INSTALLATION INSTRUCTIONS FOR PART 95-8211
95-8211
KIT FEATURES
• Double DIN Radio Provision
Stacked ISO Mount Units Provision
A) Double DIN Trim Plate
KIT COMPONENTS
A
Small Flat Blade Screwdriver Panel Removal Tool
Phillips Screwdriver Socket Set
1-800-221-0932
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
www.metraonline.com
TOOLS REQUIRED:
APPLICATIONS
Toyota Avalon
2000-2004
Dash Disassembly
-Toyota Avalon 2000-2004 (column shift models) . . . . . . . . . . . . . . . . . . . . . 1
-Toyota Avalon 2000-2004 (console shift models) . . . . . . . . . . . . . . . . . . . . . 2
Kit Assembly
- Double DIN Radio Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
- Stacked ISO Mount Units Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
TABLE OF CONTENTS
95-8211
*Note:
Refer also to the instructions included with the aftermarket radio.
95-8211 DASH DISASSEMBLY
TOYOTA AVALON 2000-2004
(column shift models)
A
B
1
Disconnect the negative battery-
terminal to prevent an accidental
short circuit.
1
Unsnap the trim below the cli-
mate control to reveal (2) 10 MM
bolts and remove.
(Figure A)
2
Carefully pull air vents above
radio towards rear of car to
unsnap. NOTE: There are (3)
snaps, (2) are at the bottom sides
and (1) is at the top middle of the
vent assembly.
(Figure B)
3
Remove (2) 10 MM bolts from
above radio/climate control
assembly. Unplug and remove
assembly together.
(Figure C)
4
5
Remove (6) Phillips screws (4
from radio and 2 from climate
control) from eac side bracket toh
separate radio and climate con-
trol. (Save climate controls and
brackets to reuse during kit
assembly).
(Figure D)
Continue to kit assembly.
C
D
R
OFF
A/C
*Note: Refer also to the instructions included with the aftermarket radio.
