Strona 1/4
Minolta Co., Ltd. 3-13, 2-Chome, Azuchi-Machi, Chuo-Ku, Osaka 541-8556, Japan
Minolta GmbH Kurt-Fischer-Strasse 50, D-22923 Ahrensburg, Germany
Minolta France S.A. 365 Route de Saint-Germain, F-78420 Carrieres-Sur-Seine, France
Minolta (UK) Limited Rooksley Park, Precedent Drive, Rooksley, Milton Keynes, MK13 8HF, UK
Minolta Austria Ges. m.b.H. Amalienstrasse 59-61, A-1131 Wien, Austria
Minolta Camera Benelux B.V. Zonnebaan 39, P.O. Box 6000, NL-3600 HA Maarssen, The Netherlands
Belgium Branch Kontichsesteenweg 38, B-2630 Aartselaar, Belgium
Minolta (Schweiz) AG Riedstrasse 6 CH-8953 Dietikon, Switzerland
Minolta Svenska AB P.O.Box 9058, Albygatan 114, S-17109 Solna, Sweden
Finland Branch Niittykatu 6 PL 37 SF-02201 Espoo, Finland
Minolta Portugal Limitada
Av. do Brasil 33-A,
P-1700 Lisboa, Portugal
Minolta Corporation
Head Office 101 Williams Drive, Ramsey, New Jersey 07446, U.S.A.
Los Angeles Branch 11150 Hope Street Cypress, CA 90630, U.S.A.
Minolta Canada Inc.
Head Office 369 Britannia Road East, Mississauga, Ontario L4Z 2H5, Canada
Vancouver Branch 230-3771 Jacombs Road, Richmond, B.C. V6V 2L9, Canada
Minolta Hong Kong Limited Room 208, 2/F, Eastern Center, 1065 King’s Road, Quarry Bay, Hong Kong, China
Minolta Singapore (Pte) Ltd. 10, Teban Gardens Crescent, Singapore 608923
Shanghai Minolta Optical Products Co., Ltd. 368 Minolta Road, Songjiang, Shanghai, China
INSTRUCTION MANUAL
© 1998 Minolta Co., Ltd. under the Bern Convention
and Universal Copyright Convention
Printed in China
9222-2220-37 PR-A802
Advantages of the Advanced Photo System
Easier to load…
Advanced Photo System cameras use the new IX240 type film. This new
film features drop-in-loading to make loading your camera simple, the first
time, every time. Indicators on the cassette tell you and your camera if the
film is unexposed, partially exposed, exposed, or processed.
Read and understand all warnings and cautions before using
this product.
WARNING
Thank you for purchasing this Minolta camera. Your camera is an
easy to operate lens shutter camera from Minolta’s line of
Advanced Photo System™ cameras.
This manual is designed to help you understand the operation of
your camera and its functions. Please familiarize yourself with
the names of the controls and their locations on the camera, then
read this manual thoroughly.
S
E
Camera Type: IX240 Lens shutter camera
Lens: 24mm f/4.5
Focusing Range: 0.8m - ∞(2.6 ft. - ∞)
Film Speed Setting: Automatic setting for ISO100, 200/400
Metering Range (ISO 200):
EV6 - EV16
Flash Range (ISO 200):
0.8 - 5.6m (2.6 - 18.2 ft.)
Battery: CR2 (3V) lithium battery x 1
Battery performance: Approx. 12 rolls with a CR2 lithium cell (based on
Minolta’s standard test method, using 25 exposure
film with flash on for 50% of the exposures).
Viewfinder: Magnification 0.64X
Dimensions WxHxD: 110 x 63.5 x 39mm
(4.4 x 2.5 x 1.5 in.)
Weight: 155g (5.5 oz.)
Specifications are based on the latest information available at the time of
printing and are subject to change without notice.
SPECIFICATIONS
OPERATING TEMPERATURE AND CONDITIONS
• This camera will only load film with the Unexposed ●mark current.
• DEP, Double Exposure Prevention, prevents the camera from
accepting exposed film.
• This camera is designed for use for -5°C to 40°C (23°F to 104°F).
• Never leave your camera where it may be subjected to extreme
temperatures such as the glove compartment of a car.
• At colder temperatures, the data panel response time will be slow; at
higher temperatures, the display will temporarily darken, but will restore
when the temperature normalizes.
• Never subject your camera to extreme humidity.
• To prevent condensation from forming, place the camera in a sealed
plastic bag when bringing it from the cold exterior to a warm building.
Allow it to come to room temperature before removing it from the bag.
• When photographing in cold weather, we recommend that you keep the
camera and spare batteries inside your coat to keep them warm when
you are not shooting. Cold batteries will regain some of their charge
when they warm up.
• This camera is not waterproof, dust-proof, or sand-proof; take care
when using it at the beach or near water. Costly or irreparable damage
may occur.
Batteries may become hot or explode due to improper use.
• Use only the batteries specified in this instruction manual.
• Do not install the batteries with the polarity (+/–) reversed.
• Do not subject batteries to fire or high temperatures.
• Do not attempt to recharge, short, or disassemble.
• Tape over lithium battery before disposal. Follow local codes for
battery disposal.
Use caution, accidents may occur when using this product
near young children.
Keep batteries or things that could be swallowed away from
young children. Contact a doctor immediately if an object is
swallowed.
Immediately remove the batteries and discontinue use if...
• the camera is dropped or subjected to an impact in which the
interior is exposed.
• the product emits a strange smell, heat, or smoke.
Do not disassemble. Electric shock may occur if a high volt-
age circuit inside the camera is touched. Take your camera
to a Minolta Service Facility when repairs are required.
VEI, Visual Exposure Indicators
MANUAL DE INSTRUCCIONES
This mark on the bottom of your camera certifies that this camera meets
the requirements of the EU (European Union) concerning interference
causing equipment regulations. CE stands for Conformité Européenne
(European Conformity).
BODY TOP and FRONT
1. Meter window*
2. Shutter-release button
3. Format switch
4. Viewfinder window*
5. Self-timer/Red-eye reduction lamp
6. Self-timer button
7. Lens*
8. Lens-cover/Main switch
9. AF windows*
10. Flash* * Do not touch
NAMES OF PARTS
To receive the best possible prints, take your
film to a photolab displaying the Certified
Advanced Photo System logo. Photofinishers
displaying this logo have been certified
according to Advanced Photo System
guidelines.
New print formats…
Classic C print, wider H print, and panorama P print formats are
available with Advanced Photo System cameras.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation. Changes or modifications not approved by the party responsible for compliance
could void the user's authority to operate the equipment. This equipment has been tested
and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
BODY BACK and BOTTOM
11. Mode button
12. Manual-rewind button
13. Flash-ready lamp
14. Viewfinder*
15. Data panel
16. Battery-chamber release
17. Battery-chamber door
18. Tripod socket
19. Film-chamber door
20. Film-chamber release
DATA PANEL
21. Flash mode indicators
22. Frame counter
23. Continuous drive indicator
24. Film-transport indicators
25. Battery-condition indicator
New processing…
In addition to returning your prints in the format you selected,
certified photofinishers will return your Advanced Photo System film
in its original cassette with an index print. To order reprints, simply
choose the images you want from the index print. No more
searching through negatives to find the right frame.
Advanced Photo System™ is a trademark of the five system
developing companies.
1. Wait for the film to completely
rewind into the cassette.
• The frame counter will count down during
rewind.
• will appear in the frame counter and
will blink when the film is rewound (M)
.
2. Turn the camera upside-down
and press the film-chamber
release.
3. Open the film-chamber door and
remove the film.
• The film’s VEI indicator will be ✖.
1. Center your subject in the focus
frame , then press the shutter-
release button partway down (K).
2. Without lifting your finger, recompose
the picture, then press the shutter-
release button all-the-way down to take
the picture (L).
• Lift your finger from the shutter-release button to
cancel focus hold.
• Make sure the subject is within the
focus distance of 0.8m - ∞
(2.6 ft. - ∞)( I )
.
3. Center your subject in the focus
frame, then press the shutter-
release button partway down.
• If blinks in the data panel with the shutter-
release button pressed partway down, and
the green flash lamp blinks the flash is
charging ( J )
.
4. When the green flash lamp glows,
press the shutter-release button
all-the-way down to take the
picture.
• After use, slide the main switch to to
close the lens cover and turn the camera off.
1. Turn the camera upside down
and slide the film-chamber
release in the direction
indicated and open the film-
chamber door (D).
2. Insert the film cassette into the
film chamber (E).
•
This camera will only load film with
the ● mark current.
3. Close the film-chamber door
until it clicks.
• The film will advance to the first frame,
then and will appear in the
data panel (F)
.
• If blinks in the data panel, open the
chamber, then remove the film.
- Your camera cannot load a cassette if
the current VEI(Visual Wxposure
Indicators) is ◗ ✖, , or ■.
- If a processed (VEI ■) or partially
exposed (VEI ◗) cassette was loaded
into this camera, the VEI has been
changed to ✖.
1. Slide the battery-chamber
release in the direction
indicated and open the battery
chamber (A).
2. Insert the battery into the
chamber with the – side
entering first (B).
3. Close the battery-chamber
cover until it clicks.
• To save power, your camera will shut
down if it is not operated for more than
five minutes. Close, then open the lens
cover again to restore power.
B
B
B
B
BA
A
A
A
AS
S
S
S
SI
I
I
I
IC
C
C
C
C
O
O
O
O
OP
P
P
P
PE
E
E
E
ER
R
R
R
RA
A
A
A
AT
T
T
T
TI
I
I
I
IO
O
O
O
ON
N
N
N
N
D
E
F
G
H
I
A
B
C
N
M
K
L
J
INSERTING THE BATTERY
Your camera uses one 3-volt CR-2 lithium battery to
supply power for all camera operations.
CHECKING THE BATTERY POWER
Battery-condition indicator appears even with the camera off (C)
.
:Power is sufficient for all
camera operations.
:Power is sufficient, but the
battery will have to be
replaced soon.
:Replace the battery.
The shutter will lock until the
battery is replaced.
No display: Replace battery or
confirm it is inserted correctly.
• The frame counter is resets to when you replace the
battery if film is in the camera.
LOADING THE FILM
Your camera uses IX240 type ISO100-400 speed film
designed for use in Advanced Photo System cameras.
FULL AUTO OPERATION
1. Slide the lens cover switch
to to open the lens cover
and turn the camera on (G).
2. Use the format switch to
choose the print format (H).
• The viewfinder changes to match
your selection.
Hold the camera steady, making
sure your fingers do not cover the
flash. If you are taking a vertically
framed picture, turn the camera so
the flash is on top.
REWINDING THE FILM
MANUAL REWIND
Use manual rewind to rewind the film before the roll is finished.
1. Gently press the manual rewind
button key on the camera strap
or similar object (N).
• Start rewind manually if automatic rewind
does not start after you take the number of
exposures specified on the film cassette.
Additional exposures may overlap
.
2. Follow steps 1- 3 from
automatic rewind.
FOCUS HOLD
When your subject is located outside the focus frame, you can first
lock focus on your subject, then recompose the picture as desired.
Step
Step
Step
Step
AUTOMATIC REWIND
Your camera automatically rewinds the film into the cassette after
the last exposure.

Specyfikacje produktu

Marka: Konica Minolta
Kategoria: Niesklasyfikowane
Model: Vectis 100 BF

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Konica Minolta Vectis 100 BF, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą


Instrukcje Niesklasyfikowane Konica Minolta

Konica Minolta

Konica Minolta Dynax 700Si Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Dynax 9Xi Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Dynax 800Si Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Dynax 500Si Super Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Dynax 500Si Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Dynax 303Si Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Dynax 60 Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta AF-Tele Super Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Auto S2 Instrukcja

23 Września 2024
Konica Minolta

Konica Minolta Dynax 300Si Instrukcja

23 Września 2024

Instrukcje Niesklasyfikowane

Najnowsze instrukcje dla Niesklasyfikowane

Black Diamond

Black Diamond BD1121530000ALL1 Instrukcja

15 Października 2024
Husqvarna

Husqvarna K 970 SmartGuard Instrukcja

15 Października 2024
Stihl

Stihl HT 70 Instrukcja

15 Października 2024
Ernesto

Ernesto H14270 Instrukcja

15 Października 2024
Uniden

Uniden BT MIC KIT Instrukcja

15 Października 2024
Vaude

Vaude Omnis Bike 26 Instrukcja

15 Października 2024
ART

ART ProChannel II Instrukcja

15 Października 2024
Aukey

Aukey DR02J Instrukcja

15 Października 2024
Master Lock

Master Lock 653EURD Instrukcja

15 Października 2024
Roland

Roland FR-18 Diatonic Instrukcja

15 Października 2024
