DynaDish 5

DynaDish 5DynaDish 5

DynaDish 5 (RBDynaDishG-5HacDr3)

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

The Installation of the equipment must comply with local and national electrical codes.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed.

This is a class A device. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures.

Exposure to Radio Frequency Radiation:

Exposure to Radio Frequency Radiation:Exposure to Radio Frequency Radiation:This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

uncontrolled environment.This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the

general public.

Connecting

Unscrew the Ethernet protector and connect your PC or LAN cable to the Ethernet port, connect the other end of the Ethernet cable to a PoE

injector, or a powered Switch.

Set LAN computer IP configuration to automatic (DHCP).

The default IP address of the unit is 192.168.88.1, open this address in your web browser to start the configuration. The username is admin and

there is no password . Please set a password to protect access to the (or, for some models, check user and wireless passwords on the sticker)

device. Select the country of operation to follow local regulations.

Powering

The device accepts power to the Ethernet port - PoE 802.3af/at 24-57 V DC . Maximum power consumption 9 W.

Connecting to a PoE Adapter:

Connect the Ethernet cable from the device to the PoE+DATA port of the PoE adapter;

Connect an Ethernet cable from your local network (LAN) to the PoE adapter;

Connect the power cord to the adapter, and then plug the power cord into a power outlet.

Configuration

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best performance and

stability. RouterOS includes many configuration options in addition to what is described in this document. We suggest visiting the RouterOS documentation

page to get yourself accustomed to the possibilities: .https://mt.lv/help

In case an IP connection is not available, the Winbox tool ( ) can be used to connect to the MAC address of the device from the LAN https://mt.lv/winbox

side (all access is blocked from the internet port by default).

Extension Slots and Ports

One 10/100/1000 Gigabit Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either straight or cross-

over cables for connecting to other network devices.

One Integrated Wireless 5 GHz 802.11a/n/ac, 2x2 MIMO with built-in parabolic dish antenna, max gain 24 dBi.

Mounting

The device is designed to be used outdoors and mounted on a pole.

When mounting, please ensure that the cable feed is pointing downwards.

The IP rating scale of this device is IP54. We recommend using Cat6 shielded cables.

The mounting and configuration of this device should be done by a qualified person.

Attach provided mounting bracket with four screws to the device;

Attach to the pole or mast;

Secure position with two screws;

Align as needed and secure screws in step 3.

Note, the position of the ethernet cable must face down.

Please secure all loose Ethernet cables and antenna cables to the pole or mast approximately 30cm from the device, so that the cable weight is

not pulling the ports and connectors.

Buttons and Jumpers

The reset button has the following functions:

Hold this button during boot time until the LED light starts flashing, release the button to reset the RouterOS configuration (total 5 seconds).

Keep holding for 5 more seconds, LED turns solid, release now to turn on CAP mode. The device will now look for a CAPsMAN server (total 10

seconds).

Or Keep holding the button for 5 more seconds until LED turns off, then release it to make the RouterBOARD look for Netinstall servers (total 15

seconds).

Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power is applied to the device.

Useful for RouterBOOT debugging and recovery.
