LHG R

LHG RLHG R

LHG R (RBLHGR)

LHG R without factory installed modem, you can choose your own solution.

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

All installation methods for mounting an access point on any wall surface is subject to the acceptance of local jurisdiction.

The Installation of the equipment must comply with local and national electrical codes.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.

Exposure to Radio Frequency Radiation:

Exposure to Radio Frequency Radiation:Exposure to Radio Frequency Radiation:This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

uncontrolled environment.This MikroTik device should be installed and operated no closer than 120 centimeters from your body, occupational user, or the

general public.

Quickstart

While holding the unit by its central column, apply force to the tab, which holds the latch closed, until the latch pops open.

Insert the SIM card into the slot, with chips facing UP.

Install your desired modem.

Assemble case by attaching legs to the base of the unit, please see paragraph. Case assembly

Mount unit in your desired place, please see paragraph. Mounting

Connect an Ethernet cable to the Ethernet port, connect the other end of the Ethernet cable to the included PoE injector.

Plug the PoE injector into your PC.

Plug the included power supply into the PoE injector to start up the device. please see the paragraph.powering

Set LAN computer IP configuration to (DHCP).

automatic



Open in your web browser to start the configuration. https://192.168.88.1

User name: a and there is no password by default you will be logged in automatically to the Quick Set screen

dmin

 (or, for some models, check

.user and wireless passwords on the sticker)

Update the device by clicking the "Check for updates" button on the right side and updating your RouterOS software to the latest version to

ensure the best performance and stability. Must have a valid SIM card inserted.

To manually update the device, please gohttps://mikrotik.com/download

Choose MIPSBE packages for this device and download it to your PC.

Upload downloaded packages to the WebFig "Files" menu and reboot the device.Updatingyour RouterOS software to the latest version will

ensure the best performance, stability, and security updates.

Expansion slots and ports

One 10/100 Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X). Either straight or crossover cable can be used for

connecting to other network devices. The Ethernet port accepts 9-30 V DC powering from a passive PoE injector.

MiniPCIe slot and SIM slot (can't be used separately) to be used with a 3G/4G/LTE modem.

Powering

The device can be powered from 12-57 V 802.3af/at sources and also Passive PoE injectors (one power supply and PoE injector are included).

Maximum power consumption 6 W.

Connecting to a POE Adapter:

Connect the Ethernet cable from the device to the POE port of the POE adapter.

Connect an Ethernet cable from your LAN to the LAN port of the POE adapter, please mind arrows for data and power flow.

Connect the power cord to the adapter, and then plug the power cord into a power outlet.

Opening the case cover

To access the miniPCIe slot, the opening of the unit's top cover is required. As an opening tool, you can use a large size flat head screwdriver or a small

coin. Be extremely cautious when opening, because the incorrect opening of the clip can break it off!

Mounting and configuration of this device should be done by a qualified person.

Follow these steps:

Additional Caution when lifting up the cover, do not force it with sharp objects.

miniPCIe slot usage

The device is equipped with a miniPCIe slot to be used with a 3G/4G/LTE modem. One SIM slot is provided for use together with a miniPCIe modem. The

SIM slot is not used separately.

In this case, an internal antenna is not connected (located inside the enclosure). Installing a miniPCIe module should be done by a qualified person, please

follow safety precautions when handling electrical equipment:

Use a wrist grounding strap when unpacking and working with electrical components to avoid electrical discharge (ESD) damage.

Open the upper cover as shown on instruction previously.

The antenna is located underneath PCB.

Locate the miniPCIe slot on the PCB and remove two factory attached screws.
