METRA. The World’s best kits.™metraonline.com © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
REV. 3/8/2016 INST95-7877
Installation instructions for part 95-7877
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• ISO DDIN radio provision
• Painted to match factory dash
95-7877S – Silver
95-7877B – Matte Black
• A) Radio housing • B) ISO DDIN brackets • C) ISO DDIN trim plate
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-1729
Antenna Adapter: • 40-HD10 • 40-HD11 (with NAV)
• Panel removal tool • Phillips screwdriver • 8mm Socket wrench
TOOLS REQUIRED
Dash Disassembly ..................................................2
Kit Preparation ........................................................3
Kit Assembly
– ISO DDIN radio provision 3 ......................................
Table of Contents
B CA

95-7877
1. Unclip and remove the lower
center panel below radio.
(Figure A)
2. Remove (1) 8mm bolt facing up
behind center panel.
Slide the recirculation Note:
control lever to FRESH for better
access to bolt. (Figure A)
3. Open the upper glove box then use
a pry tool to unclip and remove the
radio/climate control assembly.
(Figure B & C)
4. Remove (2) Phillips screws
securing the hazard switch to the
back of the factory radio panel.
(Figure D)
Dash Disassembly
(Figure A)
(Figure D)
(Figure B)
(Figure E)
(Figure C)
5. Remove (2) Phillips screws
securing the air bag light to the
back of the factory radio panel.
(Figure E)
6. Remove (5) Phillips screws
securing the A/C vents to the
radio panel.
7. Remove (7) retaining clips from
radio housing to be used later in kit
preparation.
Continue to kit preparation

95-7877
Kit Preparation Kit Assembly
1. Secure the hazard switch into the
radio housing panel using the
factory hardware. (Figure A)
2. Secure the air bag light into the
radio housing panel using the
factory hardware. (Figure A)
3. Secure the A/C vents to the
radio housing using the factory
hardware. (Figure B)
4. Attach the (7) retaining clips to the
radio housing panel in the same
location as removed from the
factory radio panel.
Continue to kit assembly
ISO DDIN radio provision
1. Snap the ISO DDIN brackets
into the inside edge of the radio
housing. (Figure A)
2. Slide the radio into the bracket/
radio housing assembly and secure
the radio into the assembly using
the screws supplied with the radio.
(Figure B)
3. Snap the onto ISO DDIN trim plate
the front of the radio/housing
assembly. (Figure B)
4. Locate the factory wiring harness
and antenna connector in the
dash, and complete all necessary
connections to the radio. Metra
recommends using the proper
mating adapter from Metra and/or
AXXESS. Test the radio for proper
operation.
5. Reassemble the dash in reverse
order of disassembly.
(Figure A) (Figure A)
(Figure B) (Figure B)
