Strona 1/32
3
BOARD SWING
Read through the instruction manual carefully before use.
Make sure you keep the instructions for future reference!
Intended use
The product is designed as a toy for private use for children over
36 months of age. The product may not be used on public equipment
such as playgrounds, schools, etc..
Technical data
Maximum load of the product: 100kg
Safety Instructions
Risk of injury!
• ATTENTION! Minimum and maximum user age: 3-14 years!
• ATTENTION! Minimum and maximum user weight: 5-100kg!
• ATTENTION! Only for use at home
• ATTENTION! The distance between the seat element of the swing and the
ground must be at least 35cm.
• ATTENTION! Suitable for outdoor use
• Warning! Not suitable for children under 3 years.
Rope poses a strangulation hazard.
• Children may only play with this product under supervision.
• Maximum load of the product = 100kg.
• The swing may only be set up on equipment that has sufficient stability
such as solid wooden scaffolding, metal scaffolding or concrete ceilings.
• An adult must perform the installation.
• An adult must check the stability after installation.
4
• Only install the swing as described in these instructions, other methods of
fastening may damage the cord or the holding element.
• An adult must inspect the fastening of the cords, the knots in the cord
beneath the swing unit, the hooks and the rings . before each use
Discontinue use of the swing as soon as the fastening element of the swing
becomes brittle and you can see the metal on the inside.
• Do not use the swing near stairs.
• The product may only ever be used by one person.
• Fasten the swing leaving enough space from other objects so that no-one
can be injured. Pay attention to the radius that the swing makes when it
swings.
• Make sure that there are no hard objects or objects with sharp edges in
the area of the swing.
• Do not fasten the swing over concrete, asphalt or any other hard surfaces.
• Use the appropriate fastening material (see the Swing Assembly) for each
installation in wooden or metal equipment as well as in concrete ceilings.
• The fastening hooks must be completely inserted through the wood and
fixed by a locknut from above when fastening into wooden equipment or
wooden beams.
Swing Assembly
Tip
Only fasten the swing to equipment for which you can guarantee adequate
strength with absolute confidence. To prevent unintentional detachment use
10mm strength screw hooks minimum for assembly, which are bent by at least
540° or which are completely closed. The fastening hooks must be complete-
ly inserted through the wood and fixed by a locknut from above in wooden
beams to accomplish an adequately secure connection.
5
Different fastening hooks
Only fasten the swing unit to an appropriate retention system.
These are:
No. 1: a closed retaining grommet, which is secured to the swing element by
a carabiner.
No. 2: a circular hook, which is bent by at least 540° to prevent
unintentional detachment.
Tip
The eye of the retaining grommet (A) must be attached at a
right angle to the direction of the swing so that the fastening
element of the swing is not damaged too much during use.
Discontinue use of the swing as soon as the
fastening element shows fractures or cracks on
the upper grommet.
Fig. 1 Fig. 2
(A) (A)
Fig. 3
No. 1 No. 2
