Strona 1/16
1
You can be killed or seriously injured if you don't immediately
You
can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To educe r the risk f e, ctric s o fir ele hock, or injury n usi whe ng your efrigerator, follow thes asic pr r e b ecautions:
SAVE THESE INSTRUCTIONS
■
Plug o int a grounded 3 pron utlet.g o
■
Do not remove ground prong.
■
Do no s dap r.t u e an a te
■
Do no s x siot u e an e ten n cord.
■
Disconnect p bower efore servicing.
■
Replace all pane parts and ls before operating.
■
Remove doors from your old refrigerator.
■
Connect to a potable water supply only.
■Use nonflammable cleaner.
■Keep flammable materials and vapors, such as gasoline,
■Disconnect power before installing ice maker (on ice maker
kit ready models only).
■
Us stue a rdy glass en disp wh ensin g ic (o me me n so odels).
■
Do not hit the refrigerator glass doors (on some models).
■
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental , capabilities or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance
USER GUIDE
SIDE BY SIDE REFRIGERATOR
LEARN MORE
In an effort to conserve natural resources, this refrigerator includes a condensed User Guide. A complete User Instructions manual for
your model can be downloaded at www.maytag.com/manuals. The model number is located on the inside wall of the refrigerator
compartment.
For assistance or service, call in the U.S.A. or in Canada.1-800-253-1301 1-800-807-6777
Register your refrigerator at www.maytag.com. www.maytag.ca. In Canada, register at
Para instrucciones en español, visite www.maytag.com.
W11323751A
away from refrigerator.
■ Use o or more people to move and instal refrigera or. tw l t
■ If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person
in order to avoid a hazard.
■ Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
by a person responsible for their safety.
■ Children should be supervised to ensure that they do not play
with the appliance.
■ This appliance is intended to be used in household and similar
applications such as
–Staff
kitchen areas in shops, offices and other working environments;
–Farm houses and by clients in hotels, motels and other residential type
environments;
–Bed and breakfast type environments;
–Catering and similar non-retail applications..
2
Proper Disposal of your old refrigerator: IMPORTANT: Child entrapment and suffocation are not
problems of the past. Junked or abandoned refrigerators are still
dangerous, even if they will sit for “just a few days.” If you are
getting rid of your old refrigerator, please follow these instructions
to help prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
JTake off the doors.
JLeave the shelves in place so that children may not easily
climb inside.
Using the Controls
The refrigerator and freezer controls are located on the dispenser
panel.
IMPORTANT: The display screen on the dispenser control
panel will turn off automatically and enter “sleep” mode when
the control buttons and dispenser lever have not been used for
2 minutes or more. While in “sleep” mode, the first press of a
control button will only reactivate the display screen, without
changing any settings.
JTouch any control button on the dispenser panel to activate
the display screen. The home screen will appear as shown.
Adjusting the Controls
For your convenience, your refrigerator and freezer controls are
preset at the factory. When you first install your refrigerator, make
sure that both the refrigerator and freezer controls are still set to
the recommended “mid-setting.” This will be displayed in the
sequence of bars with three illuminated bars.
IMPORTANT:
JWait 24 hours before you put food into the refrigerator. If you
add food before the refrigerator has cooled completely, your
food may spoil.
NOTE: Adjusting the set points to a colder than
recommended setting will not cool the compartments any
faster.
JIf the temperature is too warm or too cold in the refrigerator
or freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
JThe preset settings should be correct for normal household
usage. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
JWait at least 24 hours between adjustments. Recheck the
temperatures before other adjustments are made.
When adjusting set points, use the following chart as a guide:
CONDITION: ADJUSTMENT:
Refrigerator too cold Refrigerator setting one
setting lower
Refrigerator too warm Refrigerator setting one
setting higher
Freezer too cold Freezer setting one setting
lower
Freezer too warm/too little ice Freezer setting one setting
higher
The set point range is “1 bar” least cold to “5 bars” coldest.
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
WARNING
Important information to know about disposal of
refrigerants:
Dispose of freezer in accordance with Federal and Local
regulations Refrigerants must be acuated a licensed, . ev by
EPA certified refrigerant technician in accordance with
established procedures.
OPERATING YOUR REFRIGERATOR
3
Refrigerator Control:
JPress REFRIGERATOR TEMP to view the current set point for
the refrigerator.
JPress REFRIGERATOR TEMP again to adjust the set point.
The setting will increase by 1 bar with each press of the
button, returning to 1 bar after reaching 5.
After 2 minutes of inactivity, any changes will be saved and
the display will return to the home screen.
Freezer Control:
JPress FREEZER TEMP to view the current set point for the
freezer.
JPress FREEZER TEMP again to adjust the set point. The
setting will increase by 1 bar with each press of the button,
returning to 1 bar after reaching 5.
After 2 minutes of inactivity, any changes will be saved and
the display will return to the home screen.
Crisper Humidity Control
You can control the amount of humidity in the moisture-sealed
crisper. Adjust the control to any setting between low and high.
LOW (open) for best storage of fruits and vegetables with skins.
HIGH (closed) for best storage of fresh, leafy vegetables.
Water and Ice Dispensers
NOTES:
JThe dispensing system will not operate when the freezer door
is open.
JAllow 24 hours for the refrigerator to cool down and chill
water.
JAllow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced. Wait 72 hours for full ice
production.
JThe display screen on the dispenser control panel will turn
off automatically and enter “sleep” mode when the control
buttons and dispenser lever have not been used for 2 minutes
or more. While in “sleep” mode, the first press of a control
button will only reactivate the display screen, without
changing any settings.
Flush the Water System
Air in the water dispensing system can cause the water dispenser
to drip. After connecting the refrigerator to a water source or
replacing the water filter, flush the water system. Flushing the
water dispensing system forces air from the water line and filter,
and prepares the water filter for use.
NOTE: As air is cleared from the system, water may spurt out of
the dispenser.
1. Using a sturdy container, depress and hold the water
dispenser lever for 5 seconds, then release it for 5 seconds.
2. Repeat Step 1 until water begins to flow.
3. Once water begins to flow, continue depressing and releasing
the dispenser lever (5 seconds on, 5 seconds off) until a total
of 3 gal. (12 L) has been dispensed.
Additional flushing may be required in some households.
The Water Dispenser
IMPORTANT:
JDispense at least 1 qt (1 L) of water every week to maintain a
fresh supply.
JIf the flow of water from the dispenser decreases, it could be
caused by low water pressure.
JWith the water filter removed, dispense 1 cup (237 mL) of
water. If 1 cup of water is dispensed in 8 seconds or less,
the water pressure to the refrigerator meets the minimum
requirement.
JIf it takes longer than 8 seconds to dispense 1 cup of
water, the water pressure to the refrigerator is lower than
recommended. See “Water Supply Requirements” (in
the User Instructions or the Installation Instructions and
Owner’s Manual) or “Troubleshooting” for suggestions.
To Dispense Water:
1. Press a sturdy glass against the water dispenser lever. Hold
the glass close to the water dispenser spout to ensure that
the water dispenses into the glass.
2. Remove the glass to stop dispensing.
IMPORTANT: The small tray at the bottom of the dispenser
is designed to catch small spills and allow for easy cleaning.
There is no drain in the tray.
Ice and Water
