Planar Simplicity Series

www.planar.com

Planar Simplicity Series

Safety Instructions

Warnings and Precautions

KNOW THESE SAFETY SYMBOLS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

This symbol indicates high voltage is present inside.

It is dangerous to make any kind of contact with any

inside part of this product.

This symbol alerts you that important literature

concerning operation and maintenance has been

included with this product.

CAUTION: FCC/CSA regulations state that any unauthorized

changes or modications to this equipment may void

the user’s authority to operate it.

CAUTION: To prevent electric shock, match the wide blade of plug

to the wide slot, and fully insert the plug.

TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC

SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

OR MOISTURE.

The Socket-outlet should be installed near the apparatus and be easily

accessible.

Read and follow these instructions

when connecting and using your Public

Information Display:

• Unplug the display if you are not going to use it for an extensive

period of time.

• Unplug the display if you need to clean it with a slightly damp cloth.

The screen many be wiped with a dry cloth when the power is off.

However, never use alcohol, solvents or ammonia-based liquids.

• Consult a service technician if the display does not operate normally

when you have followed the instructions in this manual.

• The casing cover should be opened only by qualied service

personnel.

• Keep the display out of direct sunlight and away from stoves or any

other heat sources.

• Remove any object that could fall into the vents or prevent proper

cooling of the display’s electronics.

• Do not block the ventilation holes on the cabinet.

• Keep the display dry. To avoid electric shock, do not expose it to

rain or excessive moisture.

• If turning off the display by detaching the power cable, wait for 6

seconds before re-attaching the power cable for normal operation.

• To avoid the risk of shock or permanent damage to the set do not

expose the display to rain or excessive moisture.

• When positioning the display, make sure the power plug and outlet

are easily accessible.

• IMPORTANT: Always activate a screen saver program during your

application. If a still image in high contrast remains on the screen for

an extended period of time, it may leave an ‘after-image’ or ‘ghost

image’ on the front of the screen. This is a well-known phenomenon

that is caused by the shortcomings inherent in LCD technology. In

most cases the after-image will disappear gradually over a period

of time after the power has been switched off. Be aware that the

after-image symptom cannot be repaired and is not covered under

warranty.

Planar Simplicity Series

iii

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Do not use over 16 hours per day.

7. Clean only with dry cloth.

8. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

9. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliers) that produce heat.

10. Do not defeat the safety purpose of the polarized or grounding-

type plug. A polarized plug has two blades with one wider than the

other. A grounding type plug has two blades and a third grounding

prong. The wide blade or the third prong are provided for your

safety. If the provided plug does not t into your outlet, consult an

electrician for replacement of the obsolete outlet.

11. Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where

they exit from the apparatus.

12. Only use attachments/accessories specied by the manufacturer.

13. Use only with the cart, stand, tripod, bracket, or

table specied by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when

moving the cart/apparatus combination to avoid

injury from tip-over.

14. Unplug this apparatus during lightning storms or when unused for

long periods of time.

15. Refer all servicing to qualied service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPARATUS TO

RAIN OR MOISTURE.

WARNING: Apparatus shall not be exposed to dripping or splashing

and no objects lled with liquids, such as vases, shall be

placed on the apparatus.

WARNING: The batteries (batteries installed) shall not be exposed

to excessive heat such as sunshine, re or the like.

WARNING: The mains plug or appliance coupler is used as the

disconnect device,the disconnect device shall remain

readily operable.

WARNING: To prevent the spread of re, keep candles or other

open ames away from this product at all times.

WARNING: To prevent injury, this apparatus must be securely

attached to the oor/wall in accordance with the

installation instructions.

WARNING: This equipment is compliant with Class A of EN55032/

CISPR. In a residential environment this equipment may

cause radio interference.

WARNING: This is a class A product. In a domestic environment this

product may cause radio interference in which case the

user may be required to take adequate messures..

CAUTION: These servicing instructions are for use by qualied

service personnel only. To reduce the risk of electric

shock,do not perform any servicing other than that

contained in the operating instructions unless you are

qualitied to do so.

CAUTION: Excessive sound pressure from earphones and

headphones can cause hearing loss. Adjustment of the

equalizer to maximum increases the earphone and

headphone output voltage and the sound pressure level.

Therefore, to protect your hearing, adjust the equalizer

to an appropriate level.

NOTE: This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful

interference when the equipment is operated in a

commercial environment This equipment generates,

uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a

residential area is likely to cause harmful interference

in which case the user will be required to correct the

interference at his own expense.

Specyfikacje produktu

Marka:	Planar
Kategoria:	monitor
Model:	SL4851
Kolor produktu:	Czarny
Częstotliwość wejściowa AC:	50 - 60 Hz
Napięcie wejściowe AC:	100 - 240 V
Wysokość produktu:	663 mm
Szerokość produktu:	1082 mm
Głębokość produktu:	61 mm
Waga produktu:	12000 g
W zestawie pilot zdalnego sterowania:	Tak
Wbudowane głośniki:	Tak
Moc wyjściowa (RMS):	20 W
Certyfikaty:	FCC Class A, UL, CE
Port USB:	Tak
Typ HD:	Full HD
Długość przekątnej ekranu:	48 "
Przeznaczenie:	Wewnętrzna
Ilość portów Ethernet LAN (RJ-45):	1
Zakres temperatur (eksploatacja):	5 - 40 °C
Rozdzielczość:	1920 x 1080 px
Współczynnik kontrastu (typowy):	4000:1
Natywne proporcje obrazu:	16:9
Przewody:	AC, HDMI, RS-232
Pobór mocy w trybie czuwania:	- W
Wejscie Audio (L,P):	1
Przewodowa sieć LAN:	Tak
Pobór mocy:	149 W
Waga wraz z opakowaniem:	16000 g
Ilość portów HDMI:	1
Złącze RS232:	Tak
Technologia wyświetlacza:	LCD
Kąt widzenia (poziomy):	178 °
Kąt widzenia (pionowy):	178 °
Kolory wyświetlacza:	16.78 millionów kolorów
Czas odpowiedzi (typowy):	8 ms
Rozmiar plamki:	0.549 x 0.549 mm
Interfejs do montażu panelu:	200 x 200,400 x 400 mm
Typ gniazda zamka kabla:	Kensington
Jasność:	350 cd/m²
Ilość wbudowanych glosników:	2
Konstrukcja produktu:	Płaski panel Digital Signage
Wejście komponentu wideo (ypbpr/ycbcr):	1
Zdalne wejście IR:	1
Wyjście audio (prawe/lewe):	1
Port DVI:	Tak
Wejście audio dla PC:	Tak
Typ podświetlenia LED:	Edge-Lit LED
Orientacja:	Poziomy/Pionowy
Wejścia VGA (D-Sub):	1
Roboczogodziny (godziny / dni):	16/7
Żywotność panelu:	- h
Szerokość ramki (dół):	14.7 mm
Szerokość ramki (bok):	11.9 mm
Szerokość ramki (góra):	11.9 mm
