03
Reference Manual
© 2023 Roland Corporation
Panel descriptions 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Top panel ....................................................2
Rear panel (connecting your equipment) ........................3
Installing the batteries .......................................3
Outputting sound 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turning the power on/o ......................................4
Turning the power on ........................................4
Turning the power o .......................................4
Setting the connected device type ..............................4
Selecting a guitar amp type (output select) .....................4
Adjusting the volume (output level) ............................4
Tuning your guitar (tuner) .....................................4
Eect signal chain .............................................5
Saving/recalling sounds (memory mode) 6 . . . . . . . . . . . . . . . . . . .
How the patches are congured ................................6
Switching between manual/memory mode ......................6
Setting what happens when switching from memory mode to
manual mode ...............................................6
Selecting a sound (patch) ......................................6
Checking the knob positions ..................................6
Conguring what happens when switching banks ...............7
Saving a sound (patch write) ...................................7
Changing the settings for sounds (memory edit mode) ...........7
Useful functions 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding eects that follow your tempo (tap tempo) ...............8
Setting the modulation speed or delay time with the pedal .......8
Performing with phrase loops ..................................9
Conguring the [CTL] (control) pedal functions ................ 10
Setting the pedal function .................................. 10
Conguring the pedal operations ........................... 10
Connecting to and using an external eect unit via
the SEND/RETURN jacks ..................................... 11
Calibrating the expression pedal ............................. 11
Connecting to your computer via USB . . . . . . . . . . . . . . . . . . . . .12
Installing the USB driver ..................................... 12
Transmitting/receiving audio signals between a computer and
the ME-90 .................................................. 12
USB audio settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Transmitting/receiving MIDI data between a computer and
the ME-90 .................................................. 12
Loading IR data to use this unit as a speaker simulator .......... 13
Wireless connection with a mobile device . . . . . . . . . . . . . . . . . 14
Attaching the BT-DUAL ...................................... 14
Listening to sound via wireless connection with a mobile device . . 14
Bluetooth® 14 audio functionality .............................
Registering a mobile device (pairing) ........................ 14
Connecting an already-paired mobile device ................. 15
Disabling Bluetooth functionality ............................ 15
Controlling the ME-90 from a mobile device app ............... 15
Connecting to the app ..................................... 15
Operating the ME-90 wirelessly with an EV-1-WL/FS-1-WL ...... 15
Conguring the device overall (system settings) . . . . . . . . . . . 16
Parameter list ............................................. 16
Restoring the factory settings (factory reset) . . . . . . . . . . . . . . 17
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting ............................................ 18
Main specications 19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents
2
Panel descriptions
1
Eect conguration knobs
Use these knobs to congure the various eects built into the
ME-90.
* For details on the eect parameters, refer to the “ME-90 Parameter
Guide” (BOSS website).
2
Display
Shows various information for the ME-90.
MEMO
When the batteries are running low, the BATTERY LOW
indicator blinks on the display.
Replace the batteries with new ones.
3
[EXIT], [WRITE], [CTL], [EDIT] buttons
Button Explanation
[EXIT] Press to return to the previous screen or to undo an
operation.
[WRITE] Press to save your patch settings or to execute a
copy operation (p. 6).
[CTL] In memory mode, this congures the operation of
the [CTL] pedal (p. 6).
[EDIT] Enters memory edit mode (p. 7).
4
Expression pedal
Press the toe end of the pedal to switch the pedal eect on/o
(the PEDAL FX indicator turns on/o).
Pedal eect Indicator Pedal operation
O Unlit Volume pedal
On Lit
Controls the eect (such
as wah) that you set using
the [PEDAL FX] knob.
5
[MEMORY/MANUAL] pedal
Switches between memory mode and manual mode (p. 6).
Keep this pressed for two seconds or more to turn the tuner on (p.
4).
6
Pedal switch
Switches between banks and patches when the unit is in memory
mode. In manual mode, this turns each eect on/o.
When in memory mode
Use the pedal switches to switch between banks and patches.
Switch Function
[BANK ], [BANK ]É Ç Switches between banks.
[1]–[4] Switches between patches.
[CTL]
Performs the operation that’s set in
“Conguring the [CTL] (control) pedal
functions” (p. 10).
When in manual mode
Use the pedal switches to individually switch each eect (COMP,
OD/DS, MOD, DELAY, AMP, EQ, REV) on/o.
What is “memory mode”?
The eect combinations and settings (sounds) are recalled as
“patches”. There are 72 patches.
Out of the 72 patches, 36 (4 patches × 9 banks) can be saved in
the user banks (9 banks of presets and 9 user banks).
You can use the pedal to instantly switch between banks and
patches.
What is “manual mode”?
This mode lets you use the pedals to turn each eect on/o. This
lets you use this unit as if you were individually switching the
compact eects on an eect unit board on/o.
7
[OUTPUT LEVEL] knob
Adjusts the volume of the OUTPUT jacks and PHONES jack.
u
Top panel
1
5 6
7
3
Panel descriptions
1
INPUT jack
Connect your guitar here.
2
OUTPUT jacks
Connect these to your guitar amp, mixer or other audio
equipment. For a mono connection, use only the L/MONO jack.
3
Gt. AMP/LINE switch
Set this to “Gt. AMP” when connecting this unit to a guitar amp.
Set this to “LINE” when connecting this unit to a mixer or powered
speakers.
This lets you set the best output for the output destination.
4
PHONES jack
Connect a pair of headphones (sold separately) or a recorder that
uses a stereo mini plug cable. Set the Gt. AMP/LINE switch to
“LINE” when using this jack.
5
SEND/RETURN jacks
Connect an external eect unit here.
You can connect an external eect unit between the SEND jack
and RETURN jack, and use it as one of the ME-90’s eect units (p.
11).
6
Bluetooth ADAPTOR jack
Connect the Bluetooth® Audio MIDI Dual Adaptor (part number
BT-DUAL) to wirelessly play back music from your mobile device
such as a smartphone or tablet (hereafter “mobile device”), or to
edit the eects using an app on your mobile device (p. 14).
Use the volume control on your audio player to adjust the volume
of signal output received from the OUTPUT jacks and PHONES
jack.
7
Ground terminal
* Connect this to an external earth or ground if necessary.
8
USB COMPUTER port
Connect this port to your computer via USB cable. This lets you
transmit/receive audio signals between the ME-90 and your
computer, use the ME-90 dedicated app to edit the sounds and so
on (p. 12).
9
[POWER] switch
This switches the power on and o (p. 4).
10
DC IN jack
Accepts connection of an AC adaptor (BOSS PSA-S series; sold
separately).
* Use the cord hook to secure the cord of the AC adaptor as shown
in the illustration.
* To prevent malfunction and equipment failure, always turn
down the volume, and turn o all the units before making any
connections.
Installing the batteries
Install the batteries into the battery case at
the bottom of this unit. Make sure that the
batteries face the right way.
* When turning the unit over, be careful so
as to protect the buttons and knobs from
damage. Also, handle the unit carefully; do
not drop it.
* We recommend that you keep batteries installed in the unit even
though you’ll be powering it with the AC adaptor. That way, you’ll
be able to continue a performance even if the cord of the AC
adaptor gets accidentally disconnected from the unit.
* If you handle batteries improperly, you risk explosion and uid
leakage. Make sure that you carefully observe all of the items
related to batteries that are listed in “USING THE UNIT SAFELY” and
“IMPORTANT NOTES” (leaet “USING THE UNIT SAFELY”).
WARNING
Handle batteries carefully
If used improperly, you risk the dangers of uid leakage, overheating,
combustion, explosion, etc. Carefully observe the following:
¹Do not heat, disassemble, or toss them into a re or water.
¹Do not expose them to sunlight, ame, or any other source of
extreme heat.
¹Do not attempt to charge a dry cell battery.
+ –
+ –
+–
+–
Rear panel (connecting your equipment)
1 2 3 4 5 6 7 8 9 10
