Instrukcja obsługi Polti Eco Pro 3000

Polti odkurzacz parowy Eco Pro 3000

Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Polti Eco Pro 3000 (12 stron) w kategorii odkurzacz parowy. Ta instrukcja była pomocna dla 2 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek

Pobierz PDF
Strona 1/12
VT ECO PRO 3000 - Cod. M0S07067 - Edizione 1O04
Fig. 4
Fig. 5
Fig. 1Fig. A Fig. 3Fig. 2
2
5
46
1
3
2A
11
9
11
15
13
12
11
119
108
9
117
20
11
17
19
1116
U R S
5
6
4
T
11
23
V
Q
21
22
24
18
OFF
ON
Fig. 6
Fo
H
G
D
C
I
A
B
F
E
L
14
K
J
Fig. 7
VAPORETTO ECO PRO 3000
42
E
E
E
EE
E
E
E
EEN
N
N
NN
N
N
N
NNG
G
G
GG
G
G
G
GGL
L
L
LL
L
L
L
LLI
I
I
II
I
I
I
IIS
S
S
SS
S
S
S
SSH
H
H
HH
H
H
H
HH
GENERATOR
A) Patented Safety Cap
B) Generator on/off switch
C) Accessory on/off switch
D) Central connector block with splash
proof cover
E) Lock-in aperture for central connector
F) Power supply cable
G) Carrying handle
H) Pivotting wheels
I) Steam flow regulation control
J) “Out of water” indicator light
K) Steam pressure indicator light
L) Pressure indicator
ACCESSORIES
1) Flexible hose
2) Steam gun
2A) Safety switch
3) Steam request lever
4) Connector assembly
5) Press down connector button
6) Locking tab
7) Extension tubes
8) Large brush
9) Cloth retaining clips
10) Replaceable bristles plate
11) Accessories locking button
12) Small brush
13) Cotton cloths
14) Filler bottle
15) Spare washers for accessory connections
16) 120° accessory
17) Small round brush for 120° accessory
18) Window squeegee tool
19) Small blade for window tool
20) Large blade for window tool
21) High pressure lance
ACCESSORIES SOLD SEPARATELY
22) Triangular brush
23) Large round brush for 120° accessory
24) Wallpaper stripper tool
Q) Iron
R) Steam request button
S) Temperature regulation dial
T) Iron rest mat
U) Continuous steam jet button
V) “Iron heating” indicator light
Dear Customer,
Congratulations and thank you for purchasing this POLTI product, contributing to the con-
servation of our most precious natural resource: the Environment. VAPORETTO solves all cleaning and hygiene
problems without the use of detergents - all that’s needed is just normal tap water which our system transforms
into steam at a constant powerful pressure, allowing you to clean more thoroughly and in an ecological way.
Our Technical Development team have added a range of sophisticated improvements to make cleaning tasks
both safer and more effective:
• The No Volt System - a unique Polti patent, designed so that there is no electricity to the on/off switch on the
handle, making it absolutely safe even if the handle is accidentally brought into contact with liquids. The No
Volt System offers the additional safety feature of only being able to operate when the user is present - the
steam switches itself off immediately if the handgrip is released.
• This generator is equipped with the new The maximum power is taken up when theSuper Power feature.
machine is being heated from cold to ensure more rapid heating of the water. Once a certain level of tempe-
rature has been reached (level 1), a cut out comes into operation, reducing the electricity consumption. The
system continues to heat using only the required amount of electricity to reach operating temperature most
efficiently (level 2).
• The Safety Cap - a unique Polti patent, prevents opening whilst any residual pressure remains in the system.
• The water is made of a stainless steel 18/10 which resists lime scale and corrosion and extends theboiler
life of your appliance.
• Steam pressure is controlled by a pressure switch and the steam flow can be regulated while operating.
Polti’s products are submitted to very strict testing. Vaporetto passed also the Splash Proof Test, since it has
been designed to be splash proof.
VAPORETTO is built according to the IEC regulations, and is equipped with a safety valve, a safety thermostat
and an additional protective thermostat which prevents operation of the machine when it is empty and which
maintains VAPORETTO in an absolutely safe condition at all times. The accessories and all the components are
manufactured with highest quality materials which are resistant to the high temperatures attained during the op-
eration of this machine.
Read these instructions carefully before using the appliance.

Specyfikacje produktu

Marka: Polti
Kategoria: odkurzacz parowy
Model: Eco Pro 3000
