INSTALLATION INSTRUCTIONS FOR PART 99-7320
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004-2009 METRA ELECTRONICS CORPORATION
KIT FEATURES
DIN head unit provision
A) Radio Housing
KIT COMPONENTS
TOOLS REQUIRED:
99-7320
A
APPLICATIONS
Hyundai Sonata
2006-2008
Phillips Screwdriver Small Flat Blade Screwdriver
WIRING AND ANTENNA CONNECTIONS
(Sold Separately)
Harness:
• 70-5520 - Ford harness 2003-up
Antenna Adapter:
• Not required
Dash Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
TABLE OF CONTENTS
99-7320
K
NOWLEDGE IS
P
OWER
Enhance your installation and fabrication skills
by enrolling in the most recognized and respected
mobile electronics sch ol in our industro y.
Log onto www.installerinstitute.com
or call 8 0-354-6782 for mo nformation 0 re i
and take steps toward a be ter tomorrot w.
99-7320
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Open glove box and remove (2)
Phillips screws from top edge of
glove box opening and bottom edge
of wood trim below radio.
(Figure A)
2
HYUNDAI SONATA 2006-2008
Unclip and r ve wood trim fromemo
below radio and above glove box.
(Figure B)
3
Remove (1) Phillips screw per side
panel next to radio then unclip and
remove panels.
(Figure C)
4
Remove (6) Phillips screws from
radio to extract from sub dash.
(Figure D)
5
DASH DISASSEMBLY
A
OF F
AU TO
B
FM1 95.7
2 14
Lo
93
D
FM1 95. 7
2 1
4
Lo
93
C
