REV. 6/17/2016 INST99-7369B
INSTALLATION INSTRUCTIONS FOR PART 99-7369B
METRA. The World’s best kits.metraonline.com © COPYRIGHT 2016 METRA ELECTRONICS CORPORATION
CAUTION!
All accessories, switches, climate controls panels,
and especially air bag indicator lights must be connected before
cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
• ISO DIN radio provision with pocket
Painted matte black
A) Radio trim panel • B) Radio brackets • C) Pocket • D) (2) #8 x 3/8” Phillips screws
KIT FEATURES
KIT COMPONENTS
• Panel removal tool • Phillips screwdriver
• Socket wrench
TOOLS REQUIRED
A
Table of Contents
B C D
Dash Disassembly ..................................................2
Kit Assembly ...........................................................3
WIRING & ANTENNA CONNECTIONS (sold separately)
Wire harness: • 70-7304, HYBL-03 (nav models), HYBL-04
Antenna adapter: • Not required
99-7369B
1. Unsnap and remove the trim panel
above the radio and instrument
cluster. (Figure A)
2. Remove (3) Phillips screws and
unsnap the radio trim panel
including the vents. (Figure B)
3. Remove (4) Phillips screws to
remove the factory radio.
(Figure C)
Continue to kit assembly
Dash Disassembly
(Figure C)(Figure B)(Figure A)
99-7369B
Kit Assembly
1. Remove (2) screws from each vent,
attach them into the radio trim
panel, and then secure using the
same screws.
2. Remove (4) panel clips and then
attach them onto the radio
trim panel
3. Attach the to the pocket radio
brackets using the (2) supplied
#8 x 3/8” Phillips screws. (Figure A)
4. Remove the metal DIN sleeve and
trim ring from the aftermarket radio.
5. Slide the radio into the bracket/
pocket assembly and then secure
with the screws supplied with
the radio. (Figure B)
(Figure A) (Figure B)
6. Locate the factory wiring harness
and antenna connector in the
dash and complete all necessary
connections to the radio. Metra
recommends using the proper
mating adapter from Metra and/or
AXXESS. Test the radio for
proper operation.
7. Secure the completed assembly into
the dash using the factory screws.
8. Snap the over radio trim panel
the completed assembly and then
reassemble the dash in reverse
order of disassembly.
