INSTALLATION INSTRUCTIONS FOR PART 95-3106
Phillips Screwdriver Panel Removal Tool Socket Set
1-800-221-0932 www.metraonline.com
KIT FEATURES
Rev. 12-02-09 © COPYRIGHT 2004-2007 METRA ELECTRONICS CORPORATION INST95-3106
Double DIN Head Unit Provision
Stacked ISO DIN Head Unit Provision
A) DDIN Brackets B) DDIN Trim Plate
KIT COMPONENTS
TOOLS REQUIRED:
95-3106
AB
APPLICATIONS
SATURN
2003-05 Ion / 2000-05 LS
2000-02 SL / 2002-05 Vue
WIRING CONNECTIONS (Sold Separately)
HARNESS:
70-2102 - GM 2004-05 HARNESS
70-2002 - SATURN 2000-05 HARNESS
METRA. THE WORLD’S BEST KITS.
95-3106
Dash Disassembly
2003-2005 Saturn Ion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2000-2005 Saturn LS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2000-2002 Saturn SL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2002-2005 Saturn Vue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Kit Assembly
DDIN / Stacked ISO DIN Head Unit Provisions . . . . . . . . . . . . . 4
TABLE OF CONTENTS
K
NOWLEDGE IS
P
OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends using
MECP certified technicians.
95-3106
1
Disconnect the negative battery
terminal to prevent an accidental short
circuit.
1
Unclip and remove the trim panel
surrounding the radio.
(Figure A)
2
2003-2005 SATURN ION
Remove (2) 9/32” screws from radio to
remove.
(Figure A)
3
DASH DISASSEMBLY
A
2000-2005 SATURN LS
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
B
Unclip and remove the trim panel
surrounding the radio.
(Figure B)
2
Remove (2) 9/32” screws from radio
to remove.
(Figure B)
3
