Installation & Operation
RFX3-K4 • RFX3-K8
CAN-AM A 3® M VERICK X
AMPLIFIER
IN ALST LA TTION KI
R O F O F O S G A T C O MC K R D E .
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
Installation assistance available at:
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of
audio products. At Rockford Fosgate we are fanatics about musical
reproduction at its best, and we are pleased you chose our product.
Through years of engineering expertise, hand crasmanship and critical
testing procedures, we have created a wide range of products that
reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new
Rockford Fosgate product installed by an Authorized Rockford Fosgate
Dealer, as we provide specialized training through Rockford Technical
Training Institute (RTTI). Please read your warranty and retain your
receipt and original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! Aer all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Contents
If, aer reading your manual, you still have questions regarding this
product, we recommend that you see your Rockford Fosgate dealer.
If you need further assistance, you can call us direct at 1-800-669-
9899. Be sure to have your serial number, model number and date of
purchase available when you call.
Safety
This symbol with “WARNING” is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with “CAUTION” is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
can result in injury or unit damage.
• To prevent injury and damage to the unit, please read and
follow the instructions in this manual. We want you to enjoy
this system, not get a headache.
• If you feel unsure about installing this system yourself, have
it installed by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-)
terminal to prevent damage to the unit, fire and/or possible
injury.
Contents
Installation Tools
The following is a list of suggested tools needed for installation:
Introduction
©2017 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered
trademarks of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective
owners. Specifications subject to change without notice.
2Introduction
3Installation
4Warranty
• Small Flat Blade Screwdriver
• Large Ratchet
• Metric Sockets
• Metric Nutdrivers
• Metric Wrenches
• Torx Driver
• 2.5 mm Allen Driver
• Wire Cutters
• Panel Tool
• (1) Amplifier Bracket
• (2) Bracket Clamp Halves
• (1) Wire Harnesses
• Mounting Hardware
• Plastic Wire Tie Wraps
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB
may cause permanent hearing loss. High powered auto
sound systems may produce sound pressure levels well
over 130dB. Use common sense and practice safe sound.
3
Installation Considerations
This section focuses on some considerations for installing your Can-Am
Maverick X3 amplifier installation kit. This kit is designed to work in
conjunction with Rockford’s other X3 specific audio kits and parts.
If you feel unsure about installing this system yourself, have it installed
by a qualified technician.
When drilling holes, make sure what is on the other side. Be sure that
any electrical, fuel lines or any other important components are free
and clear from the area.
Before installation, disconnect the battery
negative (-) terminal to prevent damage to
the unit, fire and/or possible injury.
Before beginning any installation, follow
these simple rules:
Be sure to carefully read and understand the
instructions before attempting to install this
wiring kit.
• Consult your UTV’s service manual for model specific information.
• This amplifier installation kit is specifically designed to work with
Rockford Fosgate’s compact chassis amplifiers.
• With the addition of an amplifier or source unit, be sure that your
current charging system is in proper working order.
• Visit rockfordfosgate.com for more comprehensive product
information.
• Visit our YouTube channel for comprehensive installation videos
demonstrating complete installation guides and install tips.
Installation
Applicable Models:
Can-Am Maverick X3 (2 & 4 seat models)
This amplifier installation kit is designed to work with Rockford
Fosgate’s Maverick X3 specific enclosures and dash kits. The amp kit
steering column.
Step 1. Remove the driver side top dash panel using your Torx tool.
Step 2.
the front of the panel.
Step 3. Remove the seat(s) on the passenger side of the vehicle using
a ratchet and socket.
NOTE: On 4 seat models, both passenger side seats will need removed.
Step 4. Remove the access panels on the passenger side of the center
console.
NOTE: 2 seat models will have 3 panels to remove and the 4 seat models
will have 4.
Step 5. Mount the amplifier bracket to the vehicle’s chassis tube just
steering unit. The bracket will be secured with the supplied
clamp system.
Step 6. Mount the amplifier to the bracket once the bracket is secured
to the vehicle.
TM400X4ad mounting shown above.
TM1000X5ad mounting shown above.
Step 7. Connect the power and ground to the battery terminals and
route the wire harness down the center console toward the
front of the vehicle.
NOTE: The connectors for the radio input will get routed through the
fuse cover opening while the power and amplifier harness get routed
toward the drivers side. Be sure to secure all wiring with the supplied
plastic wire ties.
Step 8. Plug the power/ground and input/output harnesses into the
amplifier.
Step 9. Connect input connector(s) from the radio.
Step 10. Once all connections have been made, be sure to test the
system and reassemble vehicle.
