METRA - The World’s best kits ®metraonline.com
Installation instructions for part 95-7357HG
®
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2016 METRA ELECTRONICS CORPORATION
REV. 9/13/2016 INST95-7357HG
• ISO DDIN radio provision
Painted high gloss black
A) Radio housing trim panel • B) Brackets
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-7304
Antenna Adapter: • Not required
• Panel removal tool Phillips screwdriver
TOOLS REQUIRED
(without NAV)
Dash Disassembly ................................................. 2
Kit Assembly
ISO DDIN radio provision 3 ......................................
AB
Table of Contents
95-7357HG
Dash Disassembly
1. Unsnap and remove the vent
panels from either side of the radio
down to the shifter base.
(Figure A)
2. Remove the (4) screws and
remove the radio. (Figure B)
Continue to kit assembly
(Figure A)
(Figure B)
95-7357HG
Kit Assembly
ISO DDIN radio provision
1. Attach the to the brackets radio
housing trim panel. (Figure A)
2. Slide the radio into the bracket/
radio housing assembly and secure
with the screws supplied with the
radio. (Figure B)
3. Locate the factory wiring harness
in the dash. Metra recommends
using the proper mating adapter
from Metra or AXXESS. Test the
unit for proper operation.
4. Reassemble the dash in reverse
order of disassembly.
(Figure A) (Figure B)
