Strona 1/50
RoadRunner 560 RoadRunner 560GPS
Inside your package Your device at a glance
CD-ROM
RESET
HDMI USB
MODEREC
HDMI
LED
Reset
AV out
1
Getting started Technical specifications
2
3
Display 3.0", 960 x 240 pixels
Processor Amarella A7LA30
Image sensor 4.0 MP CMOS 1/3"
View angle 170°
Video resolution 1920x1080(30 fps) HDR , 1920x1080(30 fps),
1280x720(60 fps), 1280x720(30 fps)
Video codec MP4 (H.264)
Picture format JPEG
Memory up to 64GB (microSD Class 6 or above,
SDHC/SDXC)
Microphone Built-in
Motion
Detection Yes
Power source Built-in battery, car charger
Interfaces HDMI, AV out, mini USB, GPS (optional)
Operating
temperature 0 °C ~ 45°C
Dimension 53 x 97 x 26.5 mm (H x W x D)
Weight 72 g
Quick Start Guide
Prestigio RoadRunner
EN
Getting started
Start recording
1. Insert a micro SD card (not included).
2. Connect the device to the car charger. When the car engine
starts, the device will begin loop recording.
Taking photos
• Press [ ] to select the picture mode, and then press MODE
[ ] to take photos.REC
Note:
• The italicized text in this quick start guide is only for the
GPS model.
• The GPS receiver is built in the suction mount. Please
connect the car charger to the USB port on the mount.
When the device is connected to the GPS signal, the icon
will be green.
Settings
In preview mode, press [ ] to enter settings. Use [ ]/[ ]
to navigate the menu.
Settings menu
• : Select the resolution of recorded video: Resolution
1920x1080(30 fps) HDR , 1920x1080(30 fps), 1280x720(60 fps),
1280x720(30 fps).
• : Set the video duration for loop Record overwrite
recording. When the micro SD card is full, the device will
delete the first unlocked video file automatically.
• Motion detection: Turn on or off motion detection. If there
is any motion detected while the car engine is stopped,
your car DVR will start recording automatically.
• : Set the DVR to start recording when Power on record
power on.
• : Select a time span for the DVR to power Power off delay
off when the car engine stops.
• : Select a time span for the DVR to power Power on delay
on when the car engine starts.
• G-sensor set: Select the sensitivity of the G-sensor.
• : Set the car plate/registration number if Car number set
necessary.
• : Add information stamp to videos/photos.Stamp
• GPS auto update time: Set the GPS to update the date/
time automatically.
• GMT setup: Select the local GMT (Greenwich Mean Time).
• GPS set up: Turn on or off GPS.
• : Turn on or off WDR (Wide Dynamic Range).WDR
• E-dog setup: Turn on or off E-dog.
Playback and media connection
Playback mode
In preview mode, press [ ] to select playback mode. MODE
1. Press [ ]/[ ] to scroll through the files.
