Strona 1/8
Audio Core 200
User Guide
Audio Core 200 User Guide2 EN
Important safety instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when unused for
long periods of time.
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
Use only with the mains power adapter supplied with the unit.
Replacements are available from your Meridian dealer.
Safety warnings
Do not expose the unit to dripping or splashing.
Do not place any object filled with liquid, such as a vase, on the unit.
Do not place naked flame sources, such as lighted candles, on
the unit.
To avoid overheating leave at least 10cm around the equipment to
ensure sufficient ventilation.
Do not position the unit in direct sunlight, near heat sources such as
a radiator, or directly on top of heat producing equipment, such as a
power amplifier.
To avoid interference do not position the unit near strong electrical or
magnetic radiation, such as near a power amplifier.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Radio interference
FCC Warning: This equipment generates and can radiate radio
frequency energy and if not installed and used correctly in accordance
with our instructions may cause interference to radio communications
or radio and television reception. It has been type-tested and complies
with the limits set out in Subpart J, Part 15 of FCC rules for a Class
B computing device. These limits are intended to provide reasonable
protection against such interference in home installations.
EEC: This product has been designed and type-tested to comply
with the limits set out in EN55013 and EN55020.
Copyright
Meridian Audio Ltd
Latham Road
Huntingdon
Cambridgeshire
PE29 6YE
England
Copyright © 2010 Meridian Audio Ltd.
Visit us on the Web:
http://www.meridian-audio.com
Part no: AC200 (P88393)
This guide was produced by: Human-Computer Interface Ltd,
http://www.interface.co.uk/
Unpacking
The Audio Core 200 is supplied with the following accessories:
Mains power adapter.
Remote control handset.
This manual.
If either of these items are missing please contact your dealer.
NOTE: You should retain the packaging in case you need to
transport the unit.
•
•
•
Audio Core 200 User Guide 3EN
Back panel
The following diagram gives details of the back panel connections:
i80 Dock
SpeakerLink
In/SLS
SpeakerLink
Out
Slave
Master
Power in
12V DC
300mA MAX
D1 CD
D2 Sat/Radio
Aux 1 Disc
Opt 1 Game
Aux 2 Cable
Opt 2 DVD
Headphones
A2 MixerMaintenanceUSB A1 TV
L
R
Meridian Audio Audio Core 200. Designed and made in England. Registered design and copyright © Meridian Audio Ltd 2010
Analogue
phono inputs
Digital
coax inputs
SpeakerLink
input
Power
input
i80
iPod dock
USB Maintenance Analogue/optical
inputs
Headphones
output
SpeakerLink
outputs
Outputs
Use this output To connect to this
SpeakerLink Out
Master, Slave
Digital loudspeakers, such as DSP3200,
using Meridian SpeakerLink leads.
Headphones A pair of headphones, terminated with a
3.5mm jack plug.
Analogue inputs
Use this input To connect to this
A1 TV, A2 Mixer Analogue sources, using stereo phono
leads.
Aux 1, Aux 2 Analogue sources, using stereo leads
terminated in a 3.5mm mini jack plug.
Digital inputs
Use this input To connect to this
D1 CD, D2 Sat/Radio Digital sources, using S/PDIF leads.
SpeakerLink In/SLS A Meridian source or Sooloos system
with a SpeakerLink output, using a
Meridian SpeakerLink lead.
USB A computer, using a USB cable
terminated in a Type B plug, to use the
AC200 as an external sound card.
Opt 1 Game, Opt 2 DVD Digital sources, using optical cables
terminated in 3.5mm optical jack plugs
(same sockets as Aux 1 and Aux 2).
i80 Dock An iPod mounted in a Meridian i80 dock,
with control of the iPod from the AC200
front panel.
