netPower 15FR

netPower 15FRnetPower 15FR

netPower 15FR

The NetPower is a weatherproof switch with the capability of using backup PoE from connected devices.

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

The Installation of the equipment must comply with local and national electrical codes.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.

Quickstart

Please follow these quick steps to set up your device:

Open the bottom lid (see " ").Bottom Lid

Connect all served devices to Ethernet ports.

Connect the device to the power source (see " ").Powering

Open network connections on your PC.

Set the IP address of your computer to 192.168.88.4/24.

The Configuration has to be done through the web browser or WinBox configuration tool .https://mt.lv/winbox

Once connected to the network, open in your web browser to start configuration, user name: a and there is no https://192.168.88.1

dmin

password by default . (or, for some models, check user and wireless passwords on the sticker)

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best

performance and stability. Must have an active Internet connection configured.

Set a secure password.

Expansion slots and ports

DC power connector 18 – 57 V.

LED indicating a power state of the device.

Reset button.

Fast Ethernet 100Mbit/s, 15 - Ethernet ports, accepting PoE In.

Fast Ethernet 100Mbit/s, One - Ethernet port, delivering PoE out.

LED indicator of PoE out Ethernet port.

Two - 1G SFP ports.

LED Indicating the activity of SFP port.

LED Indicating the speed of SFP port.

Configuration

We recommend clicking the "Check for updates" button in the QuickSet menu, as updating your RouterOS software to the latest version ensures the best

performance and stability. For wireless models, please make sure you have selected the country where the device will be used, to conform with local

regulations.

RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself accustomed to

the possibilities: . In case the IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC https://mt.lv/help https://mt.lv/winbox

address.

For recovery purposes, it is possible to boot the device for reinstallation, see section .Buttons and Jumpers

Powering

The device accepts power in the following ways:

Ethernet ports accept passive PoE 36-57 V DC .

Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) accepts 18-57 V DC.

Use included DC plug to connect with your power source:

DC plug 2.1x5.5x12 mm to Screw Terminal 2pin.

Connect your power source cables to the two pins and secure them in place by tightening screws.

Connect the DC plug to the device.

The power consumption under maximum load can reach 10 W, with attachments 28 W.

Connecting to a PoE Adapter:
