CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
Metra. The World’s Best Kits.® MetraOnline.com © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION REV. 10/26/17 INST95-7319
I N S TA L L AT I O N I N S T R U C T I O N S
95-7319
KIT FEATURES
ISO DDIN radio provision
KIT COMPONENTS
• A) Radio housing • B) Radio brackets • C) A/C control brackets
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly
–ISO DDIN radio provision .....................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7301
Antenna Adapter: Not required
A B C
Kia Amanti 2004-2006
1.800.221.0932
|
MetraOnline.com
2
1. Unclip and remove panel surrounding
shifter including cup holders. (Figure A)
2. Remove (2) Phillips screws at base
of panel surrounding radio and a/c
controls. (Figure B)
3. Unclip and remove panel surrounding
radio and a/c control. (Figure C)
4. Remove (6) Phillips screws securing
radio and a/c control. (Figure D)
5. Remove (4) Phillips screws securing
factory a/c control to bracket assembly.
(Figure E)
Continue to Kit Assembly
P
R
N
D
VOL
LOAD
ESP
2 Phillips screws on each side
(Figure B) (Figure D)
(Figure A) (Figure C) (Figure E)
DASH DISASSEMBLY
REV. 10/26/2017 INST95-7319 3
(Figure A) (Figure B) (Figure C)
KIT ASSEMBLY
ISO DDIN radio provision
1. Attach the corresponding
a/c control
brackets
to the factory a/c control using
the factory hardware. (Figure A)
Note:
The radio housing must be
installed first before the a/c control.
2. Secure the
radio brackets
to the radio
with screws supplied with the radio.
(Figure B)
3. Slide the radio into the radio opening of
the sub-dash.
4. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio. Metra recommends using
the proper mating adapter from Metra
and/or AXXESS. Test the radio for proper
operation.
5. Secure the
radio housing
onto the
completed assembly using the factory
screws. (Figure C)
6. Reassemble the dash in reverse order of
disassembly.
