INSTALLATION INSTRUCTIONS FOR PART 95-7337B
95-7337B
KIT FEATURES
• DDIN Head Unit Provision
ISO Stacked Head Unit Provision
Painted Matte Black
A) Double DIN Trim Plate B) Double DIN Brackets
KIT COMPONENTS
A
Small Flat Blade Screwdriver Panel Removal Tool
Phillips Screwdriver
1-800-221-0932
© COPYRIGHT 2007-2009 METRA ELECTRONICS CORPORATION
www.metraonline.com
TOOLS REQUIRED:
APPLICATIONS
KIA Soul
2010
B
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Harness:
• 70-7303 - Kia / Hyundai Harness 2009-up
Antenna Adapter:
40-KI11 - Kia / Hyundai Antenna Adapter 2007-up
Dash Disassembly
-KIA Soul 2010 ...................................................1
Kit Assembly
- DDIN / Stacked ISO DIN Head Unit Provisions . . . . . . . . . . . . . . . . . . . . . . . . 2
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
TABLE OF CONTENTS
95-7337B
*Note:
Refer also to the instructions included with the aftermarket radio.
K
NOWLEDGE IS
P
OWER
Enhanc our installation and fabrication skille y s by
enrolling in the most recognize an espected d r d
mobile electronics sch ol in our industro y.
Log onto www.installerinstitute.co cam or ll
800-354-6782 for more informatio an take stepn d s
towa a etter tomorrord b w.
Metra recommends MECP certified
technicians.
95-7337B DASH DISASSEMBLY
KIA SOUL 2010
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the radio/climate
control trim panel.
(Figure A)
2
Remove (4) Phillips screws securing
the climate control.
(Figure B)
3
Remove (4) Phillips screws securing
the radio.
(Figure C)
4
Continue to kit assembly.
A
B
C
