Contents
Safety Precautions 2
Checking Your Washing Machine
7
Before Washing 8
Control Panel 10
Detergent 12
Washing & Drying 14
Program List 16
Details of Programs 18
Washing & Drying Tips 20
Changing Program Settings 22
Changing Appliance Settings 30
Maintenance 31
For Better Results 35
Troubleshooting 36
Error Display 43
Installation
Choosing the Right Location 45
Moving and Installing 46
Connecting the Hoses 48
Test Run 50
Panasonic SmartApp+ 51
Specifications 70
EN
Thank you for purchasing this product.
- Read these instructions carefully for optimum
performance and safety before use.
- Keep this manual for future reference.
It is essential to read these instructions.
AWW9901CA5C0-0C0
Operating & Installation
Instructions
Washer Dryer
(Household Use)
Model No. NA-S106FR1 NA-S96FR1
NA-S106FC1 NA-S96FC1
zIf the power cord is
damaged, it must
be replaced by the
manufacturer, its
service agent or similarly
qualified persons in
order to avoid a hazard.
Safety Precautions
May cause serious injury or death
May cause fire or electric shock
WARNING
Children must not use it alone.
zThis appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
zChildren should be supervised to ensure that
they do not play with the appliance.
Setting the Child Lock. (P. 30)
On
Hold
5 sec.
Do not touch it
with wet hands.
Fully insert it.
Do not hold or
pull on the cord.
Do not use.
Damaged
Do not use.
Plug adaptor
Extension cord
2
May cause failure
In case of failure or damaged power cord,
stop use and ask the electrical technician.
Securely insert the ground prong.
Ask the electrical technician for a new socket.
Use a socket appropriate for this appliance.
e.g.)
zThe plug shape, socket shape and rating
requirement vary with the region.
Accumulated dust
may cause fire.
Wipe the power plug
periodically.
Keep away from
flammable materials.
Do not disassemble,
repair or modify it by
yourself.
When using the “Panasonic SmartApp+” app
(Cause of malfunction due to radio waves
from the appliance)
S106FR1
zKeep at least 15 cm away from the
mounting part of the cardiac pacemaker.
zKeep away from medical equipment and
automatic control equipment (automatic
doors, fire alarms, etc.).
3
May cause fire (For safety use of the dryer)
Safety Precautions (continued)
Do not dry items soiled with flammable materials.
Drying zItems that have been soiled with substances such
as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes, wax removers
and cosmetic oils must not be dried in the appliance
even after having been washed.
Empty all pockets.
zMake sure that no objects are left in any
of the pockets. Pay particular attention to
cigarette lighters and matches. They may
cause fire.
Do not dry items made of rubber, etc.
Drying zItems such as foam rubber (latex foam), shower
caps, waterproof textiles, airtight fabrics, rubber
backed articles and clothes or pillows fitted with
foam rubber pads should not be dried in the
appliance. Such materials may be destroyed and
thereby damage the appliance.
zDo not dry unwashed items in the appliance.
The lint must not be allowed
to accumulate around the
appliance.
Observe the following.
zNever stop the appliance before
the end of the drying cycle unless
all items are quickly removed and
spread out so that the heat is
dissipated.
zThe appliance is not to be used if
industrial chemicals have been used
for cleaning.
zThe appliance must not be supplied
through an external switching device,
such as a timer, or connected to a
circuit that is regularly switched on
and off by a utility.
WARNING
4
CAUTION
May cause injury
May cause water leakage
Be careful not to get your
fingers caught.
Do not touch when it is hot.
Do not climb on the appliance.
Install the appliance correctly.
Door
Full opening
zThe appliance must not be
installed behind a lockable door, a
sliding door or a door with a hinge
on the opposite side to that of the
appliance, in such a way that a
full opening of the appliance door
is restricted.
Turn off the water faucet. Use new hose-sets.
zNew hose-sets
supplied with the
appliance are to
be used and old
hose-sets should
not be reused.
For maximum mass of dry cloth and pressure of tap water, see P. 70.
5
Safety Precautions (continued)
CAUTION
May cause failure
Keep away from heat and
direct sunlight.
Remove anchor bolts before
operation.
Do not obstruct. Do not use hot water.
zDo not obstruct
the openings of
the bottom face
with carpet, etc.
Over 50 ºC
For machine-washable items only.
zThis appliance is intended to be used in
household.
This appliance is not intended to be used in
applications such as:
- staff kitchen areas in shops, offices and other
working environments;
- farm houses;
- by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments;
- areas for communal use in blocks of flats or in
launderettes.
Do not wash excessively oily
clothes.
Follow the instructions.
zFabric softeners, or similar products,
should be used as specified by the
fabric softener instructions.
6
Part names
Checking Your Washing Machine
Detergent drawer (P. 12)
Accessories
Control panel
(P. 10)
DrumDoor
Door seal
Drain filter cover
(P. 34)
Hinge
Adjustable feet
(P. 47)
Elbow (1) (P. 49) Cover caps (4) (P. 47)
Water supply hose (1) (P. 48, 49) Bottom cover (1) / Screw (1) (P. 46)
Water inlet (P. 49)
Anchor bolts
(P. 47)
Drain hose
(P. 48, 49)
Power cord and plug*
* The plug shape varies
with the region.
7
Cannot wash or dry
Cannot wash or dry
Leather / fur Silk, rayon and cupro
(Blended fabric)
Commercially
available washing aids
Cap with hard
core materials
Others ...
zWrinkled and
embossed articles
zCrepe fabric
zDeformable
clothing (blazers,
ties, dresses, etc.)
zVelvet
Cushion, Pillow, etc. Urethane / rubber
backed or thick mats
Paper diapers
Cannot dry
Any of the above
marks
Woollen clothing Tights or pantyhose Mats and other
items with hair of
pets attached
Quilts Starched clothing Clothing with laces
or embroidery, new
synthetic fibres, etc.
NOTE
zMay cause clothing deformation, damage and harm or malfunction to the
appliance. 9
Control Panel
Add Wash lamp:
You can add clothes
while lit. (P. 14)
Lock The door is locked
The door and buttons are
all locked (Child Lock) (P. 30)
ECONAVI lamp
(P. 23)
Water temperature
Spin speed
Optional function lamp
Display
Process Wash
Rinse
Spin
Dry
Remaining time
Error display (P. 43, 44, 56)
(e.g. U11)
“My Favorite” program lamp (P. 51)
NA-S106FC1/NA-S96FC1
zImages in these instructions are of the
NA-S106FR1, unless otherwise indicated.
(P. 26) (P. 33)
(P. 27) (P. 29)
(P. 54) (P. 28)
Auto Tub Care (P. 28)
10
Program selection
slider (P. 16)
Power button
Start/
Pause
button
Temp ( P. 22)
Control buttons
Spin ( P. 23)
Wash Mode (P. 24)
Timer (P. 26)
Rinse+ (P. 27)
Tub Clean (P. 33)
Blue Ag+ (P. 29)
NOTE
zTurn off back on zNo operation auto power off
3 sec.
Turn off On
( ) Auto
Power off
(Not pressed )
10 min.
On
zIn case of a power failure
When the power recovers, operation resumes from where it stopped. (Auto Restart)
Press & hold 5 sec at the
same time:
Child Lock ( P. 30)
NA-S106FR1/NA-S96FR1
Touch operation
zIf water, detergent or softener gets
on, turn off and wipe off with a
towel etc. immediately. (Cause of
malfunction)
Dry Mode (P. 25)
Press & hold 5 sec:
Auto Tub Care (P. 28)
Press & hold 5 sec:
Remote (P. 54)
Stain Master+
(P. 16
, 17
)
Press 5 sec:
Dry Only (P. 21)
NA-S106FR1 only
(NA-S106FR1 only)
11
Detergent
NOTE
STARTSTART
Detergent
Use a low foam detergent.
zTo prevent powder detergent from
remaining in the detergent drawer:
Wet Dry
Lumps Powder
Fabric softener
Separated
or solidified
softeners
Concentrated
softener
Water
Detergent
Powder detergent Liquid detergent
Bleach
zFollow the instructions on each package.
12
