Strona 1/9

QRT 5

QRT 5QRT 5

Model: RB911G-5HPnD-QRT

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

All installation methods for mounting an access point on any wall surface is subject to the acceptance of local jurisdiction.

The Installation of the equipment must comply with local and national electrical codes.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.

This is a class A device. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures.

Exposure to Radio Frequency Radiation:

Exposure to Radio Frequency Radiation:Exposure to Radio Frequency Radiation:This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

uncontrolled environment.This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the

general public.

Quickstart

Please follow these quick steps to set up your device:

Mount the unit in your desired place, please see paragraph.Mounting

Slide off latch to access Ethernet port. Please see the section.Opening latch

Connect your PoE cable to the Ethernet port, please see the section.Powering

Set your computer IP configuration to automatic (DHCP).

From your PC connect to the wireless network name which starts with "MikroTik".

Once connected to the wireless network, open in your web browser to start configuration, since there is no password by https://192.168.88.1

default, you will be logged in automatically . (or, for some models, check user and wireless passwords on the sticker)

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best

performance and stability.

Choose your country, to apply country regulation settings, and set up your password on the screen that loads.

Powering

The device accepts power from the PoE to the Ethernet port:

Passive Power over Ethernet 8-30 V DC .

The power consumption under maximum load can reach 12 W.

Connecting to a POE Adapter:

Connecting to a POE Adapter:Connecting to a POE Adapter:

Connect the Ethernet cable from the device to the POE+DATA port of the POE adapter.

Connect an Ethernet cable from your local network (LAN) to the POE adapter.

Connect the power cord to the adapter, and then plug the power cord into a power outlet.

Configuration

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best performance and

stability. RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself

accustomed to the possibilities: . In case IP connection is not available, the Winbox tool ( ) can be used to connect to https://mt.lv/help https://mt.lv/winbox

the MAC address of the device from the LAN side (all access is blocked from the internet port by default). For recovery purposes, it is possible to boot the

device from a network, see the section Reset button.

Extension slots and ports

Gigabit Ethernet port, passive PoE on Ethernet port.

5 GHz wireless, supported protocol 802.11a/n, antenna gain 24 (dBi).

Opening latch

To access the Ethernet port and reset button, please open latch:

Pull the latch out downwards from the device.

Lift the latch, but do not remove them completely.

Front status LED behavior

RouterOS allows configuring each LED's activity the way that the user wishes. It is possible to configure the LEDs to display wireless strength, blink the
