© LINDY Group - FIRST EDITION (August 2019)
USB 3.1 Type C Multi-Port Converter
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Fraais
Manuale Italiano
No. 78 432
lindy.com
Tested to comply with
FCC Standards
For Home and Oce Use!
User Manual English
Introduction
Thank you for purchasing the USB 3.1 Type C Multi-Port Converter This product has been designed to
provide trouble free, reliable operation. It benets from both a LINDY 2 year warranty and free lifetime
technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
This USB 3.1 Type C Multi-Port Converter allows you to maximise the functionality of a single USB 3.1
Type C port by connecting an HDMI display, a VGA monitor, up to three USB 3.1/3.0 SuperSpeed
peripherals as well as a USB Type C power supply to your Macbook or notebook. Through the RJ45 port
you can access a Gigabit Ethernet Network and it is also possible to access SD or microSD cards. Please
note that a USB 3.1 Type-C port with support for DisplayPort Alternate Mode is required for video
functionality.
Package Contents
USB 3.1 Type C Multi-Port Converter
This manual
Features
Compatible with all USB Type C equipped computers with DisplayPort Alternate Mode
Input: USB 3.1 Type C connector – male, 1x USB Type C female (only for charging, no data transfer)
Output: HDMI A female, VGA female, 3x USB Type 3.1 Gen 1 / 3.0 Type A female, RJ45 female, SD
and microSD card slot
USB 3.1 Gen 1 / 3.0 standard (5 Gbps)
Max. resolution: 3840 x 2160 30Hz (HDMI), 1920x1080@60Hz (VGA)
Works as a splitter if both VGA and HDMI are connected at the same time, max. resolution
1920x1080@60Hz with the same video content
10/100/1000Mbps Gigabit Ethernet
USB Type C Power Delivery input port for charging (no data transfer) with max. 0W (20V / 510 A)
Installation & Operation
The USB 3.1 standard allows USB ports to optionally feature DisplayPort Alternate Mode; this uses the
USB C connector as a video output without the need for additional drivers or software. Please check that
your computer supports this feature.
To begin using this Multi-Port Converter simply connect the USB 3.1 Type C male connector to the USB
3.1 Type C port of your computer. Any required drivers will be automatically downloaded from the internet.
Connect the HDMI socket and/or VGA socket of the converter to the HDMI/VGA port of your monitor or
projector using appropriate male to male cables (not included). Use a standard RJ45 Ethernet cable (not
included) to connect to your network. Additional USB devices can be connected to the USB Type A ports
of the Mini Docking Station, USB 3.1 Gen1 5Gbps data transfer rates are supported whilst legacy USB
2.0/1.1 devices may also be connected. The SD and microSD card slots allow access to SD and micro SD
cards.
By connecting a compatible USB Type C power supply (not included) it is also possible to charge your
Macbook or Notebook using the Type C Power Delivery port, just connect the power supply to the Power
Delivery port when required.
