Before using, please read the manual carefully
MULTIMEDIA SPEAKER SYSTEM
All other brand and product names are trademarks of their respective holders. Actual contents may differ slightly from those shown in print. All
specifications and designs are subjected to changes without any prior notice.
No:80-SOLO7C-97-0001-01
SOLO7C
User's Manual
Caution:
Explanation of Graphical Symbols:
WARNINGS:
TO reduce the risk of electric shock, do not dismantle the apparatus and do not expose the apparatus to rain or moisture.
No user-serviceable parts inside. Refer servicing to qualified personnel.
The lightning flash within an equilateral triangle is intended to alert you to the presence of uninsulated angerous
voltage within the product's enclosure that may be of sufficient magnitude to constitute an electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
1. Read Instructions All the safety and operating instructions should be read before the appliance is operated.
2. Retain Instructions The safety and operating instructions should be retained for future reference.
3. Heed warnings All warnings on the appliance and in the operating instructions should be adhered to.
4. Follow instructions All operating and use instructions should be followed.
5. Installation Install in accordance with the manufacture's instructions.
6. Power sources This product should be operated only from the type of power source indicated by the marking adjacent
to the power cord entry. If you are not sure of the type of power supply to your home, consult your product dealer or local
power company.
7. Grounding or polarisation the appliance is not required to be grounded. Ensure the plug is fully inserted into the wall
outlet or extension cord receptacle to prevent blade or pin exposure. Some versions of the product are equipped with a
power cord fitted with a polarized alternating line plug ( a plug having one blade wide than the other). This plug will fit
onto the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarised plug. When using an extension power-supply cord or a power-supply cord other than
that supplied with the appliance, it should be fitted with the appropriate moulded-on plugs and carry safety approval
appropriate to the country of use.
8. Power cord protection Power-supply cords should be routed so that they are not likely to be walked on or pinched by
items placed on or against them, paying particular attention to cords at plugs, convenience receptacles and the point
where they exit from the appliance.
9. Overloading Do not overload wall outlets, extension cords or integral convenience receptacles, as this can result in a
risk of fire or electric shock.
10.Ventilation The product must be properly ventilated. Do not place the product on a bed, sofa, or other similar surface.
Do not cover the product with any items such as tablecloths, newspapers, etc.
11.Heat The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products)including amplifiers_ that produce heat. No naked flame sources, such as lighted candles, should be placed
on the apparatus.
12.Wall or ceiling mounting The product should be mounted to a wall or ceiling only as recommended by the manufacture.
13.Water and moisture To reduce the risk of fire or electric shock, do not expose the product to train, dripping, splashing
or excessive moisture such as in a sauna or bathroom. Do not use this product near water for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool and the like.
14.Object and Liquid Entry Never push objects of any kind into this product through openings, as they may touch
dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on
the product. Do not place any object containing liquid on top of the product.
15.Cleaning Unplug the product from the wall outlet before cleaning. The cabinet of the subwoofer may be cleaned by
dusting with a dry cloth. If you wish to use an aerosol cleaning spray, do not spray directly on the cabinet; spray onto the
cloth. Be careful not to disturb the drive units.
16.Attachments Do not use attachments not recommended by the product manufactures, as they may cause hazards.
17.Accessories Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall,
causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket
or table recommended by the manufacturer or sold with the product. Any mounting of the product should follow the
manufacturer's instructions and should use a mounting accessory recommended by the manufacturer.
18.Moving the appliance A product and cart combination should be moved with care. Quick stops, excessive force and
uneven surfaces may cause the product and cart combination to overturn
“
”
－
－
－
－
－
－
－
－
－
－
－
－
－
－
－
－
－
－
－
Important Safety Instructions Trouble Shooting
Troubles Solution
Check if the system is powered on
Check the power plug well connected
Check if the audio source is working well
Check if the audio and speaker cables well
connected
Check if the volume at right level
One or more satellite no sound Check if the satellite cable well connected
No Bass Check if the Bass Volume at right level
If the problem still exists, please contact the distributor or ask for professional service
Power LED won't light up
No Sound
Sound is distorted
Check if the volume at lower level
80- -97-0001-01 20071016 SOLO7C(07 ) SOLO7C
The apparatus is left unused for a long period of time.
20.Serving Do not attempt to service this product yourself, as opening or removing covers may expose you to dange
voltage or other hazards. Refer all servicing to qualified service personnel.
21.Replacement parts When replacement parts are required, be sure the service technician has used replacement
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions ma
result in fire, electric shock or other hazards.
22.Mains fuses For continued protection against fire hazard, use fuses only of the correct type and rating. The corre
specification for each voltage range is marked on the product.
23.Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the
speaker may be damaged when a peak level section is suddenly played.
24.The only means of completely disconnecting the product from the power supply is by removing the power cord fro
wall outlet or the product. Either the wall outlet or the power cord entry to the product must remain freely accessib
times while the apparatus is in use.
25. The socket-outlet shall be installed near the equipment and shall be easily accessible.
－
－
－
Unpacking:
*Fold the carton flaps right back and invert the carton and contents.
*Lift the carton clear of the contents.
*Remove the inner packing from the product.
We suggest you retain the packing for future use.
You should find following items while unpacking:
R(main) Speaker 1pc
L(sub) Speaker 1pc
Remote control 1pc
3.5mm-2RCA signal cable 1pc
Speaker cable 1pc
User's manual 1pc
Unpacking the system
Specification
*Amplifier specification:
Power output 55Wx2 RMS
Frequency response 5Hz-70KHz
Sensitivity Input 440mV
Separation 55 dB
S/N 85dB
*Acoustic specification:
Frequency range 55 Hz-20KHz
Sensitivity 85dB
Driver unit: 6. 5"x2 (magnetically shielded) +1"
*Audio input: (Input 1) RCA jack
(Input 2) RCA jack
(L Speaker) screw terminal
*Audio output: screw terminal
* Product size(DxWxH): 325x220x558mm
≥
Technical Information
Features:
*Designed for Multimedia PC, High Performance to Price Ratio.
*Complete wooden box with elegant wooden finish make pure sounds, avoid sound mixture.
*The system is magnetically shielded which can be put near the monitor or TV, and without
magnetic influence.
*The ultimate aim of Microlab R&D system is to inherit and carry forward the European musical
culture style. To do this, all designs must be music-oriented and sourced from music and art.
Having Microlab, you can enjoy European musical taste.
80- -97-0001-01 20071016 SOLO7C(07 ) SOLO7C
