsung.com/

hk_en/

INDIA

1800 1100 11

3030 8282

1800 3000 8282

1800 266 8282

www.samsung.com

INDONESIA 0800-112-8888

021-5699-7777 www.samsung.com

JAPAN 0120-327-527 www.samsung.com

MALAYSIA 1800-88-9999 www.samsung.com

PHILIPPINES

1-800-10-SAMSUNG(726-7864) for

PLDT

1-800-3-SAMSUNG(726-7864) for

Digitel

1-800-8-SAMSUNG(726-7864) for

Globe

02-5805777

www.samsung.com

SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com

THAILAND 1800-29-3232

02-689-3232 www.samsung.com

TAIWAN 0800-329-999

0266-026-066 www.samsung.com

VIETNAM 1 800 588 889 www.samsung.com

HDMI OUT

AUDIO OUT

R-AUDIO-L

VIDEO OUT

W R BR

R W R B G

W YR

R W Y

AUDIO OUT

R-AUDIO-L

COMPONENT OUT

P P YR B

ANT OUT

DVI OUT

R - AUDIO - L

VIDEO

COMPONENT / AV IN

VCR Blu-ray player

Power Input

TV Rear Panel

TV Side Panel

AV Device (2)

Using an Audio/Video

AV Device (3)

Using a Component Cable

(up to 1080p)

Media Play

Using a USB Drive

Using a HDMI (to DVI) Cable

Blu-ray player / DVD / cable box / set top box

AV Device (1)

Using a HDMI Cable (up to 1080p)

VHF/UHF Antenna

Cable

Changing the Input Source

Source List

Use to select TV or other external input sources such as DVD / Blu-

ray players / cable box / STB satellite receiver connected to the TV.

1. Press the button.SOURCE

2. Select a desired external input source.

■

TV / AV / Component / HDMI1/DVI / HDMI2

✎You can only choose external devices that are connected to the

TV. In the , connected inputs will be highlighted.Source List

How to use Edit Name

Edit Name lets you associate a device name to an input source. To

access , press the button in Edit Name TOOLS Source List. The

following selections appear under :Edit Name

■

VCR / DVD / Cable STB / Satellite STB / PVR STB / AV

Receiver / Game / Camcorder / PC / DVI PC / DVI / TV / IPTV

/ Blu-ray / HD DVD / DMA: Name the device connected to the

input jacks to make your input source selection easier.

✎When connecting a PC to the port with HDMI HDMI IN 1(DVI)

cable, you should set the TV to mode under .PC Edit Name

✎When connecting a PC to the port with HDMI HDMI IN 1(DVI)

to DVI cable, you should set the TV to mode under DVI PC Edit

Name.

✎When connecting an AV devices to the port HDMI IN 1(DVI)

with HDMI to DVI cable, you should set the TV to DVI mode

under Edit Name.

Information

You can see detailed information about the selected external device.

✎Information only available for the current connected source.

* It may differ depending on the model.

✎The earphone jack supports only the 3

conductor tip-ring-sleeve (TRS) type.

BN68-04002A-04

Displays channel lists on the screen.

- 2 -- 1 -

- 6 -- 5 -

- 3 -

- 7 -

- 4 -

- 8 -

Photos

E L T Pause Previous/Next Tools ReturnR

Normal

1. PhotosPress the or button to select ◄ ► , then press the

ENTER

button in the menu.Media Play

2. Press the / / / button to select the desired photo in the ﬁle ◄►▲▼

list.

3. Press the ENTER

button or



(Play) button.

✎NOTE

xWhile a photo list is displayed, press the



(Play) / ENTER

button on the remote control to start the slide show.

xAll files in the file list section will be displayed in the slide show.

xDuring the slide show, files are displayed in order.

xDuring the slide show, you can adjust the slide show speed using

(



) (REW) or (

) (FF) button.

xYou can move to other file using or button.◄ ►

✎Music files can be automatically played during the Slide Show if

the is set to .Background Music On

✎The in cannot be changed until theMode Background Music

BGM has finished loading.

ySupported Photo Formats

Image Photo Resolution

JPEG Base-line 15360 x 8704

Progressive 1024 x 768

Other Restrictions

yCMYK, YCCK Colour space JPEG are not supported.

Playing Multiple Files

■

Playing selected video/music/photo ﬁles

1. Press the Yellow button in the ﬁle list to select the desired ﬁle.

2. Repeat the above operation to select multiple ﬁles.

✎NOTE

xThe

mark appears to the left of the selected files.

xTo cancel a selection, press the Yellow button again.

xTo deselect all selected files, press the button and select TOOLS

Deselect All.

3. Press the button, and then select TOOLS Play Selected

Contents.

■

Playing the video/music/photo ﬁle group

While a ﬁle list is displayed, move to any ﬁle in desired group.

Media Play - Additional Functions

■

Videos/Music/Photos Play Option menus

When playing a ﬁle, press the button.TOOLS

Category Operation Videos Music Photos

Title You can move the other ﬁle directly.

Repeat Mode You can play movie and music ﬁles

repeatedly.

c c

Picture Size You can adjust the picture size to your

preference.

Picture Mode You can adjust the picture setting.

c c

Sound Mode You can adjust the sound setting.

ccc

Subtile Setting

You can play the video with Subtitles. This

function only works if the subtitles are the

same ﬁle name as the video.

Audio Language You can change the audio language if the

video has more than one language.

Stop Slide

Show /

Start Slide Show

You can start or stop a Slide Show.

Slide Show

Speed

You can select the slide show speed during

the slide show.

Background

Music

You can set and select background music

when watching a Slide Show.

Zoom You can zoom into images in full screen

mode.

Rotate You can rotate images in full screen mode.

Information You can see detailed information about

the played ﬁle.

ccc

Settings

Using the Setup Menu

■

DivX® Video On Demand : Shows the registration code

authorized for the TV. If you connect to the DivX web site and

activation ﬁle. Once you play it using , the registration Media Play

is completed.

✎For more information on DivX® VOD, visit http://vod.divx.

com.

■

Information: Select to view information on the connected device.

Speciﬁcations

Display Resolution 1366 X 768

Environmental Considerations

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

50°F to 104°F (10°C to 40°C)

10% to 80%, non-condensing

-4°F to 113°F (-20°C to 45°C )

5% to 95%, non-condensing

Model Name UA26EH4000 UA32EH4000 / UA32EH4030

Screen Size inches inches26 32

Sound Output 5W x 2 10W x 2

Dimensions (W x D x H)

Body

With stand

615.1 X 93.3 X 365.6 (mm)

615.1 X 180.7 X 419.2 (mm)

738.8 X 93.3 X 436.7 (mm)

738.8 X 191.7 X 493.3 (mm)

Weight

Without Stand

With Stand

4.2 kg

4.7 kg

5.7 kg

6.3 kg

✎Design and specifications are subject to change without prior notice.

✎For information about power supply, and more about power consumption, refer to the label attached to the product.

ySupported Subtitle Formats

- External

Name File extension

MPEG-4 timed text .ttxt

SAMI .smi

SubRip .srt

SubViewer .sub

Micro DVD .sub or .txt

SubStation Alpha .ssa

Advanced SubStation Alpha .ass

- Internal

Name Container Format

Xsub AVI Picture Format

SubStation Alpha MKV Text Format

Advanced SubStation Alpha MKV Text Format

SubRip MKV Text Format

MPEG-4 Timed text MP4 Text Format

ySupported Video Formats

File

Extension Container Video Codec Resolution Frame

rate(fps) Bit rate(Mbps) Audio Codec

*.mp4 MP4

DivX 3.11/4.x/5.1/6.0 1920x1080 6~30 30Mbps

MP3 / ADPCM

/ AAC

H264 1920x1080 6~30 30Mbps

AVC 1920x1080 6~30 30Mbps

MJPEG 640x480 6~30 10Mbps

*.avi

*.mkv"

"AVI

MKV"

DivX 3.11/4.x/5.1/6.0 1920x1080 6~30 30Mbps

MP3 / AC3 /

LPCM / ADPCM

/ DTS Core

MPEG4 SP / ASP 1920x1080 6~30 30Mbps

H264 1920x1080 6~30 30Mbps

MJPEG 640x480 6~30 10Mbps

*.asf

*.wmv ASF

DivX 3.11 / 4.x /5.1 / 6.0 1920x1080 6~30 30Mbps MP3 / AC3

/ LPCM /

ADPCM / WMA /

WMA Pro

MPEG4 SP / ASP 1920x1080 6~30 30Mbps

H.264 1920x1080 6~30 30Mbps

*.ts

*.trp

*.tp

*.m2ts

MPEG2 1920x1080 6~30 30Mbps AC3 / AAC /

MP3 / DD+ /

HE-AAC

H. 264 BP / MP / HP 1920x1080 6~30 30Mbps

*.dat

*.mpg

*.mpeg

*.vob

MPEG1 1920x1080 24/25/30 30Mbps

AC3 / MPEG /

LPCM / AAC

MPEG2 1920x1080 24/25/30 30Mbps

H. 264 BP / MP / HP 1920x1080 6~30 30Mbps

*.3gp 3GPP MPEG4 SP / ASP 1920x1080 6~30 30Mbps MP3

H.264 1920x1080 6~30 30Mbps

*.ﬂv

*.swf ﬂash formats H.264 1920x1080 6~30 30Mbps MP3

Sorenson H.263 1920x1080 6~30 30Mbps

Other Restrictions

✎NOTE

yVideo content will not play, or not play correctly, if there is an error

in the content or the container.

ySound or video may not work if the contents have a standard bit

rate/ frame rate above the compatible Frame/sec listed in the table

above.

yIf the Index Table is in error, the Seek (Jump) function is not

supported.

yThe menu may take longer to appear if the video’s bit rate exceeds

10Mbps.

yVideo content can not be played, if there are many contents in one

ﬁle.

Video Decoder

Supports up to H.264, Level 4.1

H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are not supported.

MPEG4 SP, ASP :

– Below 1280 x 720: 60 frame max

– Above 1280 x 720: 30 frame max

H.263 is not supported.

GMC is not support.

Audio Decoder

Supports up to WMA7, 8, 9 STD, 9 PRO, 10 PRO

WMA 9 PRO and WMA 10 PRO support 5.1 channel. (LBR mode of WMA Pro is not

supported)

WMA Lossless is not supported.

Music

3/15

I Love you

Jhon

Music 1

No Singer

Music 2

No Singer

Music 3

No Singer

Music 4

No Singer

Music 5

No Singer

I Love You

Jhon

1st Album

Pop

2010

4.2MB

01:10 / 04:02

SUM

E Pause Jump Tools ReturnL T R

Playlist

1. MusicPress the or button to select ◄ ► , then press the

ENTER

button in the menu.Media Play

2. Press the / / / button to select the desired Music in the ﬁle ◄►▲▼

list.

3. Press the ENTER

button or (Play) button.

✎During music playback, you can search using the and ◄ ►

button.

✎



(REW) and

(FF) buttons do not function during play.

✎Only displays the files with MP3 and PCM file extension. Other

file extensions are not displayed, even if they are saved on the

same USB device.

✎If the sound is abnormal when playing MP3 files, adjust the

Equalizer Sound in the menu. (An over-modulated MP3 file

may cause a sound problem.)

Assembling the Holder-Wire stand

Storage and Maintenance

✎If you remove the attached sticker on the TV screen, clean the residues and then watch TV.

Do not spray water directly onto the product. Any liquid that goes into the

product may cause a failure, ﬁre, or electric shock.

Clean the product with a soft cloth dampened with in a small amount of water.

Do not use a ﬂammable liquid (e.g. benzene, thinners) or a cleaning agent.

Licence

Other Information

Installing the Wall Mount Kit

The wall mount kit (sold separately) allows you to mount the TV on

the wall. For detailed information on installing the wall mount, see

the instructions provided with the wall mount. Contact a technician

for assistance when installing the wall mount bracket.

Samsung Electronics is not responsible for any damage to the

product or injury to yourself or others if you elect to install the TV

on your own.

Wall Mount Kit Speciﬁcations (VESA)

✎The wall mount kit is not supplied, but sold separately.

Install your wall mount on a solid wall perpendicular to the ﬂoor.

When attaching to other building materials, please contact your

nearest dealer. If you install the TV on a ceiling or slanted wall, it

may fall and result in severe personal injury.

✎NOTE

xStandard dimensions for wall mount kits are shown in the table

below.

xWhen purchasing our wall mount kit, a detailed installation

manual and all parts necessary for assembly are provided.

xDo not use screws that do not comply with the VESA standard

screw specifications.

xDo not use screws longer than the standard dimension, as they

may cause damage to the inside of the TV set.

xFor wall mounts that do not comply with the VESA standard

screw specifications, the length of the screws may differ

depending on the wall mount specifications.

xDo not fasten the screws too firmly. This may damage the

product or cause the product to fall, leading to personal injury.

Samsung is not liable for these kinds of accidents.

xSamsung is not liable for product damage or personal injury

when a non-VESA or non-specified wall mount is used or the

consumer fails to follow the product installation instructions.

xDo not mount the TV at more than a 15 degree tilt.

xAlways have two people mount the TV on a wall.

Product

Family

TV size in

inches

VESA scew hole specs

(A * B) in millimeters

Standard

Screw Quantity

LED-TV

19~22 75 X 75

26 100 X 100

32~40 200 X 200 M6

46~60 400 X 400 M8

Do not install your Wall Mount Kit

while your TV is turned on. It may

result in personal injury due to

electric shock.

Securing the TV to the Wall

Caution: Pulling, pushing, or climbing onto the TV

may cause the TV to fall. In particular, ensure that your

children do not hang over or destabilize the TV; doing

so may cause the TV to tip over, resulting in serious

injuries or death. Follow all safety precautions provided

on the included Safety Flyer. For added stability, install

the anti-fall device for safety purposes, as follows.

To prevent the TV from falling

✎Since the necessary clamps, screws, and string are not

supplied, please purchase these additionally.

1. Put the screws into the clamps and ﬁrmly fasten them onto the

wall. Conﬁrm that the screws have been ﬁrmly installed onto the

wall.

✎You may need additional material such as an anchor

depending on the type of wall.

✎Since the necessary clamps, screws, and string are not

supplied, please purchase these additionally.

2. Remove the screws from the back Centre of the TV, put the

screws into the clamps, and then fasten the screws onto the TV

again.

✎Screws may not be supplied with the product. In this case,

please purchase the screws of the following specifications.

3. Connect the clamps ﬁxed onto the TV and the clamps ﬁxed onto

the wall with a strong cable and then tie the string tightly.

✎Note

xInstall the TV near to the wall so that it does not fall

backwards.

xIt is safe to connect the string so that the clamps fixed on

the wall are equal to or lower than the clamps fixed on the

TV.

xUntie the string before moving the TV.

4. Verify all connections are properly secured. Periodically check

connections for any sign of fatigue for failure. If you have

any doubt about the security of your connections, contact a

professional installer.

Kensington Lock

The Kensington Lock is not supplied by Samsung. It is a device

used to physically ﬁx the system when using it in a public place.

Refer to the manual provided with the Kensington Lock for

additional information on proper use.

✎Please find a “

” icon on the rear of the TV. The Kensington

slot is beside the “

” icon.

✎The position and colour may differ depending on the model.

To lock the product, follow these steps:

1. Wrap the Kensington lock cable around a large, stationary object

such as desk or chair.

2. Slide the end of the cable with the lock attached through the

looped end of the Kensington lock cable.

3. Insert the locking device into the Kensington slot on the product.

4. Lock the lock.

✎These are general instructions. For exact instructions, see the

User manual supplied with the locking device.

✎The locking device has to be purchased separately.

✎The location of the Kensington slot may be different

depending on the TV model.

Troubleshooting

If you have any questions about the TV, ﬁrst refer to this list. If none of these troubleshooting tips apply, please visit “www.samsung.com,”

then click on Support, or contact the call centre listed on the back-cover of this manual.

Problem Possible Solution

Picture Quality

The TV image does not look as good as

it did in the store.

• If you have an analogue cable/set top box, upgrade to a digital set top box. Use HDMI or Component cables to

deliver HD (high deﬁnition) picture quality.

• Cable/Satellite subscribers: Try HD stations from the channel line up.

• Antenna connection: Try HD stations after performing Auto tuning.

✎Many HD channels are up scaled from SD(Standard Definition) contents.

• Adjust the Cable/Set top box video output resolution to 1080i or 720p.

• Make sure you are watching the TV at the minimum recommended distance based on the size and deﬁnition of

the signal.

The picture is distorted: macroblock

error, small block, dots, pixelization

• Compression of video contents may cause picture distortion especially in fast moving pictures such as sports and

action movies.

• Low signal level or bad quality can cause picture distortion. This is not a TV issue.

• Mobile phones used close to the TV (cca up to 1m) may cause noise in picture on analogue and digital TV.

Colour is wrong or missing. If you’re using a component connection, make sure the component cables are connected to the correct jacks. •

Incorrect or loose connections may cause colour problems or a blank screen.

There is poor colour or brightness. Adjust the • Picture options in the TV menu. (go to Picture mode / Colour / Brightness / Sharpness)

• Adjust Energy Saving option in the TV menu. (go to - MENU Setup Eco Solution Energy Saving - - )

• Try resetting the picture to view the default picture settings. (go to MENU - Picture - Picture Reset)

There is a dotted line on the edge of

the screen.

• If the picture size is set to Screen Fit, change it to .16:9

• Change cable/satellite box resolution.

The picture is black and white. If you are using an AV composite input, connect the video cable (yellow) to the Green jack of component input 1 •

on the TV.

When changing channels, the picture

freezes or is distorted or delayed.

• If connected with a cable box, please try to reset the cable box. Reconnect the AC cord and wait until the cable

box reboots. It may take up to 20 minutes.

• Set the output resolution of the cable box to 1080i or 720p.

Sound Quality

There is no sound or the sound is too

low at maximum volume.

• Please check the volume the of external device connected to your TV.

The picture is good but there is no

sound.

• Set the Speaker Select option to TV Speaker in the sound menu.

• If you are using an external device, make sure the audio cables are connected to the correct audio input jacks on

the TV.

• If you are using an external device, check the device’s audio output option (ex. you may need to change your

cable box’s audio option to HDMI when you have a HDMI connected to your TV).

• If you are using a HDMI cable, a separate audio cable is required.

• If your TV has a headphone jack, make sure there is nothing plugged into it.

The speakers are making an

inappropriate noise.

• Check the cable connections. Make sure a video cable is not connected to an audio input.

• For antenna or cable connections, check the signal strength. Low signal level may cause sound distortion.

No Picture, No Video

The TV will not turn on. Make sure the AC power cord is securely plugged in to the wall outlet and the TV.•

• Make sure the wall outlet is working.

• Try pressing the POWER button on the TV to make sure the problem is not the remote. If the TV turns on, refer to

“The remote control does not work” below.

The TV turns off automatically. Ensure the • Sleep Timer is set to in the menu. Off Time

• If your PC is connected to the TV, check your PC power settings.

• Make sure the AC power cord is plugged in securely to the wall outlet and the TV.

• When watching TV from an antenna or cable connection, the TV will turn off after 10 ~ 15 minutes if there is no

signal.

There is no picture/video. Check cable connections (remove and reconnect all cables connected to the TV and external devices).•

• Set your external devices’ (Cable/Set top Box, DVD, Blu-ray etc) video outputs to match the connections to the

TV input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input on the TV.

• Make sure your connected devices are powered on.

• Be sure to select the TV’s correct source by pressing the button on the TV remote.SOURCE

Problem Possible Solution

RF(Cable/Antenna) Connection

The TV is not receiving all channels. Make sure the Antenna cable is connected securely.•

• Please try Plug & Play (Initial setup) to add available channels to the channel list. Go to MENU - Setup - Plug &

Play (Initial setup) and wait for all available channels to be stored.

• Verify the Antenna is positioned correctly.

The picture is distorted: macroblock

error, small block, dots, pixelization

• Compression of video contents may cause picture distortion, especially on fast moving pictures such as sports

and action movies.

• A low signal can cause picture distortion. This is not a TV issue.

PC Connection

A “Mode Not Supported” message

appears.

• Set your PC’s output resolution so it matches the resolutions supported by the TV.

The video is OK but there is no audio. If you are using a HDMI connection, check the audio output setting on your PC.•

Others

The picture will not display in full screen. HD channels will have black bars on either side of the screen when displaying up scaled SD (4:3) contents.•

• Black bars on the top and bottom will appear during movies that have aspect ratios different from your TV.

• Adjust the picture size options on your external device or TV to full screen.

The remote control does not work. Replace the remote control batteries with the poles (+/–) in the right direction.•

• Clean the transmission window located on the top of the remote control.

• Try pointing the remote directly at the TV from 5~6 feet away.

The cable/set top box remote control

does not turn the TV on or off, or adjust

the volume.

• Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/Set top box user manual

for the SAMSUNG TV code.

A “Mode Not Supported” message

appears.

• Check the supported resolution of the TV, and adjust the external device’s output resolution accordingly. Refer to

resolution settings in this manual.

There is a plastic smell from the TV. This smell is normal and will dissipate over time.•

TV is tilted to the right or left side. Remove the stand base from the TV and reassemble it.•

There are difﬁculties assembling the

stand base.

• Make sure the TV is placed on a ﬂat surface. It is necessary to use magnetized screw driver if you cannot remove

the screws from the TV.

The Channel menu is grey out

(unavailable).

• The menu is only available when the TV source is selected. Channel

Your settings are lost after 30 minutes or

every time the TV is turned off.

• If the TV is in the Store Demo mode, it will reset audio and picture settings every 30 minutes. Change the settings

from Store Demo mode to Home Use mode in the Plug & Play (Initial setup) procedure. Press the SOURCE

button to select mode, go to TV MENU →Setup Plug & Play → (Initial setup) →ENTER

You have intermittent loss of audio or

video.

• Check the cable connections and reconnect them.

• Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are ﬂexible

enough for long term use. If mounting the TV to the wall, we recommend using cables with 90 degree

connectors.

You see small particles when you look

closely at the edge of the frame of

the TV.

• This is part of the product’s design and is not a defect.

There are recurrent picture/sound issues. Check and change the signal/source.•

A reaction may occur between the

rubber cushion pads on the base stand

and the top ﬁnish of some furniture.

• To prevent this, use felt pads on any surface of the TV that comes in direct contact with furniture.

✎This TFT LED panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However, there may be a few bright or dark

pixels on the screen. These pixels will have no impact on the performance of the product.

✎You can keep your TV as optimum condition to upgrade the latest firmware on web site (samsung.com Support Downloads) by USB.→ →

Media Play

Enjoy photos, music and/or movie ﬁles saved on a

USB Mass Storage Class (MSC) device.

MEDIA.P

Connecting a USB Device

1. Turn on your TV.

2. Connect a USB device containing photo, music and/or movie

ﬁles to the jack on the side of the TV.USB

3. When USB is connected to the TV, you can select . Media Play

Using the Media Play Menu

SUM

▒

Change Device

E R Enter Return

Media Play

Videos

1. Press the MENU button. Press the or button to select ▲ ▼

Application, then press the ENTER

button.

2. Media Play (USB) Press the or button to select ▲ ▼ , then

press the ENTER

button.

3. Videos, Music, Press the or button to select an icon (◄ ►

Photos, Settings), then press the ENTER

button.

✎It might not work properly with unlicenced multimedia files.

✎If you want to view detailed information of the file or

connected device, press button in the file list, and TOOLS

then select or .Detailed Information Device Information

✎Need-to-Know List before using Media Play (USB)

xThe file system supports FAT16, FAT32 and NTFS.

xCertain types of USB Digital camera and audio devices may not

be compatible with this TV.

xMedia Play only supports USB Mass Storage Class (MSC)

devices. MSC is a Mass Storage Class Bulk-Only Transport

device. Examples of MSC are Thumb drives and Flash Card

Readers. Devices should be connected directly to the TV’s USB

port. USB HDD is not supported.

xBefore connecting your device to the TV, please back up your

files to prevent them from damage or loss of data. SAMSUNG is

not responsible for any data file damage or data loss.

xA USB device that requires high power (more than 0.5A) may

not be supported.

xDo not disconnect the USB device while it is loading.

xThe higher the resolution of the image, the longer it takes to

display on the screen.

xThe maximum supported JPEG resolution is 15360 x 8640

pixels.

xIf a file is corrupted or the TV does not support the file type, the

“Not Supported File Format” message appears.

xIf a USB extension cable is used, the USB device may not be

recognized or the files on the device may not be read.

xThe TV cannot play MP3 files with DRM that have been

downloaded from a for-pay site. Digital Rights Management

(DRM) is a technology that supports the creation, distribution,

and management of digital content in an integrated and

comprehensive way, including protecting the rights and

interests of content providers, preventing illegal copying of

contents, and managing billings and settlements.

xPTP device is not supported.

xIf an over-power warning message is displayed while you are

connecting or using a USB device, the device may not be

recognized or may malfunction.

xIf the TV has no input during the time set in Auto Protection

Time, the Screensaver will run.

xThe power-saving mode of some external hard disk drives may

be released automatically when your connect them to the TV.

xIf a USB device connected to the TV is not recognized, the

list of files on the device is corrupted, or a file in the list is not

played, connect the USB device to a PC, format the device, and

check the connection.

xIf a file you deleted from the PC is still found when you run

Media Play, use the “Empty the Recycle Bin” function on the

PC to permanently delete the file.

xPhotos only supports sequential jpeg format.

xThe scene search and thumbnail functions are not supported

in the . Videos

xIf the number of files and folders saved on a USB storage

device is approximately over 4000, the files and folders may not

appear and some folders may not be opened.

xThe maximum displayed number of files, including sub folders,

►1/1

Movie 01.avi

E Pause

L Jump T Tools R Return

1. VideosPress the or button to select ◄ ► , then press the

ENTER

button in the menu.Media Play

2. Press the / / / button to select the desired video in the ◄►▲▼

ﬁle list.

3. Press the ENTER

button or



(Play) button.

- The selected file is displayed on the top with its playing

time.

- If video time information is unknown, playing time and the

progress bar are not displayed.

- During video playback, you can search using the and ◄

► button.

- You can use (



) (REW) and (

) (FF) buttons during

playback.

✎In this mode, you can play movie clips contained in a game,

but you cannot play the game itself.

TheaterSound, SRS and the symbol are

trademarks of SRS Labs, Inc.

TheaterSound technology is incorporated under

licence from SRS Labs, Inc.

SRS TheaterSound™ provides the most immersive

surround sound experience from the TVs built-in

speakers, while maintaining steady volume and

delivering rich bass and clear dialog.

DivX Certiﬁed to play DivX video up to HD 1080p,

including premium content.

ABOUT DIVX VIDEO: DivX® is a digital video

format created by DivX, LLC, a subsidiary of Rovi

Corporation. This is an ofﬁcial DivX Certiﬁed®

device that plays DivX video. Visit divx. com for

more information and software tools to convert your

ﬁles into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX

Certiﬁed® device must be registered in order to

play purchased DivX Video-on-Demand (VOD)

movies. To obtain your registration code, locate

the DivX VOD section in your device setup menu.

Go to vod.divx.com for more information on how

to complete your registration. Covered by one or

more of the following U.S. patents : 7,295,673;

7,460,668; 7,515,710; 7,519,274

DivX®, DivX Certiﬁed® and associated logos are

trademarks of Rovi Corporation or its subsidiaries

and are used under license.

Manufactured under Licence from Dolby

Laboratories. Dolby and the double-D symbol are

trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent

Nos: 5,956,674; 5,974,380; 6,487,535 & other

U.S. and worldwide patents issued & pending.

DTS, the Symbol, & DTS and the Symbol together

are registered trademarks & DTS 2.0 Channel is a

trademark of DTS, Inc.

The terms HDMI and HDMI High-Deﬁnition

Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other

countries.

Open Source Licence Notice

Open Source used in this product can be found on the following webpage.

(http://opensource.samsung.com) Open Source Licence Notice is written

only English.

To send inquiries and requests for questions regarding open sources,

contact Samsung via Email (oss.request@samsung.com).

■

This product uses some software programs which are distributed under

the Independent JPEG Group.

ICU License - ICU 1.8.1 and later

Permission is hereby granted, free of charge, to any person obtaining a

copy of this software and associated documentation ﬁles (the "Software"),

to deal in the Software without restriction, including without limitation

the rights to use, copy, modify, merge, publish, distribute, and/or sell

copies of the Software, and to permit persons to whom the Software is

furnished to do so, provided that the above copyright notice(s) and this

permission notice appear in all copies of the Software and that both the

above copyright notice(s) and this permission notice appear in supporting

documentation.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY

KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE

WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR

PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO

EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS INCLUDED IN

THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT

OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES WHATSOEVER

RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN

AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS

ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR

PERFORMANCE OF THIS SOFTWARE.

Except as contained in this notice, the name of a copyright holder shall

not be used in advertising or otherwise to promote the sale, use or other

dealings in this Software without prior written authorization of the copyright

holder.

All trademarks and registered trademarks mentioned herein are the

property of their respective owners.

- 10 -- 9 -

- 14-- 13 -

- 11 -

- 15 -

- 12 -

- 16 -

Specyfikacje produktu

Marka:	Samsung
Kategoria:	Niesklasyfikowane
Model:	UA32EH4030R

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Samsung UA32EH4030R, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje Niesklasyfikowane Samsung

Samsung HG32AJ570NK Instrukcja

13 Października 2024

Samsung NA64H3010CK Instrukcja

9 Października 2024

Samsung UN28K4000AF Instrukcja

9 Października 2024

Samsung UE32N4010AU Instrukcja

9 Października 2024

Samsung RH22H8010SR Instrukcja

9 Października 2024

Samsung RH65DG54R3B1 Instrukcja

9 Października 2024

Samsung RR20R182ZCB Instrukcja

8 Października 2024

Samsung RR21J2835SZ Instrukcja

8 Października 2024

Samsung RR21T2G2YDU Instrukcja

8 Października 2024

Samsung RR21T2H2WCB Instrukcja

8 Października 2024

Instrukcje Niesklasyfikowane

Najnowsze instrukcje dla Niesklasyfikowane

Black Diamond BD1121530000ALL1 Instrukcja

15 Października 2024

Husqvarna K 970 SmartGuard Instrukcja

15 Października 2024

Stihl HT 70 Instrukcja

15 Października 2024

Ernesto H14270 Instrukcja

15 Października 2024

Uniden BT MIC KIT Instrukcja

15 Października 2024

Vaude Omnis Bike 26 Instrukcja

15 Października 2024

ART ProChannel II Instrukcja

15 Października 2024

Aukey DR02J Instrukcja

15 Października 2024

Master Lock 653EURD Instrukcja

15 Października 2024

Roland FR-18 Diatonic Instrukcja

15 Października 2024
