1
iOptron® SkyHunterTM Portable EQ/AZ GOTO System
Instruction Manual
Product #SHEQA, #SHEQ #SHAZ and
2
Table of Content
Table of Content ................................................................................................................................................. 2
1. SkyHunter Portable EQ/AZ GOTO Mount Overview ................................................................................... 3
2. SkyHunterTM Mount Assembly ...................................................................................................................... 5
2.1. Parts List .................................................................................................................................................. 5
2.2. Identication of Parts .............................................................................................................................. 6
2.3. SkyHunter Ports and Buttons .................................................................................................................. 7
2.4. SkyHunterTM Mount Assembly ............................................................................................................... 8
3. SkyHunterTM Mount Operation .................................................................................................................... 14
3.1. Use mount control panel ........................................................................................................................ 14
3.2. Use mount as a tracking mount ............................................................................................................. 15
3.3. Zero Position ......................................................................................................................................... 15
3.4. Control SkyHunter Mount via iOptron Commander Lite ..................................................................... 16
3.5. Control SkyHunter Mount Using a Hand Controller ............................................................................ 17
3.5.1. Go2Nova® 8410 Hand Controller .................................................................................................. 17
3.5.2. Go2Nova® 8410 Hand Controller Function ................................................................................... 20
3.5.3. Star Identifying Function ................................................................................................................ 27
3.6. Install iOptron iGuider .......................................................................................................................... 27
4. Maintenance and Servicing .......................................................................................................................... 28
4.1. Maintenance .......................................................................................................................................... 28
4.2. iOptron Customer Service ..................................................................................................................... 28
4.3. Product End of Life Disposal Instructions ............................................................................................ 28
4.4. Battery Replacement and Disposal Instructions .................................................................................... 28
Appendix A. Technical Specications ............................................................................................................. 29
Appendix B. Go2Nova® 8410 HC MENU STRUCTURE .............................................................................. 30
Appendix C. Firmware Upgrade ...................................................................................................................... 32
Appendix D. Computer Control a SkyHunter Mount ...................................................................................... 33
Appendix E. Go2Nova® Star List ..................................................................................................................... 34
IOPTRON ONE YEAR TELESCOPE, MOUNT, AND CONTROLLER WARRANTY .............................. 43
WARNING!
NEVER USE A TELESCOPE TO LOOK AT THE SUN WITHOUT A PROPER FILTER!
Looking at or near the Sun will cause instant and irreversible damage to your eye.
Children should always have adult supervision while observing.
Ver. 1.1 2023. 04
iOptron reserves the rights to revise this instruction without notice. Actual color/contents/design/function may dier from those described in this
instruction.
3
1. SkyHunter Portable EQ/AZ GOTO Mount Overview
Introducing the SkyHunter
TM iOptron's new ultra compact EQ/AZ GoTo mount! --
Figure 1 SkyHunter GoTo Mount
The SkyHunterTM mount takes the next step toward perfection. It is the lightest and most compact full
function portable goto mount in iOptron's exceptional history. Weighing in at only 2.9 lbs (including internal
recharg ble battery), the SkyHunter is capable of supporting an 11 lbs payload in both equatorial and alt-ea
azimuth modes.
The SkyHunterTM mount features four tracking rates, 1X or sidereal, 1/2X for sky and landscape
combined, solar and lunar. All 4 tracking rates work in both northern and southern hemispheres.
The SkyHunterTM mount can be controlled by an iOS or Android SmartPhone/tablet, an optional
8410 hand controller, or a computer via ASCOM, INDI or embedded drive.
Features:
Specialized Grab N’ Go GOTO EQ/AZ mount
Mount weighs 2.9 lbs (1.3kg)
Payload 11 lbs (5kg) (balanced, exclude CW)
Dual-axis servomotors with optical encoders
Tracking speed: solar, lunar, 1X, 1/2X, S/N
Operation in both northern and southern hemisphere
Vixen dovetail saddle
Built-in rechargeable battery for up to 10 hours of operation (20°C)
Built-in WIFI adapter for full ASCOM, iOptron Commander
TM and Sky Safari control
USB port for rmware upgrade and computer control
Optional Go2Nova® 8410 controller with Advanced GOTONOVA
® GOTO Technology
iPolar electronic polar scope ( , otherwise optional) #SHEQA
Counterweight Shaft: Φ20X200mm with 3/8” thread, stainless steel
Counterweight: 3 lbs (1.35kg)
Attaches to a camera tripod with 3/8” or 1/4” threads
