METRA. The World’s best kits.™metraonline.com © COPYRIGHT 2015 METRA ELECTRONICS CORPORATION
REV. 10/9/2015 INST99-7626HG
CAUTION: Metra recommends disconnecting the negative battery
terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your
local Dealership for more information. All accessories, switches,
climate controls panels, and especially air bag indicator lights
must be connected before reconnecting the battery or cycling
the ignition. Also, do not remove the factory radio with the key
in the on position, or the vehicle running. It would be best to
remove the key from the ignition and then wait a few seconds
before removing the factory radio.
Installation instructions for part 99-7626HG
• ISO DIN radio provision with pocket
• DDIN radio provision
• Built and painted in multiple colors to match the
factory color and appearance
• A) Radio housing trim panel • B) Radio brackets • C) ISO Pocket • D) (4) #8 x 3/8” Phillips screws
• E) (2) White panel clips
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-7552 Antenna Adapter: • 40-NI12
• Panel removal tool
• Phillips screwdriver or drill with long Phillips bit
• T-20 Torx screwdriver
TOOLS REQUIRED
(Without NAV and with the factory climate controls above the radio controls)
A DCB
Dash Disassembly ................................................. 2
Kit Assembly
– ISO DIN radio provision with pocket 3 ......................
– DDIN radio provision 3 ............................................
Table of Contents
E

99-7626HG
Dash Disassembly
1. Remove top trim above climate
control panel and remove the
exposed Phillips screw holding the
climate control panel. (Figure A)
2. Unclip and remove climate control
panel. (Figure B)
3. Remove (2) Phillips screws at the
top of the radio trim bezel.
(Figure C)
4. Remove trim panel under the
radio and remove the (2) exposed
Phillips screws securing the radio.
(Figure D, E)
5. Remove (4) Phillips screws securing
the metal brace above the radio.
(Figure F)
6. Unclip, unplug and remove the radio.
7. Remove the (2) T-20 Torx screws
holding the climate control module
to the factory radio bracket
assembly, and set aside for
kit assembly.
Continue to kit assembly
(Figure A) (Figure D)
(Figure B) (Figure E)
(Figure C) (Figure F)

99-7626HG
(Figure A)(Figure A)
(Figure B)(Figure B)
Kit Assembly
ISO DIN radio provision
1. Attach the supplied (2) to white panel clips
the radio housing trim panel
2. Remove the metal “DIN” sleeve and trim
ring from the aftermarket radio.
3. Secure the included to the radio brackets
radio using the screws supplied with the
radio. (Figure A)
4. Mount the to the bracket assembly pocket
with the (4) #8 x 3/8” Phillips screws
supplied. (Figure A)
5. Mount the climate control module to
the bracket assembly below the radio and
pocket, using the hardware removed
during disassembly. (Figure B)
6. Locate the factory wiring harness and
antenna plug in the dash and make all
necessary connections to the radio and
climate control module. Metra recommends
using the proper mating adapters from
Metra and/or AXXESS.
7. Mount the new radio assembly into the dash
using the factory hardware and reassemble
the dash in the reverse order of disassembly.
DDIN radio provision
1. Attach the supplied (2) to white panel clips
the radio housing trim panel
2. Secure the included to the radio brackets
radio using the screws supplied with the
radio. (Figure A)
3. Mount the climate control module to
the bracket assembly below the radio,
using the hardware removed during
disassembly. (Figure B)
4. Locate the factory wiring harness and
antenna plug in the dash and make
all necessary connections to the radio
and climate control module. Metra
recommends using the proper mating
adapters from Metra and/or AXXESS.
5. Mount the new radio assembly into the
dash using the factory hardware and
reassemble the dash in reverse order of
disassembly.
