8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without warning.
24” signature series
Adara beer dispenser
HP24TS-3-**1A 24” INDOOR MODEL, 1 FAUCET
HP24TS-3-**2A 24” INDOOR MODEL, 2 FAUCET
Form No.HP24T-3A
Rev. 09.06.2017
• Availablewithsolidstainlesssteeldoororsolidwood
overlaydoor
• Stores(1)1/4barrelor(2)1/6barrels
• Complete,self-containedbeersystem
• Portabledrainer;noplumbingrequired
• 1-or2-faucetAdaratappingkit
• Lowprolecouplerfor“D”systemkegvalvesincluded
• BeerDispensertemperature33°-42°F
• Zero-clearancehingingallowsforabutmentwith
surroundingcabinetry
• Perlick’sexclusivecommercial-grade995Btuvariable
speedcompressor
• Robustfront-vented,RAPIDcoolforced-airrefrigeration
system
• Commercial-gradestainlesssteelinteriorandexterior
• State-of-the-artdigitalcontrolmodule
• Optionaldoorlocks(factoryinstalled)
• Alsoavailable-24”Refrigerator,Freezer,BeverageCenter,
WineReserveandBeerDispenser
• 5.2cubicfeetofcapacity
• IndustryBestThreeYearWarrantyplusadditionalthree
yearsonsealedsystem
general signature series
features
HP24TS-3-***A features
Solid Door Model
C
US
I
N
D
U
S
T
R
Y
S
B
E
S
T
I
N
D
U
S
T
R
Y
S
B
E
S
T
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
3 YEAR
3 YEAR
FU LL 3 YEA RS, 6 YEA RS O N SE ALE D SYS T
FU LL 3 YEA RS, 6 YEA RS O N SE ALE D SYS TEM
Available with 1 or 2 faucets (2 faucet model shown)
• SleekEuropeandesignwithsoft,curvedsilhouette
• Chrometowerwithmatchingchromehandle(s)createsa
brightandmodernmonochromaticlook
• ComesstandardwithPerlicksaward-winning650SS
FlowControlBeerFaucet(s)
• Towerisair-cooledforconsistenttemperature
fromkegtotap
• Availablein1-or2-faucetmodels
Adara tower features
(1) 1/4 barrel (2) 1/6 barrels
8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without warning.
Form No.HP24T-3A
Rev. 09.06.2017
Overall Width 23-7/8”(60.64cm.)
Overall Height 34-1/4”(86.96cm.)
Overall Depth 24”(60.96cm.)
Opening Width 24”(60.96cm.)
Opening Height 34-3/8”(87.31cm.)
Opening Depth 24”(60.96cm.)
Refrigerated Volume 5.2cu.ft.
Door Swing Clearance 25”(63.5cm.)minimum
Electrical 115V,60Hz.,1Phase,2.3amps
Plumbing NoneRequired
Annual Energy Usage 290kWh/yr
Shipping Weight 222lbs(100.7kg.)
product specifications ADARA indoor models
HP24TS-3-1L1A Solidstainlesssteeldoor,hingeleft*
HP24TS-3-2L1A Solidwoodoverlaydoor,hingeleft*
Single Faucet models
HP24TS-3-1L2A Solidstainlesssteeldoor,hingeleft*
HP24TS-3-2L2A Solidwoodoverlaydoor,hingeleft*
* Also available hinge right
Two Faucet models
50" Area in which1270
electrical outlet must be located
7
9
16
"192
1 3/8" 32
Min. clearance from
a corner to
acheive 90
door swing.
24
15
16
" 634
Min. clearance
for door swing.
16
1
8
" 410
Typical
quarter barrel.
14" 356
3
1
2
" 89
21
3
8
" 543
9
15
16
" 252
11
7
8
" 302 6
1
4
" 159
18
3
16
" 461
24
7
8
" 632
16
3
16
" 412
20" 508
1
5
8
" 42
21
3
8
" 543
3
1
2
" 89
26
9
16
" 674
1
15
16
" 49
Power cord 6-5/8" [168] off floor. *
8
7
16
"214
11
15
16
"303
Shelf included with
dispensing cabinets.
24" 611
(with 1/16" tolerance)
Value may change
with a wood overlay door.
1
3
8
" 35
Value may
change due to a
custom pull.
18
15
16
" 480
23
7
8
"606
*34
5
16
" 872
*3
15
16
" 100
* - Leg levelers can add
3/4" [19] to these dimensions
when fully extended.
Signature Series HP24 Models
Tapping
Also fits two sixth
barrels when shelf
is removed.
PERLICK CORPORATION
MILWAUKEE, WI 53223
PROPERTY OF THE PERLICK CORP.
NOT TO BE COPIED OR USED DETRIMENTAL TO OUR INTERESTS
DR.:
PRINTED
DATE:
9/5/2017
95005
9/30/09DAS
SCALE: 1:10
