Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Midea MFAG36VA-W (60 stron) w kategorii klimatyzacja. Ta instrukcja była pomocna dla 3 osób i została oceniona przez 2 użytkowników na średnio 4.6 gwiazdek
Strona 1/60
MODEL NUMBER:
MFAG20VA-N
MFAG26VA-N
MFAG36VA-N
MFAG51VA-N
MFAG60VA-N
MFAG70VA-N
MFAG80VA-N
USER MANUAL
Room Air Conditioner
Warning notices: Before using this product, please read this manual and SAFETY
MANUAL(if any) carefully and keep it for future reference. The design and
specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.The diagram above s just for i
reference. Please take the appearance of the actual product as the standard.
01
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please
read this manual thoroughly to ensure that you know how to operate the
features and functions that your new appliance oers in a safe way.
CONTENTS
01
02
06
07
08
10
20
29
25
31
32
34
34
39
5 0
55
55
52
56
33
THANK YOU LETTER
SAFETY PRECAUTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
PRODUCT INSTALLATION
Install Your Indoor Unit
Install Your Outdoor Unit
Refrigerant Piping Connection
Air Evacuation
Electrical And Gas Leak Checks
Test Run
Packing And Unpacking The Unit
OPERATION INSTRUCTIONS
Indoor Unit Display
Remote Control Operation
CARE AND MAINTENANCE
TROUBLESHOOTING
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
DISPOSAL AND RECYCLING
DATA PROTECTION NOTICE
02
It’s really important you read Safety Precautions Before Operation and Installation
Incorrect installation due to ignoring instructions can cause serious damage or injury.
The seriousness of potential damage or injuries is classified as either a WARNING
or CAUTION.
SAFETY PRECAUTIONS
Read these operating instructions carefully and attentively before using/commis-
sioning the unit and keep them in the immediate vicinity of the installation site or
unit for later use!
Warning of electrical voltage
This symbol indicates that there is a danger to life and health of
persons due to voltage.
Warning
The signal word indicates a hazard with a medium level of risk
which, if not avoided, may result in death or serious injury.
Caution
The signal word indicates a hazard with a low degree of risk which,
if not avoided, may result in minor or moderate injury.
Attention
The signal word indicates important information (e.g. damage to prop-
erty), but not danger.
Observe instructions
This symbol indicates that a service technician should only operate and
maintain this appliance in accordance with the operating instructions.
Explanation of Symbols
WARNING
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision(European Union countries).
This appliance is not intended for use by persons(including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety. Children should be supervised to ensure that
they do not play with the appliance.
03
ELECTRICAL WARNINGS
If an abnormal situation arises (like a burning smell), immediately turn o the
unit and disconnect the power. Call your dealer for instructions to avoid electric
shock, fire or injury.
Do not insert fingers, rods or other objects into the air inlet or outlet. This may
cause injury, since the fan may be rotating at high speeds.
Do not use flammable sprays such as hair spray, lacquer or paint near the unit.
This may cause fire or combustion.
Do not operate the air conditioner in places near or around combustible gases.
Emitted gas may collect around the unit and cause explosion.
Do not operate your air conditioner in a wet room such as a bathroom or laundry
room. Too much exposure to water can cause electrical components to short
circuit.
Do not expose your body directly to cool air for a prolonged period of time.
If the air conditioner is used together with burners or other heating devices,
thoroughly ventilate the room to avoid oxygen deficiency.
In certain functional environments, such as kitchens, server rooms, etc., the use
of specially designed air-conditioning units is highly recommended.
Do not allow children to play with the air conditioner. Children must be
supervised around the unit at all times.
●
●
●
●
●
●
●
●
●
Only use the specified power cord. If the power cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
The product must be properly grounded at the time of installation, or electrical
shock may occur.
For all electrical work, follow all local and national wiring standards, regulations,
and the Installation Manual. Connect cables tightly, and clamp them securely to
prevent external forces from damaging the terminal. Improper electrical
connections can overheat and cause fire, and may also cause shock. All electrical
connections must be made according to the Electrical Connection Diagram
located on the panels of the indoor and outdoor units.
All wiring must be properly arranged to ensure that the control board cover can
close properly. If the control board cover is not closed properly, it can lead to
corrosion and cause the connection points on the terminal to heat up, catch fire,
or cause electrical shock.
Disconnection must be incorporated in the fixed wiring in accordance with the
wiring rules.
Do not pull power cord to unplug unit. Hold the plug firmly and pull it from the
outlet. Pulling directly on the cord can damage it, which can lead to fire or
electric shock.
Do not modify the length of the power supply cord or use an extension cord to
power the unit.
Do not share the electrical outlet with other appliances. Improper or insucient
power supply can cause fire or electrical shock.
Keep power plug clean. Remove any dust or grime that accumulates on or
around the plug. Dirty plugs can cause fire or electric shock.
If connecting power to fixed wiring, an all-pole disconnection device which has
at least 3mm clearances in all poles, and have a leakage current that may exceed
10mA, the residual current device(RCD) having a rated residual operating current
not exceeding 30mA, and disconnection must be incorporated in the fixed wiring
in accordance with the wiring rules.
●
●
●
●
●
●
●
●
●
●
WARNING FOR PRODUCT USE
05
Turn o the air conditioner and disconnect the power if you are not going to use
it for a long time.
Turn o and unplug the unit during storms.
Make sure that water condensation can drain unhindered from the unit.
Do not operate the air conditioner with wet hands. This may cause electric shock.
Do not use device for any other purpose than its intended use.
Do not climb onto or place objects on top of the outdoor unit.
Do not allow the air conditioner to operate for long periods of time with doors or
windows open, or if the humidity is very high.
●
●
●
●
●
●
●
Do not clean the air conditioner with combustible cleaning agents. Combustible
cleaning agents can cause fire or deformation.
Turn o the device and disconnect the power before cleaning. Failure to do so
can cause electrical shock.
Do not clean the air conditioner with excessive amounts of water.
●
●
●
CAUTION
CLEANING AND MAINTENANCE WARNINGS
●
●
●
●
●
Note about Fluorinated Gasses(Not applicable to the unit using R290 Refrigerant)
This air-conditioning unit contains fluorinated greenhouse gasses. For specific
information on the type of gas and the amount, please refer to the relevant label
on the unit itself or the “Owner's Manual - Product Fiche ” in the packaging of the
outdoor unit. (European Union products only).
Installation, service, maintenance and repair of this unit must be performed by a
certified technician.
Product uninstallation and recycling must be performed by a certified technician.
For equipment that contains fluorinated greenhouse gases in quantities of 5
tonnes of CO2 equivalent or more, but of less than 50 tonnes of CO2 equivalent,
If the system has a leak-detection system installed, it must be checked for leaks at
least every 24 months.
When the unit is checked for leaks, proper record-keeping of all checks is strongly
recommended.
●
●
●
●
●
●
WARNING FOR USING R32/R290 REFRIGERANT
2
2
2
2
2
When flammable refrigerant are employed, appliance shall be stored in a well -
ventilated area where the room size corresponds to the room area as specifiec
for operation.
For R32 frigerant models:
Appliance shall be installed, operated and stored in a room with a floor area larger
than 4m .
For R290 refrigerant models, appliance shall be installed, operated and stored in a
room with a floor area larger than:
<=2.6kW units: 17.33m
>2.6kW and <=3.5kW units: 25.4m
>3.5kW and <=5.2kW units: 34.67m
>5.3kW and <=7.1kW units: 47.33m
Reusable mechanical connectors and flared joints are not allowed indoors.
When mechanical connectors are reused indoors, sealing parts shall be renewed.
When flared joints are reused indoors, the flare part shall be re-fabricated.
Mechanical connectors used indoors shall comply with ISO 14903.
06
SPECIFICATIONS
Product Model
Power source
Cooling capacity
Heating capacity
Rated current
Rated power input
Outdoor unit
resistance class
220-240V~ 50Hz, 1Ph
MFAG20VA-N
MFAG20VA-W
2.00kW
2.25kW
9.5A
2100W
MFAG26VA-N
MFAG26VA-W
2.60kW
2.70kW
9.5A
2100W
IP24
MFAG36VA-N
MFAG36VA-W
3.55kW
3.80kW
10.5A
2300W
Product Model
Power source
Cooling capacity
Heating capacity
Rated current
Rated power input
Outdoor unit
resistance class
220-240V~ 50Hz, 1Ph
MFAG60VA-N
MFAG60VA-W
6.00kW
6.20kW
15.5A
3600W
MFAG70VA-N
MFAG70VA-W
7.00kW
7.50kW
17.5A
4050W
IP24
MFAG80VA-N
MFAG80VA-W
8.00kW
8.50kW
17.5A
4050W
MFAG51VA-N
MFAG51VA-W
5.00kW
5.52kW
15.5A
3600W
