8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is commied to connuous improvement. Therefore, we reserve the right to change specicaons without warning.
FORM NO. Z2527
REV. B-11/20/2019
GENERAL C-SERIES FEATURES
HC24RB/RO FEATURES
24” C-SERIES
REFRIGERATOR
HC24RB-3 24” INDOOR MODEL
HC24RO-3 24” OUTDOOR MODEL
• Industry Exclusive front-vented RAPIDcool forced-air
refrigeraon system provides best-in-class cooling
performance
• Commercial-grade stainless steel interior. Indoor
models have black vinyl clad exterior; outdoor
models have stainless steel exterior
• All models available with stainless steel or panel
ready door. Panel ready doors come ready to accept
customer-supplied overlay and handle
• Drawer models feature self-closing slides
• Zero-clearance hinging allows for abutment with
surrounding cabinetry
• Industry Exclusive full extension refrigerator shelves
provide easy access for stocking and retrieving
product. Shelves glide smoothly in and out of
cabinet on stainless steel ball bearing glides
• Interior lighng and digital control
• Low E, double pane UV-resistant glass provides
exceponal insulaon and protecon from light
• Comprehensive Full Three Year Warranty plus
addional three years on sealed system
• Available with stainless steel solid door, panel ready
solid door, stainless steel glass door, panel ready
glass door, stainless steel drawers or panel ready
drawers
• Outdoor models available with solid stainless
steel door, solid wood overlay door, stainless steel
drawers or wood overlay drawers
• Door models include two (2) full-extension pull-out
shelves
• Refrigerator rated for both food and beverage
storage
• Storage for 144 cans
• Refrigerator temperature 33°- 42°F
C
US
Glass Door Model (Indoor) Solid Door Model (Outdoor) Drawer Model (Indoor)
(L) Factory Installed Lock
66736 Caster Kit for HP24/HC24/HA24 models
RS-24-24D Divider Shelf for HP24/HC24/HA24 models
Perlick accessories are available for purchase through an
authorized Perlick dealer. For a full list of accessories and to
nd a dealer near you, visit perlick.com/residenal
ACCESSORIES
8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is commied to connuous improvement. Therefore, we reserve the right to change specicaons without warning.
FORM NO. Z2527
REV. B-11/20/2019
Product Width 23-7/8” (606 mm.)
Product Height 34-1/4” (870 mm.)
Product Depth 24” (610 mm.)
Opening Width 24” (610 mm.)
Opening Height 34-1/2” (876 mm.)
Opening Depth** 24-7/8” (632 mm.)
Refrigerated Volume 5.2 cu. .
Door Swing Clearance 25” (635 mm.) minimum
Electrical 115V, 60Hz., 1 Phase, 2.3 amps
Compressor 525 BTU, standard
Plumbing None Required
Annual Energy Usage 274 kWh (solid door)
305 kWh (glass door and drawers)
Shipping Weight 183 lbs (83.01 kg.)
PRODUCT SPECIFICATIONS INDOOR MODELS
HC24RB-3-1L* Stainless steel solid door, hinge le
HC24RB-3-2L*† Panel ready solid door, hinge le
HC24RB-3-3L* Stainless steel glass door, hinge le
HC24RB-3-4L*† Panel ready glass door, hinge le
HC24RB-3-5 Stainless steel drawers
HC24RB-3-6† Panel ready drawers
OUTDOOR MODELS
HC24RO-3-1L* Solid stainless steel door, hinge le
HC24RO-3-2L*† Solid wood overlay door, hinge le
HC24RO-3-5 Stainless steel drawers
HC24RO-3-6† Wood overlay drawers
* Also available hinge right (R)
† This unit comes ready to accept customer-provided overlay panel and handle
11 7/8" 302 6 1/4" 159
3 1/2" 89
23 1/16" 585
26 9/16" 674
18 3/16" 461
2" 50
Shelf
adjustability.
4 1/4" 108
Lowest
shelf location.
Min. clearance
for door swing.
3 1/2" 89
23 1/16" 585
20" 508
26 9/16" 674
24" 611
(with 1/16" tolerance)
Value may change
with a wood overlay door.
1 7/8" 49 22 1/8" 562
1 1/2" 39
Value may
change due to a
custom pull.
p
clearance.
CK CORPORATION
WAUKEE, WI 53223
PERTY OF THE PERLICK CORP.
OR US ED DETRIMENTAL TO OUR INTERESTS
PRINTED
9/5/2017
23 7/8" 606
*3 7/8" 100
*34 5/16" 872
24 15/16" 634
Min. clearance
for door swing.
7 9/16" 192
50" 1270 Area in which
electrical outlet must be located.
6 1/4" 159
11 7/8" 302
18 3/16" 461
20" 508
1 1/2"
Value
change d
custom
RES
(HC2
*
- Le
3/4"
whe
Power cord 6-5/8" [168] off floor.*
90° Swing
required for
pull-out shelf
clearance.
1 1/2" 36 Min.
clearance from
a corner to
acheive 90
door swing.
*- Leg leveler can add
3/4" [19] to these dimensions
when fully extended.
7 9/16" 192
50" 1270 Area in which
electrical outlet must be located.
23 7/8" 606
Power cord 6-5/8" [168] off floor.*
39
18 1/4" 464
1 1/2"
17 13/16" 453
Inside Drawer
(Top & Bottom)
c
17 1/4" 439
6 3/16" 157
10 13/16" 276
Max. product ht.
3 3/16" 81
8 3/8" 213
10 3/4" 274
Max. product ht.
10 1/2" 266 6 3/4" 172
5 9/16" 142
Max. product ht.
WI 53223
PORATION
MENTAL TO OUR INTERES
TS
P
9/5/2017
ERLICK CORP.
100
23 7/8" 606
*3 7/8"
*34 5/16" 872
39
18 1/4" 464
1 1/2"
Inside Drawer
(Top & Bottom)
481 7/8"
with a wood overlay.
Value may change
1/16" tolerance)(with
611
56222 1/8"
24"1 1/2" 39
Value may
change due to a
custom pull.
Door Models
Drawer Models
** Includes 7/8” plug clearance. To achieve 24” depth, you must recess the plug
into the wall directly behind the unit.
California Prop 65 Noce:
WARNING: The materials used in this product may contain chemicals known to the State of California to cause cancer and
birth defects or other reproducve harm. For more informaon go to www.P65Warnings.ca.gov.
