METRA. THE WORLD’S BEST KITS.™
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
APPLICATIONS
KIT FEATURES
KIT COMPONENTS
TOOLS REQUIRED
1-800-221-0932 metraonline.com
METRA. THE WORLD’S BEST KITS.™
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
REV. 2/09/2010
1-800-221-0932 metraonline.com
INSTALLATION INSTRUCTIONS FOR PART 95-8226BINSTALLATION INSTRUCTIONS FOR PART 95-8226B
TOYOTA PRIUS
2010
95-8226B
• DDIN Head Unit Provision
• Stacked ISO DIN Head Unit Provision
• Painted Scratch Resistant Matte Black
• A) DDIN Radio HousingB) DDIN Brackets • C) Radio Housing Trim Panel • D) Trim Plate
• Phillips Screwdriver • Panel Removal Tool • Socket Wrench
WIRING & ANTENNA CONNECTIONS (SOLD SEPARATELY)
• 70-1761 Toyota Harness 1987-UP
TYTO-01 Toyota Prem Sound Interface
ABC D
TABLE OF CONTENTS NOTES
DASH DISASSEMBLY
• 2010 TOYOTA PRIUS . . . . . . . . . . . . . . . . . . 1
KIT ASSEMBLY
• 2010 TOYOTA PRIUS
• DDIN / STACKED ISO HEAD UNIT PROVISION. . 2
**NOTE: Refer Also to the instructions included with the aftermarket radio.
*CAUTION: Metra recommends disconnecting the negative
battery terminal before beginning any installation. All
accessories, switches, and especially air bag indicator
lights must be plugged in before reconnecting the
battery or cycling the ignition.
Metra recommends MECP certified
technicians
KNOWLEDGE IS ERPOW
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better tomorrow.
95-8226B 95-8226B
1
2010 TOYOTA PRIUS
95-8226B DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
Unsnap and remove the shifter trim.
(Fig. A)
Unsnap and remove the console
panel (extends from the pocket up the
passenger side to the upper vents).
(Fig. B)
Unsnap the ignition button trim panel
(not necessary to remove). (Fig. C)
Unsnap and remove the radio/ climate
trim panel. (Fig. C)
Remove four ten mm bolts to remove
the radio.
1
2
3
4
5
6
A
B
C
Continue to Kit Assembly
NOTES
95-8226B
