Acoustic Design Series

Quick Start Guide

AD-C.SUB

AD-C.SAT

EXPLANATION OF SYMBOLS

The term “WARNING!” indicates instructions regarding personal safety. If the instructions are not followed the result may be bodily injury or death.

The term “CAUTION!” indicates instructions regarding possible damage to physical equipment. If these instructions are not followed, it may result in

damage to the equipment that may not be covered under the warranty.

The term “IMPORTANT!” indicates instructions or information that are vital to the successful completion of theprocedure.

The term "NOTE" is used to indicate additional useful information.

The intent of the lightning ﬂash with arrowhead symbol in a triangle is to alert the user to the presence of un-insulated "dangerous"

voltage within the product's enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to humans.

The intent of the exclamation point within a triangle is to alert the user to the presence of important safety, and operating and

maintenance instructions in this manual.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Clean only with a dry cloth.

6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

7. Only use attachments/accessories speciﬁed by the manufacturer.

8. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

9. Do not use this apparatus in or near water or liquids.

10. Do not use any aerosol spray, cleaner, disinfectant or fumigant on, near or into the apparatus.

11. Adhere to all applicable, local codes.

12. Consult a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.

Maintenance and Repair

Advance technology, e.g., the use of modern materials and powerful electronics, requires specially adapted maintenance and repair methods. To avoid

a danger of subsequent damage to the apparatus, injuries to persons and/or the creation of additional safety hazards, all maintenance or repair work

on the apparatus should be performed only by a QSC authorized service station or an authorized QSC International Distributor. QSC is not responsible

for any injury, harm or related damages arising from any failure of the customer, owner or user of the apparatus to facilitate those repairs.

Warranty

For a copy of the QSC Limited Warranty, visit the QSC website at www.qsc.com

TD-001556-01-A1

*TD-001556-01*

TD-001556-01-A1

Install the AD-C.SUB Subwoofer

What's in the AD-C.SUB Box

(1x)

AD-C.SUB

(1x)

Grille

(3x)

Euro-

style plug

(4-pole)

(1x)

C-Ring

(2x)

Tile Rail

Screws

(sheet metal)

(2x)

Tile Rails

(1x)

Cutout

Template

(1x)

Terminal Cover

(1x)

Warranty

TD-000453

(1x)

Quick Start

Guide

TD-001556

Prepare Ceiling

Refer to Figure 1.

1. Use the supplied Cut-Out template to cut a 12 inch (305 mm) diameter

hole (1) in the ceiling where the loudspeaker is to be installed. For frame-

construction ceiling, skip to "Wire the Loudspeakers".

2. Install two V-rails (2), one on each side of the hole, and supported by the

suspended-ceiling support rails (3).

3. Install the C-ring (4) over the hole, using the V-rails as support. Make sure the

clips on the C-ring are properly ﬁtted over the V-rail.

4. Use sheet-metal screws (5) to secure the C-ring to the V-rails.

Wire the Subwoofer

Refer to Figure 2.

1. Loosen the two screws (1) holding the wire-terminal cover

(2) to the body of the loudspeaker enclosure.

2. Pull the cover (2) up slightly in front, then pull away from

the enclosure.

3. Pass the wires through the conduit/stress-relief clamp

(3). Leave enough wire for making connections. Carefully

tighten the clamp (3) over the wires, or over the conduit if

it is used.

NOT: The wire-terminal cover has two

additional openings (4) that you can use if the

factory-selected opening causes conﬂict between

the wiring and the structure.

4. Wire the female Euro-style plugs as shown in Figure 3.

5. The Euro-style plugs are factory installed. If you remove

the connectors, make sure to re-tighten the screws

to secure the connections.

6. Slide the cover (2) over the connector and under the

two clips, then tighten the two Phillips screws.

Cut-Out Template

AD-C.SAT

— Figure 1 —

— Figure 2 —

— Figure 3 —

Input Thru Sat 1 Sat 2 Sat 3 Sat 4

Amp

TD-001556-01-A1

Mount the Subwoofer

Refer to Figure 5.

1. Use a small ﬂat-tip screwdriver, or similar tool, to carefully pry the grille off the

loudspeaker housing giving you access to the dog-ear screws. The grille is

held on by magnets.

2. Make sure all four of the dog ears are turned in, up against the side of the

metal loudspeaker housing. Figure 5 (1) shows turned in, (2) shows the

dogear not turned in.

NOTE: The dog ears can be turned in at two places only. One

accommodates up to 2-inch thick ceiling material, the other

accommodates 1.25-inch thick material. See Figure 4. Use the one

most suitable to your installation.

3. Slide the Loudspeaker Housing up through the hole into the ceiling. Make

sure that the wiring does not get pinched or caught on anything.

4. Use a Phillips screwdriver to tighten all four of the dog-ear screws. As you

tighten the screws, the dog ears swing away from the housing and over the

ceiling material. Before the dog ears are completely tightened, make sure all

dog ears are properly positioned over the ceiling material.

CAUTION!: Do not overtighten the dog-ear screws!

Seismic Safety

WARNING!: Be sure to check and adhere to local building

codes for seismic requirements. If in doubt, consult an appropriate

engineer. Regardless of local building codes, QSC recommends

that you use the appropriate safety tethers for the installation.

Refer to Figure 6.

1. Attach appropriate safety tethers (1) to the tether tabs (2), on the back of the

loudspeaker enclosure, and to an appropriate part of the building's structure.

Set the Operating Mode

Refer to Figure 7

1. Use a small coin, or similar tool, to set the transformer tap (1) based on the requirements of

theinstallation.

2. Install the loudspeaker grill / tether.

— Figure 4 —

2” (50 mm)

Max

1.25” (31 mm)

Max

— Figure 5 —

— Figure 6 —

— Figure 7 —

100

12.5

4Ω

100

25Ω

N/A

4Ω

100

12.5

4Ω

100

N/A

4Ω

70 Volts

100 Volts

Specyfikacje produktu

Marka:	QSC
Kategoria:	głośnik
Model:	AD-C.SUB
Kolor produktu:	Czarny
Wysokość produktu:	- mm
Szerokość produktu:	340 mm
Głębokość produktu:	254 mm
Waga produktu:	8700 g
Rekomendowane użycie:	Dom
Technologia łączności:	Przewodowa
Impedancja:	4 Ω
Moc wyjściowa (RMS):	100 W
Zakres temperatur (eksploatacja):	-20 - 50 °C
Kanały wyjścia audio:	- kan.
Rodzaj opakowania:	Pudełko
Stosunek sygnału do szumu:	106 dB
Zasięg częstotliwości:	45 - 15000 Hz
Rozmieszczenie głośników:	Możliwość montażu sufitowego
Ilość przetworników:	1
Czułość:	86 dB
Średnica sterownika średniego zasięgu (imperial):	6.5 "
Średnica mid-range:	165 mm
