INSTALLATION INSTRUCTIONS FOR PART 95-7425
95-7425
APPLICATIONS
Nissan Rogue 2008-11
KIT FEATURES
• Double DIN Radio Provision
• Stacked ISO Mount Units Provision
A) Double DIN Radio Housing B) Double DIN Brackets
Harness & Antenna Connections (sold separately)
70-7552 - Nissan Harness 07-up
40-NI12 - Nissan Antenna Adapter 07-up
KIT COMPONENTS
A
TOOLS REQUIRED:
Small Flat Blade Screwdriver/ Panel Removal Tool
Phillips Screwdriver
1-800-221-0932
© COPYRIGHT 2008-10 METRA ELECTRONICS CORPORATION
www.metraonline.com
B
Dash Disassembly
-
Nissan Rogue 2008-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1,2
Kit Assembly
- Double DIN/ Stacked ISO Mount Units Provision . . . . . . . . . . . . . . . . . 3
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
TABLE OF CONTENTS
95-7425
*Note:
Refer also to the instructions included with the aftermarket radio.
95-7425 DASH DISASSEMBLY
NISSAN Rogue 2008-11
A
B
C
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
If equipped with center speaker:
Unclip and remove the grille
(Figure A).
Remove (4) Phillips screws
securing the speaker. Unplug and
remove the speaker.
(Figure B).
Unclip the panel above the radio
including the a/c vents, then unplug
hazard switch and remove.
(Figure C)
2
Continued on page 2.
Note: If not equipped with center
speaker skip step number 2.
