www.lg.com
Please read this manual carefully before operating your set and retain it
for future reference.
webOS 3.0
USER GUIDE
LG Digital
Signage
(MONITOR SIGNAGE)
ENGLISH_ ind ex
2
TABLE OF CONTENTS
USER SETTINGS 3 ............................
- Main Menu Settings 3 ........................................................
Picture Settings
Sound Settings
Network Settings
General Settings
ENTERTAINMENT 15 ......................
- Using Multimedia Features.......................................15
Connecting USB/SD Storage Devices
- Photo & Video 18 ..................................................................
Supported Photo & Video Files
Viewing Photos and Videos
Scheduled Playing
Export
Delete
- Music 22 ....................................................................................
Supported Music Files
Playing Music
Delete
- SuperSign Contents 23 .....................................................
- Information 23 .......................................................................
- Local Contents Scheduler 24 .........................................
Setting a Scheduled Playing
- Screen Share 25 ....................................................................
Configuring WiDi (Wireless Display)
- Group Manager 26 ...............................................................
- Leveler Tool........................................................................28
- Control Manager 29 ............................................................
How to Use
Follow the steps below if you encounter issues
with your security certificate while attempting
to access.
- Multi-Screen 34 .....................................................................
- 35PICTURE ID Settings ....................................................
IR CODES 36 ....................................
TO CONTROL MULTIPLE
PRODUCTS 38 ..................................
- Connecting the Cable 38 ..................................................
- Communication Parameter 39 ......................................
- Command Reference List 40 ..........................................
- Transmission/Reception Protocol 44 .........................
To obtain the source code under GPL, LGPL, MPL,
and other open source licenses, that is contained
in this product, please visit http://opensource.lge.
com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices
are available for download.
LG Electronics will also provide open source code
to you on CD-ROM for a charge covering the
cost of performing such distribution (such as the
cost of media, shipping, and handling) upon email
request to opensource@lge.com.
This offer is valid for a period of three years after
our last shipment of this product. This offer is
valid to anyone in receipt of this information.
ENGLISH_ ind ex
3
NOTE
•The software-related contents may be changed without prior notice due to upgrade of the product functions.
•Some features described in the User Guide may not be supported in certain models.
•SNMP 2.0 is supported.
USER SETTINGS
Main Menu Settings
Picture Settings
To Select Picture Mode
/ [Picture] [Picture Mode Settings] [Picture Mode]
Select the picture mode that is best suited to the video type.
•[Vivid]: Adjusts the video image for a retail environment by enhancing the Contrast, Brightness, and Sharpness.
•[Standard]: Adjusts the video image for a normal environment.
•[APS]: APS (Auto power saving) mode reduces power consumption by dimming control.
•[Cinema]: Optimizes the video image for watching movies.
•[Sports]: Optimizes the video image for watching sports. Even fast actions such as kicking or throwing a ball are
rendered clearly on the screen.
•[Game]: Optimizes the video image for playing videogames.
•[Photo]: Optimizes the screen for viewing photos. (This feature is available only with certain models.)
•[Expert]/[Calibration]: Allows an expert, or anyone interested in high quality pictures, to manually tune the picture for
the best picture quality.
NOTE
•Depending on the input signal, the available Picture modes may differ.
•[Expert] is an option that allows a picture quality expert to fine-tune the picture quality using a specific image. Thus,
it may not be effective for a normal picture.
ENGLISH_ ind ex
4
To fine-tune the picture mode
/ [Picture] [Picture Mode Settings] [Customize]
•[Backlight]/[OLED Light]: Adjusts the brightness of the screen by controlling the LCD backlight. The closer the value
is to 100, the brighter the screen is.
•[Contrast]: Ajusts the difference between the light and dark areas of the picture. The closer the value is to 100, the
greater the difference is.
•[Brightness]: Adjusts the overall brightness of the screen. The closer the value is to 100, the brighter the screen is.
•[Sharpness]: Adjusts the sharpness of the edges of objects. The closer the value is 50, the clearer and the sharper the
edge becomes.
•[H Sharpness]: Adjusts the sharpness of the contrast edges on the screen from a horizontal point of view.
•[V Sharpness]: Adjusts the sharpness of the contrast edges on the screen from a vertical point of view.
•[Color]: Softens or deepens the tints on the screen. The closer the value is 100, the deeper the colors become.
•[Tint]: Adjusts the balance between red and green levels displayed on the screen. The closer the value is to Red 50,
the deeper the color red becomes, and the closer the value is to Green 50, the deeper the color green becomes.
•[Color Temperature]: Adjusts the tints of the screen to evoke feelings of warmth or coolness.
•[Advanced Controls]/[Expert Control]: Customizes the advanced options.
- [Dynamic Contrast]: Optimizes the difference between the light and dark parts of the screen according to the
brightness of the image.
- [Super Resolution]: Sharpens the blurry or indistinguishable parts of the picture.
- [Color Gamut]: Selects the range of colors to display.
- [Dynamic Color]: Adjusts the tint and saturation of the image for a more vivid and lively display.
- [Edge Enhancer]: Provides much sharper and clearer edges to the picture.
- [Color Filter]: Accurately adjusts color and tint by filtering a specific color area of RGB space.
- [Preferred Color]: Adjusts the skin tint, grass tint, and sky tint to your preference.
- [Gamma]: Adjusts the medium brightness of the image.
- [White Balance]: Adjusts the overall tint of the picture to your preference. In Expert mode, you can fine-tune the
picture using the Method/Pattern options.
- [Color Management System]: Experts use the color management system when they adjust the colors by using the
test pattern. The color management system allows you to make an adjustment by selecting from among 6 different
color spaces (Red/Yellow/Blue/Cyan/Magenta/Green) without affecting other colors. You may not see tints change
in a normal picture even after adjustment.
ENGLISH_ ind ex
5
•[Picture Options]: Customizes the picture options.
- [Noise Reduction]: Removes irregularly generated tiny dots for a clear picture.
- [MPEG Noise Reduction]: Reduces the noise produced while creating digital video signals.
- [Black Level]: Adjusts the black level of the picture to correct the brightness and contrast of the picture.
(Recommended settings according to input signal: RGB 0–255: High, RGB 16–235: Low, YCbCr: Low)
- [Real Cinema]: Optimizes the video image for a cinematic look.
- [Motion Eye Care]: Reduces eye fatigue by adjusting brightness levels and lessening blurriness based on the
displayed image. (Only applies to certain models.)
- [LED Local Dimming]: Brightens the brighter parts of the image and darkens the darker parts, maximizing contrast.
Turning this feature off may lead to increased power consumption. (Only applies to certain models.)
- [TruMotion]: Reduces image shaking and image sticking that can occur with moving images.
•[Reset]: Reset the picture settings. Because the picture settings are reset according to the monitor's picture mode,
please select the picture mode before resetting the picture settings.
NOTE
•You can adjust advanced settings only in the [User] mode.
•Depending upon the input signal or the selected picture mode, the available options may differ.
To set the aspect ratio
(Some features may not be supported in certain models.)
/ [Picture] [Aspect Ratio]
Changes the aspect ratio to view the image in its optimal size.
•[16:9]: Displays the image with a 16:9 aspect ratio.
•[Just Scan]: Displays the image in the original size without cutting off the edges. Original is available in HDMI (720p
or higher) mode. (On 58:9 models, this option can be selected regardless of the input signal.)
•[Original]: Automatically changes the aspect ratio to 4:3 or 16:9 depending on the input video signal.
•[4:3]: Displays the image with a 4:3 aspect ratio.
•[58:9]: Displays the screen with a 58:9 aspect ratio.
•[Vertical Zoom]: Adjusts the height and vertical position of the displayed image.
•[All-Direction Zoom]: Adjusts the horizontal/vertical/diagonal dimensions and horizontal/vertical position of the
displayed image.
CAUTION
•If a fixed image is displayed on the screen for a long period of time, it will be imprinted and become a permanent
disfigurement on the screen. This image burn or burn-in is not covered by the warranty.
•If the aspect ratio is set to [4:3] for a long period of time, image burn may occur on the letterboxed area of the
screen.
•The options may differ depending on the model.
•Depending on the input signal, the available aspect ratio may differ.
•When you adjust [Vertical Zoom] or [All-Direction Zoom], the screen may flicker for some input signals.
ENGLISH_ ind ex
6
To use the Energy Saving function
/ [Picture] [Energy Saving]
Reduces power consumption by adjusting peak screen brightness.
•[Auto]: Adjusts the brightness of the monitor according to ambient light. (This feature is available only with certain
models.)
•[Off]: Disables the Energy Saving mode.
•[Minimum]/[Medium]/[Maximum]: Uses the Energy Saving according to the Energy Saving level specified for your
monitor.
•[Screen Off]: Turns off the screen. You will only hear audio. You can turn on the screen again by pressing any button
on the remote control except the power button.
NOTE
•To revert to the default settings, either go to [General] [Reset to Initial Settings] or [Installation Menu] [Signage
Setup] [Factory Reset].
To use the Smart Energy Saving function
(Only applies to certain models.)
/ [Picture] [Smart Energy Saving]
According to picture brightness, the brightness of the monitor will be adjusted automatically to save energy.
•[Off]: Disables the Smart Energy Saving function.
•[On]: Enables the Smart Energy Saving function.
NOTE
•To revert to the default settings, either go to [General] [Reset to Initial Settings] or [Installation Menu] [Signage
Setup] [Factory Reset].
Configuring the OLED Display
(For OLED models only)
/ [Picture] [OLED Panel Settings]
•[Clear Panel Noise]: Corrects issues that may arise when the screen is turned on for a long period of time.
To use the SCREEN(RGB-PC) function
(Only applies to certain models.)
/ [Picture] [Screen(RGB-PC)]
Customizes the PC display options in RGB mode.
•[Set Automatically]: Sets to adjust the screen position, clock, and phase automatically. The displayed image may be
unstable for a few seconds while the configuration is in progress.
•[Resolution]: Selects a proper resolution.
•[Position]/[Size]/[Phase]: Adjusts the options when the picture is not clear, especially when characters are shaky,
after the auto configuration.
•[Reset]: Restores the options to the default setting.
ENGLISH_ ind ex
7
Sound Settings
•Only applies to certain models.
To select a Sound Mode
/ [Sound] [Sound Mode]
The best sound quality will be selected automatically depending on the video type currently being watched.
•[Standard]: This sound mode works well for content of all types.
•[Cinema]: Optimizes sound for watching movies.
•[Clear Voice III]: Enhances voices so they can be heard more clearly.
•[Sports]: Optimizes sound for watching sports.
•[Music]: Optimizes sound for listening to music.
•[Game]: Optimizes sound for playing videogames.
To use the Sound Effects function
/ [Sound] [Sound Mode Settings]
•[Equalizer]: Manually adjust sound by using the equalizer.
•[Balance]: Adjust the output volume for the left speaker and the right speaker.
•[Reset]: Reset the sound settings.
ENGLISH_ ind ex
9
Network Settings
To Set a Signage Monitor Name
/ [Network] [Signage Name]
You can set a name for Signage Monitor that will be used on the network by using the on-screen keyboard.
To Set Your Wired Network
/ [Network] [Wired Connection (Ethernet)]
•Connecting to a wired network: Connect your monitor to a local area network (LAN) via the LAN port, and configure
the network settings. Only wired network connections are supported. After making a physical connection, a small
number of networks may require the display network settings to be adjusted. For most networks, the display will
automatically make a connection without any adjustments. For detailed information, contact your Internet provider or
consult your router manual.
Setting a Wireless Network
(Only applies to certain models.)
/ [Network] [Wi-Fi Connection]
If you have set the monitor up for a wireless network, you can check and connect to the available wireless Internet
networks.
•[Add a Hidden Wireless Network]: If you input the name of network directly, you can add a wireless network.
•[WPS PBC connection]: Press the button on the wireless router that supports PBC to easily connect to the router.
•[WPS PIN Code connection]: Enter the PIN number in the web page of the PIN-supporting wireless router to connect
to the router in a simple manner.
•[Wi-Fi advanced settings]: Manually input the network information to connect to a wireless network. When a usable
wireless network does not appear, press Wi-Fi advanced settings. You will be able to add a network.
NOTE
•For models that support Wi-Fi Dongle, the Wireless Network Connection menu is enabled only when a Wi-Fi Dongle
is connected to the product.
•When connected to a network that supports IPv6, you can select IPv4 / IPv6 in the wired / wireless network
connection. But, IPv6 connection only supports automatic connection.
ENGLISH_ ind ex
10
Setting up a SoftAP
(Only applies to certain models.)
/ [Network] [SoftAP]
If you set up a SoftAP, you can connect many devices via a Wi-Fi connection without a wireless router and use wireless
Internet.
•To use SIGNAGE, you must have an Internet connection.
•You cannot use the SoftAP feature and the Screen Share feature at the same time.
•On models that support Wi-Fi dongles, the SoftAP menu is enabled only when a Wi-Fi dongle is connected to the
product.
•SoftAP connection information
- SSID: A unique identifier necessary to make a wireless Internet connection
- Security key: The security key you enter to connect to the desired wireless network
- Number of connected devices: Shows the number of devices currently connected to your Signage device via a Wi-Fi
connection. Up to 10 devices are supported.
Tips for Network Setting
•Use a standard LAN cable (Cat5 or higher with a RJ45 connector) with this display.
•Many network connection problems during set-up can often be fixed by re-setting the router or modem. After
connecting the display to the home network, quickly power off and/or disconnect the power cable of the home
network router or cable modem, then power on and/or connect the power cable again.
•Depending on the Internet Service Provider (ISP), the number of devices that can receive Internet service may be
limited by the applicable terms of service. For details, contact your ISP.
•LG is not responsible for any malfunction of the display and/or the Internet connection feature due to communication
errors/malfunctions associated with your Internet connection, or other connected equipment.
•LG is not responsible for problems with your Internet connection.
•You may experience undesired results if the network connection speed does not meet the requirements of the
content being accessed.
•Some Internet connection operations may not be possible due to certain restrictions set by the Internet Service
Provider (ISP) supplying your Internet connection.
•Any fees charged by an ISP including, without limitation, connection charges are your responsibility.
ENGLISH_ ind ex
11
NOTE
•If you want to access the Internet directly on your display, the Internet connection should always be on.
•If you cannot access the Internet, check the network conditions from a PC on your network.
•When you use Network Setting, check the LAN cable or check if DHCP in the router is turned on.
•If you do not complete the network settings, the network may not function correctly.
CAUTION
•Do not connect a modular telephone cable to the LAN port.
•Since there are various connection methods, please follow the specifications of your telecommunication carrier or
Internet Service Provider.
•Network Setting menu will not be available until the display is connected to a physical network.
Tips for Wireless Network Setting
•Wireless networks can be subject to interference from other devices operating at a frequency of 2.4 GHz (wireless
phones, Bluetooth devices or microwave ovens). There may also be interference from devices with a frequency of 5
GHz, same as other Wi-Fi devices.
•The surrounding wireless environment can cause the wireless network service to run slowly.
•If you do not turn off the entire local home network, network traffic may occur on some devices.
•For an AP connection, an access point device that supports wireless connection is required and the wireless
connection feature must be enabled on the device. Contact your service provider regarding availability of wireless
connection on your access point.
•Check the SSID and security settings of the AP for AP connection. Refer to the appropriate documentation for SSID
and security settings of the AP.
•Invalid settings on network devices (wired/wireless line sharer, hub) can cause the monitor to run slowly or not
operate properly. Install the devices correctly according to the appropriate manual and set the network.
•Connection method may differ according to the AP manufacturer.
ENGLISH_ ind ex
12
General Settings
To configure the language
/ [General] [Menu Language]
Select one of the languages on the menu displayed on the screen.
•[Menu Language]: Sets a language for Signage.
Setting up the keyboard language
/ [General] [Keyboard Languages]
Select the language you wish to show on the keyboard.
•[Keyboard Languages]: Sets the keyboard language.
To set the time/date
/ [General] [Time & Date]
You can check or change the time.
•[Set Automatically]: You can set Time and Date.
•[Daylight Saving Time]: You can set Start Time and End Time for Daylight Saving Time. The DST start/end settings
work only when you set them more than one day apart from each other.
•[NTP Server Setting]: Allows you to set other NTP servers other than the basic NTP server. (Only applies to certain
models.)
•[Time zone]: You can change the settings for Continent, Country/Territory, and City.
To turn your monitor on or off automatically
/ [General] [Timers]
You can set the On/Off Timer for your monitor.
•[On Timer]: You can set the time when your monitor turns on.
•[Off Timer]: You can set the time when your monitor turns off.
•[No Signal Power Off (15Min)]:When there is no input source, the monitor will automatically turn off after 15
minutes. If you don’t want it to turn off automatically, set No Signal Power Off to [Off].
•[Auto Power Off]:When there is no key input, the monitor will automatically turn off.
NOTE
•On Time/Off Time can be saved for up to seven schedules; the monitor is turned on or off at the preset time in the
schedule list. If multiple preset times are stored in the schedule list, this function works at the nearest time from the
current time.
•Once the on or off time is set, these functions operate daily at the preset time.
•The scheduled power-off function works properly only when the device time is set correctly.
•When the scheduled power-on and power-off times are the same, the power-off time has priority over the power-on
time if the set is turned on, and vice versa if the set is turned off.
ENGLISH_ ind ex
13
Configuring Set ID
/ [General] [Set ID]
•[Set ID](1 to 1000): Assigns a unique Set ID number to each product when several products are connected for
display. Assign numbers ranging from 1 to 1000 and exit the option. You can control each product separately by
using the Set ID you assigned to each product.
•[Auto Set ID]: Automatically assigns a unique Set ID number to each set when several products are connected for
display.
•[Reset Set ID]: Resets the Set ID of the product to 1.
NOTE
•When using automatic ID settings, the IR signal only needs to be transmitted to the first set. Malfunctions could
occur when the IR signal is transmitted to other sets.
Using Tile Mode
(Only applies to certain models.)
/ [General] [Tile Mode]
You can configure the integrated screen in the same way as each screen is configured.
•[Row](1 to 15): Sets the number of tile rows.
•[Column](1 to 15): Sets the number of tile columns.
•[Tile ID](1 to 225): Sets the Tile ID. The ID you selected will be displayed on the screen.
•[Natural]: For a more natural display, the image is partly omitted to account for the distance between the screens.
•[Natural Size]: Sets the distance between screens for Natural mode.
•[Reset]: Resets the tile settings to 2 x 2.
NOTE
•If Tile mode is set to On, Smart Energy Saving mode will be disabled to provide the same picture quality as other
displays.
•The maximum number of columns and lines that can be set may differ by model.
•To use this function, the product:
- Must be displayed with other products.
- Must be operated by connecting to each display via a distributor or DP daisy chain.
- Tile Mode: Horizontal x Vertical (Horizontal = 1 to 15, Vertical = 1 to 15)
- 15 x 15 is available
ENGLISH_ ind ex
14
Configuring the Dual-View Screen
(For double-sided flat OLED models only)
/ [General] [Dual-View Screen Setting]
•[Front Screen Name]: Sets the name of the front screen.
•[Back Screen Name]: Sets the name of the back screen.
•[Screen Swap]: Swaps the images on the front and back side of the screens.
•[Screen Mirroring]: Copies the image of the current screen to the opposite screen.
•[Screen Off]: Turns off the front or back screen.
•[Clone All Settings]: Copies all settings for the front screen to those for the back screen. This option is only enabled
for the front screen.
To reset your monitor settings
/ [General] [Reset to Initial Settings]
Resets all monitor settings.
Using UHD Deep Color
(For Ultra HD models only)
/ [General] [UHD Deep Color]
If you connect an HDMI or DP device to one of the Deep Color adjustable ports, you can select between Ultra Deep
Color On (6G) or Off (3G) in the UHD Deep Color settings menu.
If a compatibility issue occurs with the graphics card when the Deep Color option is set to On at 3840 x 2160 @ 60
Hz, set the Deep Color option to Off.
•HDMI and DP specifications may vary depending on the input port. Check the specifications of each device before
connecting.
•HDMI input ports 1 and 2 are best suited for specifications for high definition 4K @ 60 Hz (4:4:4, 4:2:2) video.
However, video or audio may not be supported depending on the specifications of the external devices. If this is the
case, please connect to a different HDMI port.
ENGLISH_ ind ex
15
ENTERTAINMENT
Using Multimedia Features
Connecting USB/SD Storage Devices
Connect a USB storage device such as a USB flash memory, SD storage devices or an external hard drive to the display
and use multimedia features.
CAUTION
•Do not turn the monitor off or remove the USB storage device while Photo & Video or Music is playing.
•Back up files you have saved on a USB storage device frequently, as loss or damage to the files may be not covered by
the warranty.
ENGLISH_ ind ex
16
Tips for using USB/SD storage devices
•Only a USB storage device can be recognized.
•A USB device does not work effectively when it is connected via a USB hub.
•A USB storage device using an automatic recognition program may not be recognized.
•A USB storage device using its own driver may not be recognized.
•The recognition speed of a USB storage device may depend on each device.
•Please do not turn off the display or unplug the USB storage device when the connected device is working. If the USB
storage device is suddenly disconnected, the stored files or the device itself may be damaged.
•Please do not connect a USB storage device which was modified to work on a PC. The device may cause the monitor
to malfunction or the content fail to be played. Use only a USB storage device which contains normal music, image or
video files.
•A USB storage device formatted as a utility program not supported by Windows may not be recognized.
•A USB storage device (over 0.5 A) which requires an external power supply must be connected to a power supply
separately. If it is not, the device may not be recognized.
•Please connect the USB storage device using the cable provided by the device manufacturer.
•Some USB storage devices may not be supported or operate smoothly.
•File alignment method of USB storage devices is similar to that of Window XP and filenames can recognize up to 100
English characters.
•Back up important files regularly as data stored on a USB storage device may be damaged. We will not be responsible
for any data loss.
•If the USB HDD does not have an external power source, the USB device may not be detected. To ensure the device is
detected, connect the external power source.
- Please use a power adapter for an external power source. We do not provide a USB cable for an external power
source.
ENGLISH_ ind ex
18
Photo & Video
•The photo feature is not supported in OLED models.
Supported Photo & Video Files
Supported External Subtitle Format
•*.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX), *.dcs (DLP Cinema)
NOTE
•Subtitles are not supported in certain models.
•Embedded subtitles are not supported.
Supported Video Codecs
Extension Codec
.asf, .wmv Video VC-1 Advanced Profile (excluding WMVA), VC-1 Simple and Main Profiles
Audio WMA Standard (excluding WMA v1 / WMA Speech)
.avi Video Xvid (excluding 3 warp-point GMC), H.264/AVC, Motion Jpeg, MPEG-4
Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby Digital, LPCM, ADPCM, DTS
.mp4, .m4v, .mov Video H.264/AVC, MPEG-4, HEVC
Audio Dolby Digital, Dolby Digital Plus, AAC, MPEG-1 Layer III (MP3)
.3gp, .3g2 Video H.264/AVC, MPEG-4
Audio AAC, AMR-NB, AMR-WB
.mkv Video MPEG-2, MPEG-4, H.264/AVC, VP8, VP9, HEVC
Audio Dolby Digital, Dolby Digital Plus, AAC, PCM, DTS, MPEG-1 Layer I, II, MPEG-1
Layer III (MP3)
.ts, .trp, .tp, .mts Video H.264/AVC, MPEG-2, HEVC
Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby Digital, Dolby Digital Plus,
AAC, PCM
.mpg, .mpeg, .dat Video MPEG-1, MPEG-2
Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3)
.vob Video MPEG-1, MPEG-2
Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM
NOTE
•3D videos are not supported.
ENGLISH_ ind ex
19
Maximum data transfer rate
•Full HD video
H.264 1920 x 1080@60P BP/MP/HP@L4.2 40 Mbps
HEVC 1920 x 1080@60P MP@L4.1, Main10 Profile@L4.1 40 Mbps
•Ultra HD (For Ultra HD models only)
H.264 1920 x 1080@60P 4096 x 2160@30P BP/MP/HP@L5.1 50 Mbps
HEVC 4096 x 2160@60P MP@L5.1, Main10 Profile@L5.1 50 Mbps
Supported Photo File
File Format Format Item
.jpeg, .jpg, .jpe JPEG •Minimum: 64 x 64
•Maximum
- Normal Type: 15360 (W) x 8640 (H)
- Progressive Type: 1920 (W) x 1440 (H)
.png PNG •Minimum: 64 x 64
•Maximum: 5760 (W) x 5760 (H)
.bmp BMP •Minimum: 64 x 64
•Maximum: 1920 (W) x 1080 (H)
ENGLISH_ ind ex
20
Viewing Photos and Videos
/
1 Select your desired storage device.
2 Select and view your desired photo or video.
Tips for Playing Video Files
•Some user-created subtitles may not work properly.
•Some special characters in subtitles are not rendered.
•HTML tags are not supported in subtitles.
•Subtitles in languages other than the supported languages are not available.
•The screen may suffer temporary interruptions (image stoppage, faster playback, etc.) when the audio language is
changed.
•A damaged video file may not play correctly, or some player functions may not be usable.
•Video files produced with some encoders may not be played correctly.
•If the video and audio structure of a recorded file is not interleaved, either video or audio is outputted.
•Video files other than the specified types and formats may not play correctly.
•Maximum bit rate of playable video file is 20 Mbps. (Motion JPEG: 10 Mbps only)
•We cannot guarantee smooth playback of files encoded level 4.1 or higher in H.264 / AVC.
•Video files more than 30 GB in file size are not supported.
•A video file and its subtitle file must be located in the same folder. A video file name and its subtitle file name must be
identical in order to display the subtitle properly.
•Playing a video via a USB connection that does not support high-speed connection may not function correctly.
•Subtitles on a Network Attached Storage (NAS) device may not be supported depending on the manufacturer and
model.
•Streaming of files encoded by GMC (Global Motion Compensation) or Qpel (Quarterpel Motion Estimation) is not
supported.
•(For Ultra HD models only) Ultra HD image: 3840 X 2160
Some HEVC-encoded Ultra HD videos other than the content officially provided by LG Electronics may not be played.
Some codecs can be used after upgrading software.
Extension Codec
.mkv, .mp4, .ts Video H.264/AVC, HEVC
Audio Dolby Digital, Dolby Digital Plus, AAC, HE-AAC
•Playable file sizes may vary depending on the encoding condition.
•The AAC Main profile is not supported.
•Video files created by some encoders may not play.
ENGLISH_ ind ex
22
Music
Supported Music Files
•Some of the models that do not support the audio output cannot play the music.
File Format Item Information
.mp3 Bit rate 32 Kbps to 320 Kbps
Sample freq. 16 KHz to 48 KHz
Support MPEG1, MPEG2
Channels Mono, Stereo
.wav Bit rate -
Sample freq. 8 kHz to 48 kHz
Support PCM
Channels Mono, Stereo
.ogg Bit rate 64 Kbps to 320 Kbps
Sample freq. 8 kHz to 48 kHz
Support Vorbis
Channels Mono, Stereo
.wma Bit rate 128 Kbps to 320 Kbps
Sample freq. 8 kHz to 48 kHz
Support WMA
Channels Up to 6 channels
Playing Music
/
1 Select your desired storage device. You can select the songs you would like to play across all storage devices in My
playlist.
2 Select the desired music content and enjoy.
Delete
/
1 Select your desired storage device.
2 Enter the path to the file you wish to delete.
3 Click the Delete button.
4 Select the file you wish to delete.
5 Click the Delete button at the top right.
6 Check that the file has been deleted from the list.
ENGLISH_ ind ex
23
SuperSign Contents
Plays stored files using the Export option in SuperSign Editor.
To play back the stored files using the Export option
/
Only contents distributed by SuperSign Manager are displayed and selectable. If there is a USB/SD storage device
connected, the image on the USB/SD device is outputted additionally.
NOTE
•If a folder named normal or AutoPlay exists on the USB/SD card and there are playable files, the files will play
automatically when the USB/SD card is connected.
•OLED product types do not play content types other than single video or single flash files. Content produced via
SuperSign Editor is not played either.
Information
To check the basic information of Signage Monitor
/
You can see the basic information on Signage Monitor.
You can also switch to Smart Energy Saving Mode or configure Fail Over settings. (You can switch to Smart Energy
Saving Mode only when Energy Saving Mode is set to Off. The Smart Energy Saving mode is not available on OLED
models.)
ENGLISH_ ind ex
26
Group Manager
•Only applies to certain models.
Using this template-based content editing program, you can produce, manage and play content. There are three modes:
Master, Slave and StandAlone. The program can be used to distribute and play schedules between the Master and
Slave. It also provides access from mobile device or PC.
CAUTION
•A maximum of 5,000 images stored on a USB drive/SD card can be displayed from your PC or mobile device. Images
more than 5,000 cannot be displayed from your PC or mobile device. In addition, we recommend you store no more
than 1,000 images for use on your USB drive or SD card. If you use more than 1,000 images, the images may not be
displayed smoothly depending on your environment.
•Supported devices (Some features may not be available depending on the type or version of your device or browser.)
- Android 4.4 or later (Chromium v.38.0)
- iOS 8 or later (Safari v.600.1.4 or later)
- PC: Chromium v.38.0
•Supported resolutions (this program is optimized for the following resolutions):
- 360 x 640, 600 x 960, 375 x 667, 768 x 1024 and 1920 x 1080
•If you play UHD videos on a UHD model, videos with a high bitrate may not play properly due to the limitations of the
processing speed.
•You can select Slave mode in Master mode when the monitors are connected to the same network.
•Video files larger than 50 MB may not upload properly from mobile devices. We recommend that you play such files
via USB/SD storage devices.
Function
The following functions are provided according to the mode selected by the user. However, Slave mode is automatically
set to the monitor selected in Master mode.
•Master
- Group: Add / Edit / Delete / Control (Volume, Backlight, Reboot, Exit)
- Content: Add / Edit / Delete
- Schedule: Add / Edit / Delete / Distribute / Play
- Edit PIN Number / Automatic USB Backup / USB Backup Restoration / Mail Settings / QR Code / Device Mode
•Slave
- Plays the schedule distributed by the Master
•StandAlone
- Content: Add / Edit / Delete
- Schedule: Add / Edit / Delete / Distribute / Play
- Edit PIN Number / QR Code / Device Mode
ENGLISH_ ind ex
27
How to Use
•Monitors: Run the app in the Launcher bar and add/edit/delete the desired content.
•Mobile devices: Run the app in the Launcher bar and get access using the QR code or URL provided.
NOTE
•If you use a mobile device, you need to go through an authorization process using a PIN code. The default PIN code is
‘000000’.
•When using a PC, use the full screen (F11) feature in 1920 x 1080 (Full HD) resolution to view the same screen as
the monitor.
•To delete a distributed schedule, disable the schedule and redistribute.
Supported Photo Files
File Format Format Item
.jpeg, .jpg JPEG •Minimum: 64 x 64
•Maximum: 1920 (W) x 1080 (H)
.png PNG •Minimum: 64 x 64
•Maximum: 1920 (W) x 1080 (H)
Supported Video Codecs
Refer to the ‘Supported Video Codecs’ table of Photo & Video app.
Tips for Playing Video Files
Refer to the ‘Tips for Playing Video Files’ subsection of Photo & Video app.
ENGLISH_ ind ex
28
Leveler Tool
•Only applies to certain models.
You can check whether the product is horizontally and vertically level when installing the product outdoors in an
enclosure.
Accessing the Leveler Tool
/
You can check whether the product is horizontally and vertically level.
Exiting the Leveler Tool
Exit the Leveler Tool by pressing the EXIT key on your remote control.
Checking the Angle of the Product
/
•You can check the tilt of the product using the bubble in the leveler and the angle indication.
•The left/right tilt is indicated by the leveler and angle indication on the left side of the screen.
•The front/back tilt is indicated by the leveler and angle indication on the right side of the screen.
NOTE
•If the product is tilted more than five degrees in any direction, an arrow will flash in the direction the product needs
to be adjusted to.
Specyfikacje produktu
| Marka: | LG |
| Kategoria: | monitor |
| Model: | 75XF3ES |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z LG 75XF3ES, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje monitor LG
28 Marca 2025
12 Marca 2025
25 Lutego 2025
25 Lutego 2025
25 Lutego 2025
25 Lutego 2025
20 Lutego 2025
19 Lutego 2025
4 Lutego 2025
30 Stycznia 2025
Instrukcje monitor
- monitor Sony
- monitor Yamaha
- monitor Samsung
- monitor PeakTech
- monitor UPERFECT
- monitor Xiaomi
- monitor Joy-It
- monitor Sharp
- monitor Huawei
- monitor TCL
- monitor Pioneer
- monitor Lenovo
- monitor Philips
- monitor Plantronics
- monitor SilverCrest
- monitor Gigabyte
- monitor Acer
- monitor Bosch
- monitor Epson
- monitor JBL
- monitor Hikvision
- monitor Fujitsu
- monitor HyperX
- monitor LC-Power
- monitor Hisense
- monitor Panasonic
- monitor Promethean
- monitor Canon
- monitor Crestron
- monitor Viewsonic
- monitor Behringer
- monitor Asus
- monitor AG Neovo
- monitor Allen & Heath
- monitor IK Multimedia
- monitor Medion
- monitor Boss
- monitor Marquant
- monitor MSI
- monitor Toshiba
- monitor Tesla
- monitor Westinghouse
- monitor Jensen
- monitor Yealink
- monitor Ring
- monitor Garmin
- monitor Blaupunkt
- monitor Salora
- monitor Iiyama
- monitor Citizen
- monitor APC
- monitor Haier
- monitor HP
- monitor Hyundai
- monitor Honeywell
- monitor Chauvet
- monitor Tripp Lite
- monitor Shure
- monitor Cisco
- monitor Xerox
- monitor Smart
- monitor Cooler Master
- monitor Alpine
- monitor Godox
- monitor Dynaudio
- monitor Deltaco
- monitor JVC
- monitor V7
- monitor Dell
- monitor IFM
- monitor Corsair
- monitor Alesis
- monitor Vimar
- monitor Dahua Technology
- monitor Schneider
- monitor Eurolite
- monitor Ricoh
- monitor SMART Technologies
- monitor NZXT
- monitor Emos
- monitor Renkforce
- monitor Marshall
- monitor Viessmann
- monitor Omron
- monitor Thomson
- monitor Velleman
- monitor Neumann
- monitor DataVideo
- monitor Danfoss
- monitor Pyle
- monitor Apple
- monitor Newline
- monitor Waeco
- monitor AOC
- monitor Peerless-AV
- monitor Speco Technologies
- monitor Samson
- monitor PreSonus
- monitor ARRI
- monitor Kindermann
- monitor Olympus
- monitor Mitsubishi
- monitor Fluid
- monitor Razer
- monitor ART
- monitor Continental Edison
- monitor RCF
- monitor NEC
- monitor Brandson
- monitor Prestigio
- monitor OSEE
- monitor Sanyo
- monitor Elvid
- monitor Optoma
- monitor Focal
- monitor Asrock
- monitor Monkey Banana
- monitor Abus
- monitor AMCV
- monitor Jay-Tech
- monitor Mackie
- monitor Palmer
- monitor Barco
- monitor Insignia
- monitor AVer
- monitor Akuvox
- monitor 3M
- monitor Element
- monitor Denver
- monitor Marshall Electronics
- monitor Orion
- monitor Hitachi
- monitor Postium
- monitor Kali Audio
- monitor IStarUSA
- monitor Seiki
- monitor Ernitec
- monitor Wohler
- monitor SmallHD
- monitor AJA
- monitor KRK
- monitor BenQ
- monitor Atlona
- monitor Thermaltake
- monitor Simrad
- monitor Hanwha
- monitor Odys
- monitor Elo
- monitor Ikan
- monitor BOOX
- monitor JUNG
- monitor Burg Wächter
- monitor Eizo
- monitor Monacor
- monitor Aputure
- monitor Daewoo
- monitor Tannoy
- monitor GVision
- monitor Positivo
- monitor Adj
- monitor Freedom Scientific
- monitor SPL
- monitor Qian
- monitor I3-Technologies
- monitor Stairville
- monitor Vitek
- monitor Planar
- monitor Mobile Pixels
- monitor REVO
- monitor Atomos
- monitor Newstar
- monitor SWIT
- monitor Kramer
- monitor RGBlink
- monitor AMX
- monitor Midas
- monitor Alienware
- monitor Archos
- monitor Acti
- monitor Emachines
- monitor Caliber
- monitor Maxdata
- monitor Sunstech
- monitor GlobalTronics
- monitor Sunny
- monitor BlueBuilt
- monitor Da-Lite
- monitor ProXtend
- monitor Kubo
- monitor GeoVision
- monitor LaCie
- monitor InFocus
- monitor Festo
- monitor Konig
- monitor Swissonic
- monitor IHealth
- monitor Peaq
- monitor QSC
- monitor Hannspree
- monitor ESI
- monitor Avocor
- monitor Vivitek
- monitor Genelec
- monitor Interlogix
- monitor Vorago
- monitor EverFocus
- monitor POSline
- monitor Peerless
- monitor M-Audio
- monitor Mad Catz
- monitor Krom
- monitor Monoprice
- monitor Eve Audio
- monitor Yorkville
- monitor HoverCam
- monitor Voxicon
- monitor Sonifex
- monitor TV One
- monitor Fostex
- monitor Prowise
- monitor Terra
- monitor Neets
- monitor Soundstream
- monitor Xoro
- monitor HKC
- monitor CTOUCH
- monitor Ozone
- monitor Ibm
- monitor Maxell
- monitor Packard Bell
- monitor Provision ISR
- monitor Mybeo
- monitor CSL
- monitor Bearware
- monitor Drawmer
- monitor Blue Sky
- monitor Zalman
- monitor Iadea
- monitor Advantech
- monitor Hercules
- monitor Avantone Pro
- monitor Ganz
- monitor TVLogic
- monitor Gamber-Johnson
- monitor Extron
- monitor Neat
- monitor Legamaster
- monitor Belinea
- monitor Adam
- monitor Triton
- monitor ITek
- monitor Kogan
- monitor Posiflex
- monitor Antelope Audio
- monitor MicroTouch
- monitor X-Rite
- monitor EKO
- monitor ONYX
- monitor IBoardTouch
- monitor Mirai
- monitor Elite Screens
- monitor Hollyland
- monitor Mitsai
- monitor Christie
- monitor Skytronic
- monitor Enttec
- monitor Feelworld
- monitor Phoenix Contact
- monitor COMMBOX
- monitor Yiynova
- monitor Alogic
- monitor Pelco
- monitor Lilliput
- monitor LightZone
- monitor AOpen
- monitor Planet Audio
- monitor EC Line
- monitor Datacolor
- monitor HELGI
- monitor Desview
- monitor Syscom
- monitor Allsee
- monitor Night Owl
- monitor ProDVX
- monitor Varad
- monitor PureTools
- monitor DoubleSight
- monitor CTL
- monitor Game Factor
- monitor Nixeus
- monitor Chimei
- monitor Blue Sea
- monitor Faytech
- monitor Hamlet
- monitor Wyse - Dell
- monitor Approx
- monitor Bauhn
- monitor GeChic
- monitor Oecolux
- monitor ADS-TEC
- monitor Satco
- monitor Casalux
- monitor Jupiter
- monitor Transvideo
- monitor Innocn
- monitor KeepOut
- monitor Shimbol
- monitor Raysgem
- monitor Motrona
- monitor Ikegami
- monitor AORUS
- monitor Portkeys
- monitor Mimo Monitors
- monitor American Dynamics
- monitor AIS
- monitor Wortmann AG
- monitor Viotek
- monitor Vidi-Touch
- monitor KTC
- monitor CoolerMaster
- monitor Atlantis Land
- monitor HEDD
- monitor Colormetrics
- monitor IOIO
- monitor DTEN
- monitor Cocopar
- monitor Titan Army
- monitor Xenarc
- monitor Delvcam
- monitor Wimaxit
- monitor BookIT
- monitor SideTrak
- monitor TRIUMPH BOARD
- monitor Japannext
Najnowsze instrukcje dla monitor
8 Kwietnia 2025
8 Kwietnia 2025
8 Kwietnia 2025
7 Kwietnia 2025
5 Kwietnia 2025
4 Kwietnia 2025
4 Kwietnia 2025
3 Kwietnia 2025
2 Kwietnia 2025
2 Kwietnia 2025
