Models
Undercounter
Worktop
Prep Table
Refrigerated Kitchen Equipment
Steelheart B Series
Service Manual
Number: 73247
Issued: 3-22-2021
Revised: 6-16-2021
hoshizakiamerica.com
2
WARNING
Only qualied service technicians should install and service the appliance. To
obtain the name and phone number of your local Hoshizaki Certied Service
Representative, visit www.hoshizaki.com. No service should be undertaken until
the technician has thoroughly read this Service Manual. Failure to service and
maintain the appliance in accordance with this manual will adversely affect safety,
performance, component life, and warranty coverage. Proper installation is the
responsibility of the installer. Product failure or property damage due to improper
installation is not covered under warranty.
Hoshizaki provides this manual primarily to assist qualied service technicians in the
service of the appliance.
Should the reader have any questions or concerns which have not been satisfactorily
addressed, please call, send an e-mail message, or write to the Hoshizaki Technical
Support Department for assistance.
Phone: 1-800-233-1940; (770) 487-2331
Fax: 1-800-843-1056; (770) 487-3360
E-mail: techsupport@hoshizaki.com
618 Highway 74 South
Peachtree City, GA 30269
Attn: Hoshizaki Technical Support Department
Web Site: www.hoshizaki.com
NOTE: To expedite assistance, all correspondence/communication MUST include the
following information:
• Model Number
• Serial Number
• Complete and detailed explanation of the problem.
3
IMPORTANT
This manual should be read carefully before the appliance is serviced. Read
the warnings and guidelines contained in this booklet carefully as they provide
essential information for the continued safe use, service, and maintenance of the
appliance. Retain this booklet for any further reference that may be necessary.
CONTENTS
Important Safety Information 4 .................................................................................................
I. Construction and Refrigeration Circuit Diagram 8 .................................................................
A. Construction 8 ..................................................................................................................
B. Refrigeration Circuit Diagram ...................................................................................... 10
II. Sequence of Operation and Service Diagnosis ................................................................11
A. Sequence of Operation Flow Chart ..............................................................................11
1. UR/WR: Refrigerator ...............................................................................................11
2. SR: Refrigerator ..................................................................................................... 12
3. UF/WF: Freezer ..................................................................................................... 13
B. Service Diagnosis ....................................................................................................... 14
C. Control Module Check 20 .................................................................................................
D. Thermistor Check ........................................................................................................ 23
E. Diagnostic Table .......................................................................................................... 24
III. Controls and Adjustments 27 ...............................................................................................
A. Temperature Settings .................................................................................................. 27
B. Defrost 28 .........................................................................................................................
C. Safety Devices 29 ............................................................................................................
D. Perimeter and Mullion Heaters (UF/WF only) 29 ..............................................................
IV. Refrigeration Circuit and Component Service Information.............................................. 30
A. Refrigeration Circuit Service Information 32 ....................................................................
B. Component Service Information 35 ..................................................................................
V. Preparing the Appliance for Periods of Non-Use 36 .............................................................
VI. Disposal 37 ..........................................................................................................................
VII. Technical Information ..................................................................................................... 38
A. Electrical and Refrigerant Data 38 ...................................................................................
B. Wiring Diagrams .......................................................................................................... 39
1. UR/WR27, UR/WR36, UR/WR48 (except glass door), and SR36 39 ..........................
2. UF/WF27, SR27, and SR48 40 ....................................................................................
3. UR/WR48 (glass door), UR/WR60, and UR/WR72 41 ...............................................
4. UF/WF48, UF/WF60, SR60, and SR72 42 .................................................................
