INSTALLATION INSTRUCTIONS FOR PART 99-7010
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
KIT AT SFE URE
DIN Head unit provision with po et ck
ISO DIN Head unit provision with pocket
DDIN Head unit provision
ISO Stacked Head unit provision
Painted Silver to Match Factory
A) Radio Housing B) ISOBrackets C) IS O Trim Pla te D) DDIN Bra Po etckets E) ck F) DDIN Trim Plate
KIT COM SPONENT
TOOLS REQUIRED :
99-7010
A
APPLICATI SON
Mitsubishi Ec pseli
2006-2011
CD
B
Phillips Sc rewdriver Small Flat Blad e rSc ewdri erv
EF
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Wire harness:
MITO-01 Mitsubishi amp interface harness 2006-up
70-7001 Mitsubishi harness 1992-up
Antenna adapter:
Not required
Dash Disassembly
Mitsubishi Eclipse 2006-2011 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Radio Housing Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Kit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3, 4
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
TABLE OF CONTENTS
99-7010
K
NOWLEDGE IS
P
OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take
steps toward a better tomorrow.
99-7010
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove the trim panel
including the radio a/c vents
(Figure A)
2
MITSUBISHI ECLIPSE 2006-2011
Remove (4) Phillips screws securing
radio chassis to dash to remove.
(Figure B)
3
Unclip and remove the a/c vents
from the factory radio trim panel.
(Figure C)
4
Unclip and remove the hazard switch
from the factory radio trim panel.
(Figure D)
5
DASH DISASSEMBLY
A
B
REAR VIEW
C
D
