120 95-5817 Supplemental Instructions
for Double-DIN Receiver Applications
120 95-5817I
Revision 04/05/11
*120955817I*
Permanent modifications will be necessary in order
to allow a Double-DIN receiver to fit into the dash of
vehicles that use the 120 95-5817 installation kit.
Removal of dash material is required. Once
modifications are made, the factory unit may not
properly fit if reinstalled.
Notes:
Do not remove too much material. It is better to
remove portions and measure or test fit as you go.
Test fit using the receiver only. The side brackets
should not be in place. If the receiver is fully
snapped into place, it cannot be removed without
the dash panel being removed.
1. Using a file or rotary tool, carefully remove
portions from the top and bottom rim of the dash
opening as shown.
2. Once a proper fit is achieved, complete
receiver installation following instructions supplied
with the 120 95-5817 installation kit.
Tools Required
File or
Rotary
Tool
Copyright 2011 Crutchfield Corporation
R
1-800-955-9094
TECHNICAL SUPPORT
Cut
Cut
Cut
Cut out
out
out
out these
these
these
these areas
areas
areas
areasCut out these areas
Always be careful when cutting or drilling in a vehicle. WEAR
EYE PROTECTION. Be aware of things such as wiring,
windows, fuel lines and safety devices. Check drilling depth
and location to avoid damage to vehicle appearance.
CAUTION:
!

REV. 7/1/2016 INST95-5817
METRA. The World’s best kits.™metraonline.com © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
Installation instructions for part 95-5817
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• ISO DDIN radio provision
Note:
• Sub-dash modifications are necessary to use this
dash kit. You will need to trim the sub-dash to gain
suitable depth and height.
• Once the kit is snapped in, it cannot be removed
without dash panel removal.
• A) ISO DDIN brackets • B) Filler bar
20;-,(;<9,:
20;*64765,5;:
>0905.(5;,55(*655,*;065: (sold separately)
Wiring Harness:
• Please visit metraonline.com for wiring
harness options
Antenna Adapter:
• Not required
• Dremel/Cutting tool • Metra 86-5618 removal keys
;663:9,8<09,+
Ford multi-kit 1995-2011
95-5817
AB
(7730*(;065:
See application list inside cover

95-5817
Applications
2
Ford
Crown Victoria ....................................................................... 1995-2011
Econoline ............................................................................... 1997-2008
Escape................................................................................... 2001-2007
Excursion ............................................................................... 2000-2005
Explorer ................................................................................. 1995-2001
Explorer Sport Trac ................................................................2001-2005
F-250/350/450/550 ............................................................... 1999-2004
F-650/750 .............................................................................2000-2010
Ranger ................................................................................... 1995-2011
Windstar ................................................................................ 1999-2003
Lincoln
Continental ............................................................................ 1995-1997
Mark VIII ................................................................................ 1995-1998
Town Car ............................................................................... 1995-2002
Mazda
B-Series Pickup ..................................................................... 1995-2009
Mercury
Cougar (with 6 disc in-dash) ...................................................... 2000-2002
Grand Marquis ....................................................................... 1995-2011
Marauder ............................................................................... 2003-2004
Mariner .................................................................................. 2005-2007
Mountaineer .......................................................................... 1997-2001
Dash Disassembly
- All Vehicles ............................................... 3
Ford Crown Victoria 1995-2011
Ford Econoline 1997-2008
Ford Escape 2001-2007
Ford Excursion 2000-2005
Ford Explorer 1995-2001
Ford Explorer Sport Trac 2001-2005
Ford F-250/350/450/550 1999-2004
Ford F-650/750 2000-2010
Ford Ranger 1995-2011
Ford Windstar 1999-2003
Lincoln Continental 1995-1997
Lincoln Mark VIII 1995-1998
Lincoln Town Car 1995-2002
Mazda B-Series Pickup 1995-2009
Mercury Cougar (with 6 disc in-dash) 2000-2002
Mercury Grand Marquis 1995-2011
Mercury Marauder 2003-2004
Mercury Mariner 2005-2007
Mercury Mountaineer 1997-2001
Kit Assembly
- ISO DDIN radio provision .......................... 3
Table of Contents
