HP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitorHP L1506x 15-inch LED Monitor
1.
Button: Menu selection
4.
Button: Power LED
2.
Button: Menu "-" selector button
5.
Button: Power button
3.
Button: Menu "+" selector button
QuickSpecs
HP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitoHP L1506x 15-inch LED Monitor
Overview
DA - 14048 Canada — Version 1 — April 27, 2011
Page 1
PanelPanelPanelPanel
TypeTypeTypeType
TN (Twisted Nematic) WLED Backlit LCD
Viewable Image AreaViewable Image AreaViewable Image AreaViewable Image Area
(diagonal)
15 in (38.1 cm)
Screen OpeningScreen OpeningScreen OpeningScreen Opening
(W x H)
12.1 x 9.1 in (307.4 x 231.3 mm)
Aspect RatioAspect RatioAspect RatioAspect Ratio
4:3
Viewing AngleViewing AngleViewing AngleViewing Angle
(typical)
160 degrees horizontal/140 degrees vertical (10:1 minimum contrast ratio)
BrightnessBrightnessBrightnessBrightness
(typical)
*
400 nits (cd/m
2
)
Contrast RatioContrast RatioContrast RatioContrast Ratio
(typical)
*
700:1
Dynamic Contrast RatioDynamic Contrast RatioDynamic Contrast RatioDynamic Contrast Ratio
(typical)
*
1,000,000:1
Response TimeResponse TimeResponse TimeResponse Time
(typical)
*
8 ms (on/off)
Pixel PitchPixel PitchPixel PitchPixel Pitch
0.297 mm(H) ×0.297 mm(V)
Backlight Lamp LifeBacklight Lamp LifeBacklight Lamp LifeBacklight Lamp Life
(to
half brightness)
50,000 hours typical
Colour GamutColour GamutColour GamutColour Gamut
(typical)
60%
*All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
On Screen DisplayOn Screen DisplayOn Screen DisplayOn Screen Display
(OSD)
ControlsControlsControlsControls
Buttons or SwitchesButtons or SwitchesButtons or SwitchesButtons or Switches
3-button OSD (menu, minus, plus); power on/off
LanguagesLanguagesLanguagesLanguages
English, French, German, Italian, Dutch, Spanish, Netherlands, Japanese,
Portuguese, Traditional Chinese, Simplified Chinese languages
User ControlsUser ControlsUser ControlsUser Controls
Brightness
Contrast
Colour
Image Control
OSD Control
Management
Language
Information
Factory Reset
Exit
Signal Interface/Signal Interface/Signal Interface/Signal Interface/
PerformancePerformancePerformancePerformance
Horizontal FrequencyHorizontal FrequencyHorizontal FrequencyHorizontal Frequency
30 to 63 kHz
Vertical FrequencyVertical FrequencyVertical FrequencyVertical Frequency
50 to 76 Hz
Native ResolutionNative ResolutionNative ResolutionNative Resolution
1024 x 768 @ 60 Hz (recommended)
Preset VESA GraphicPreset VESA GraphicPreset VESA GraphicPreset VESA Graphic
ModesModesModesModes
(non-interlaced)
1024 x 768 @ 60 Hz, 70 Hz, and 75 Hz
832 x 624 @ 75Hz, 800 x 600 @ 60 Hz, 72 Hz, and 75 Hz
720 x 400 @ 70 Hz
640 x 480 @ 60 Hz, 72 Hz, and 75 Hz
Text ModeText ModeText ModeText Mode
720 x 400 @ 70 Hz
Maximum Pixel ClockMaximum Pixel ClockMaximum Pixel ClockMaximum Pixel Clock
SpeedSpeedSpeedSpeed
80 MHz
User ProgrammableUser ProgrammableUser ProgrammableUser Programmable
ModesModesModesModes
Yes (20)
Anti-GlareAnti-GlareAnti-GlareAnti-Glare
Yes
QuickSpecs
HP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitoHP L1506x 15-inch LED Monitor
Technical Specifications
DA - 14048 Canada — Version 1 — April 27, 2011
Page 2
Default ColourDefault ColourDefault ColourDefault Colour
TemperatureTemperatureTemperatureTemperature
Warm (6500K)
Video/Other InputsVideo/Other InputsVideo/Other InputsVideo/Other Inputs
Plug and PlayPlug and PlayPlug and PlayPlug and Play
Yes
Input ConnectorsInput ConnectorsInput ConnectorsInput Connectors
15 pin D-sub (Analog VGA)
Input ImpedanceInput ImpedanceInput ImpedanceInput Impedance
75 ohms (2 % value change allowed)
Sync InputSync InputSync InputSync Input
TTL separate synch
Video CableVideo CableVideo CableVideo Cable
Detachable 15-pin D-sub
Video Cable LengthsVideo Cable LengthsVideo Cable LengthsVideo Cable Lengths
70.8 in (1.8 m)
PowerPowerPowerPower
Input PowerInput PowerInput PowerInput Power
100 - 240 VAC
Typical PowerTypical PowerTypical PowerTypical Power
ConsumptionConsumptionConsumptionConsumption
< 10 W
MaximumMaximumMaximumMaximum
< 15.0 W
Power SavingPower SavingPower SavingPower Saving
< 1.0 W
Power Cable LengthPower Cable LengthPower Cable LengthPower Cable Length
74.8 in (1.9 m); detachable
MechanicalMechanicalMechanicalMechanical
DimensionsDimensionsDimensionsDimensions
(W x D x H)
Unpacked w/standUnpacked w/standUnpacked w/standUnpacked w/stand
13.9 x 13.4 x 7.9 in (35.5 x 34.0 x 20.3 cm)
Unpacked w/o standUnpacked w/o standUnpacked w/o standUnpacked w/o stand
(head only)
11.4 x 13.4 x 2.4 in (29.0 x 34.0 x 6.0 cm)
PackagedPackagedPackagedPackaged
15.6 x 15.6 x 5.9 in (39.5 x 39.5 x 15.0 cm)
WeightWeightWeightWeight
UnpackedUnpackedUnpackedUnpacked
6.83 lb (3.10 kg)
PackagedPackagedPackagedPackaged
9.59 lb (4.35 kg)
Tilt RangeTilt RangeTilt RangeTilt Range
-5 to +30 degrees vertical tilt
Swivel RangeSwivel RangeSwivel RangeSwivel Range
None
Height AdjustableHeight AdjustableHeight AdjustableHeight Adjustable
No
Pivot RotationPivot RotationPivot RotationPivot Rotation
No
BaseBaseBaseBase
Detachable
EnvironmentalEnvironmentalEnvironmentalEnvironmental
Temperature - OperatingTemperature - OperatingTemperature - OperatingTemperature - Operating
0° to 50° C (32° to 122° F)
Temperature - Non-Temperature - Non-Temperature - Non-Temperature - Non-
operatingoperatingoperatingoperating
-20° to 60° C (-4° to 140° F)
Humidity - OperatingHumidity - OperatingHumidity - OperatingHumidity - Operating
20% to 80% non-condensing
Humidity - Non-Humidity - Non-Humidity - Non-Humidity - Non-
operatingoperatingoperatingoperating
5% to 90%
Altitude - OperatingAltitude - OperatingAltitude - OperatingAltitude - Operating
0 to 16,400 ft (0 to 5,000 m)
Altitude - Non-operatingAltitude - Non-operatingAltitude - Non-operatingAltitude - Non-operating
0 to 40,000 ft (0 to 12,100 m)
White LED BacklightsWhite LED BacklightsWhite LED BacklightsWhite LED Backlights
Yes
CCFL PanelCCFL PanelCCFL PanelCCFL Panel
No
Arsenic-Free GlassArsenic-Free GlassArsenic-Free GlassArsenic-Free Glass
*
Yes
* Arsenic and its compounds were not detected using US EPA Test Methods 3052 & 3052/6010b by
or ICP-AES.
BFR/PVC FreeBFR/PVC FreeBFR/PVC FreeBFR/PVC Free
Plastics and Finishes or Paint
Mercury FreeMercury FreeMercury FreeMercury Free
Yes
Environmental DataEnvironmental DataEnvironmental DataEnvironmental Data
Eco-Label CertificationsEco-Label CertificationsEco-Label CertificationsEco-Label Certifications
& Declarations& Declarations& Declarations& Declarations
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these marks:
QuickSpecs
HP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitorHP L1506x 15-inch LED MonitoHP L1506x 15-inch LED Monitor
Technical Specifications
DA - 14048 Canada — Version 1 — April 27, 2011
Page 3
