KVM-9036 CAT5 USB KVM Extender

CAT5 USB KVM Extender

Transmitter (Tx) Unit x 1

Receiver (Rx) Unit x 1

USB Cable x 2KVM

Power Adapters (DC5V) x 2

This Quick Installation Guide x 1

Transmitter Unit (Local End Connection) )

[Tx Front-panel]–

a. Power LED (Lights when power on)is

b. Link LED (Lights when link on)is

c. USB keyboard connector

d. USB mouse connector

e. Select Button for Receiver Mode (View Only/Full

Access/Access Deny)

f. Video LED (Lights when Remote Console monitor is on)

g. Control LED (Lights when Remote Console on)is

[Tx Back panel]–

h. Power jack (DC5V, center-positive)

i. CAT5 Extension Port [RJ-4 connect 5, to the Receiver Unit

via a CATx UTP cable, 100 M max.] eter

j. Computer port [HDB-15(VGA), connect to the (Local)

computer using a special 3-in-1 KVM Combo-free cable]

Upgrade port (USB Type dedicated for rmware upgradeB,

use)

Receiver Unit (Remote End Connection)

[Rx-front panel]

1. Power LED (Lights when power on)is

2. Link LED (Lights when link on)is

3. USB keyboard connector

4. USB mouse connector

5. Toggle Button for Local / Remote Computers

6. Local Computer LED (Lights when Local computer active)

7. Remote Computer LED (Lights when Remote computer active)

[RX-back-panel]

8. Power jack (DC5V, center-positive)

9. CAT5 Extension Port [RJ-4 connect 5, to the (Remote)

computer via a CATx UTP cable, 100 Meter max

10. Computer port [HDB-15(VGA), connect the (Local)to

computer using a special 3-in-1 Combo-free cable]KVM

11. Upgrade Port (USB Type dedicated for firmware upgradeB,

use)

12. Console Video port [HDB-15(VGA), connect monitor]to

OSD Main Menu

On the Receiver Unit, the OSD (on-screen display) Menu

control available is to facilitate more intuitive operations. Users

can congure various settings by the OSD Menu:

OSD Menu

To navigate the OSD Menu, just use the following keys

Esc: Exit,

→Left/Right cursor: change value the menu optionin

Up/Down Cursor: Navigate.

F10: Logout the OSD Menu (However, the password if

protection is not enabled, the Logout feature will not be

available)

Hotkey sequence = [Scroll Lock] + [Scroll Lock] + H +(y)** *

(y) = CAPS, F12 NUMor

⚫ Note that the hotkey preceding sequence setting the on

Receiver Console will not aect the hotkey preceding

sequence on the Transmitter Console, which will always

allow Scroll Lock + Scroll Lock preceding hotkey. as In

addition using the hotkey command and can also use the to

OSD menu change the hotkey preceding sequence.to

Please refer the previous section.to

Auto logout: [0 ~ 10]

Disable / Enable the Logout timeout (0~10min, 0 = Disable).

The Auto logout time can congured from 0 (Disable), right be up

to Min. 10 If the password protection not enabled, the Auto is

logout will not be put into function.

Hotkey: [Scroll Lock (Default)]

To change

the preceding sequence hotkey pressby , →to select

the CAPS, F12 or NUM.

OSD Timeout: [0~60]

Congured the OSD timeout value, start at seconds, with 20 an

increment 5 of up seconds (0~60 seconds, 0 = Disable).to 60

O Shared Console

Congured the Console Control [(Disable/Enable the timeout value

(0~30 seconds, 0= Disable)]

Note: Local Remote switching engaged priority offers and

“Deadlock Function , the deadlock function protect while al”to one

user (either one) was using, the other user have wait until the to

rst user released the process, then the other user can start to use.

When the deadlock active, the is Transmitter’s LED “Video” &

“Control” ashing, until the user released the process control.is

⚫ The blue component color adjusted automatically is as in

proportion the red and green. Users need adjust to do no to

⚫

themselves.

In order achieve optimized video output to on the console

that may 100M Meters away from the computer, users be

could adjust these various parameters conscientiously to

achieve an on optimized video output the console monitor.

For a general guideline how adjust your video display of to

parameters the remote console, please refer next on to

section, Optimize the Video Display the Remote Console.on

Load Default Settings

Load the factory default settings.

FCC / CE Statements

FCC Statement: This equipment has been tested and found to

comply with the regulations for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed provide to

reasonable protection against harmful interference when the

equipment operated a is in commercial environment. This

equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used accordance with this Quick in

Installation Guide, may cause harmful interference radio to

communications. Operation this equipment a residential area of in

is likely cause harmful interference which case, the user will to in

be required correct the interference to at his/her own expense.

CE Statement: This a Class B product a domestic is in

environment, this product may cause radio interference, which in

case the user may required take adequate measures.be to

Deutsch

Installationsschema.

Français

Schéma d'installation.

Españ ol

Diagrama de instalación.

Italiano

Diagramma di installazione.

Português

Diagrama de instalação

English

Installation diagram

Model No.

Component Units

KVM-9036 CAT5 KVM Extender

1 x TX a console) (transmitter w/

1 x -RX w/ console & built-in (receiver a

KVM switching function)

Console Keyboard &

mouse support

USB

Computer connection USB

Number of Console 1 x local console (on TX unit)

1 x remote console (on RX unit)

Max. PC Connections 1 x computer for TX

2 x computer for RX (1 x computer 100M

max. away + 1 x computer in proximity)

RX Connectors 1 x HDB 15-pin Female (for VGA monitor)

1 x HDB 15-pin Female (for computer- integrated with video, keyboard and mouse)

1 x USB Type B Upgrade port

2 x USB Type A for keyboard & mouse –

1 x RJ45

1 x DC5V power jack

TX Connectors 1 x HDB 15-pin Female (for VGA monitor)

1 x HDB 15-pin Female (for computer- integrated with video, keyboard and mouse)

1 x USB Type B Upgrade port

2 x USB Type A for keyboard & mouse –

1 x RJ45

1 x DC5V power jack

DDC/EDID Emulation 2 Modes Local Monitor / Remote Monitor DDC Emulation –

OSD Yes

LEDs [On receiver]

1 x Red Power –

1 x Green Link –

1 x Green Local (lit Local computer active) – –

1 x Green Remote (lit - Remote computer active -lit) –

[On transmitter]

1 x Red Power –

1 x Green Link –

1 x Green Video (lit Video active for remote console) – –

1 x Green Control (lit Keyboard & mouse control available for remote console) – –

Keyboard/Mouse

Emulation

USB

Skew Compensation No

Extension Distance 100M

VGA Resolution 1 0 x 1200 92

Case Metal

Power Adapter DC 5V

Safety / Emission FCC, CE

Features

10 CAT5 extension 0M distance

Built-in KVM the Receiver UnitSwitching feature on

Local / Remote computer selection on Receiver console by a switch button and keyboard hotkeys

Remote Console Access Mode Selection for ON/OFF/View Only by switch buttons and keyboard hotkeys

USB connectivity support on console and computer side

OSD Menu-driven control for easy system conguration

Keyboard hotkey control for conguration and operation

Full keyboard and mouse emulation to support Microsoft and Logitech standard 5 key mouse and

compatibles.

DDC/EDID support mode selection for Local / Remote Monitor by OSD and keyboard hotkeys

Easy plug-and-play extend your up 100 M awayto second console to eter

Analog video resolution support up to 1 0 x 120092

Firmware upgradeable via USB interface

Specifications
