INSTALLATION INSTRUCTIONS FOR PART 95-7953
95-7953
KIT FEATURES
Double DIN Radio Provision
Stacked ISO Mount Units Provision
A) Radio Housing B) Double DIN Brackets C) Double DIN Trim Plate
KIT COMPONENTS
A
BC
Small Flat Blade Screwdriver Panel Removal Tool
Phillips Screwdriver Socket Set
1-800-221-0932
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
www.metraonline.com
TOOLS REQUIRED:
APPLICATIONS
Suzuki Grand Vitara
2006-2010
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Wiring Harness:
• 70-1721 - Honda/Acura harness 1998-up
Antenna Adapter:
• Not required
Dash Disassembly
-Suzuki Grand Vitara 2006-2010. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit Assembly
- Double DIN Radio Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
- Stacked ISO Mount Units Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Final Assembly .......................................... 4
TABLE OF CONTENTS
95-7953
*Note:
Refer also to the instructions included with the aftermarket radio.
K
NOWLEDGE IS
P
OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take
steps toward a better tomorrow.
95-7953 DASH DISASSEMBLY
SUZUKI GRAND VITARA 2006-2010
A
B
1
Disconnect the negative battery-
terminal to prevent an accidental
short circuit.
1
Unclip and remove the (2) outside
trim panels.
(Figure A)
2
Remove (6) Phillips screws secur-
ing the radio and climate controls
to the sub dash. Unplug and
remove radio/climate control
assembly.
(Figure B)
3
Remove the (2) Phillips screws
securing the factory radio bracket
to the radio/climate control
assembly.
(Figure C)
4
5
Separate the bracket and factory
radio from the climate control.
(Figure D)
Continue to kit assembly.
CD
*Note: Refer also to the instructions included with the aftermarket radio.
